Chapter 1. Installing Your PCI Modem 7
Windows 2000 Users: A few seconds after startup, you
may see the Digital Signature Not Found dialog box.
You can safely ignore this message and click Yes. Con-
tinue below with Completing the Installation.
Windows XP Users: When the Found New Hardware
Wizard dialog box appears, click Next. You may see a
disclaimer box regarding Windows logo testing. You can
safely disregard this message and click Continue Any-
way. Continue with Completing the Installation.
Completing the Installation
1Open Control Panel (and, in Windows XP only, click
Printers and Other Hardware). Then double-click the
Modems or Phone and Modem Options icon.
2You may be asked to fill out Location Information if you
have not had a modem installed previously. Type the re-
quired information and, when done, click OK or Close.
Windows XP and Windows 2000 Users: Click the Mo-
dems tab, under Phone and Modem Options, to proceed
to Step 3.
3Select the entry for your new modem and then click Prop-
erties.
4Set the Maximum speed to the highest speed available
(115,200).
Windows XP Users: You have to click the Modem tab
before you can set the Maximum speed.
Click OK and close the currently open dialog box.
5Click the Diagnostics tab. In Windows XP, click Query
Modem. Select the port next to the entry for your new mo-
dem (for example, COM3) and click More info or Query
Modem. This step tests the modem by querying it with AT
commands. A list of responses means that your new mo-
dem is properly connected.
