HERO SPLENDOR i Smart Manuale utente
PREFACE
Let us make this world a safer, healthier and more environment friendly place.
This booklet is your guide to the basic operation and maintenance of your new Hero
MotoCorp SPLENDOR i Smart. Please take time to read it carefully. As with any fine
machine, proper care and maintenance are essential for trouble-free operation and
optimum performance.
Thank you for selecting a Hero MotoCorp SPLENDOR i Smart. We wish you many
miles of continued riding pleasure in the years ahead.
We, at Hero MotoCorp, are committed to demonstrate excellence in our environment
performance on a continual basis, as an intrinsic element of our corporate philosophy. To
achieve this we commit ourselves to continue product innovations to improve
environment compatibility, comply with all applicable legislation including
environment legislation and strengthen the green supply chain.
Your motorcycle is conforming to latest (Bharat Stage-III norms) regulation for
emission, safety & noise levels. We are also using non asbestos brake shoes and engine
gaskets which are environment friendly in nature.
Your Authorised Hero MotoCorp dealer will be glad to provide further information or
assistance and is equipped to handle your future service needs.
NOTE
ALL INFORMATION, ILLUSTRATION, PHOTOGRAPH, DIRECTIONS,
SPECIFICATIONS AND OTHER CONTENTS COVERED IN THIS OWNER'S
MANUAL ARE BASED ON THE LATEST PRODUCT INFORMATION
AVAILABLE AT THE TIME OF ITS PRINTING APPROVAL, AND THE
ACCURACY OR CORRECTNESS OF THE SAME IS NOT UNDERTAKEN OR
GUARANTEED. Hero MotoCorp Limited. RESERVES THE RIGHT TO MAKE
CHANGES IN ITS CONTENTS AT ANY TIME WITHOUT NOTICE AND/OR
INCURRING ANY OBLIGATION, WHATSOEVER. NO ONE IS ALLOWED TO
REPRODUCE ANY PART OF THIS PUBLICATION WITHOUT OBTAINING
PRIOR WRITTEN PERMISSION FROM Hero MotoCorp Limited.
STARTER SWITCH / CLUTCH SWITCH
STEERING LOCK / HELMET LOCK
UTILITY BOX
PARKING
ANTI THEFT TIPS
RIGHT HANDLEBAR CONTROLS
15
15
16
17
18
19
19
20
26
27
28
29
31
30
30
31
33
33
FUEL VALVE
i3s (IDLE STOP START SYSTEM) 11
SIDE STAND INDICATOR/SIDE STAND SWITCH 12
14
15
60
63
58
59AIR SUCTION VALVE
56
CATALYTIC CONVERTER 59
54
54
53
51
49
46
45
43
42
41
39
39
37
36
35
STOP LAMP SWITCH
52SIDE STAND
HEADLAMP ADJUSTMENT
ACCESSORIES AND MODIFICATIONS 5
7
10
10
13
SAFETY PRECAUTION 32
MBLXXXXEWYZXYYYYY
MBL
Manufacturer
Code
XXXXEW
Vehicle
Description
Y
Year of
Mfg.
Z
Assembly
Plant
X
Month of
Mfg.
YYYYY
Serial
Number
MBLXXXXEWYZXYYYYY
XXXXEJ
Engine
Description
Y
Year of
Mfg.
Z
Assembly
Plant
X
Month of
Mfg.
YYYYY
Serial
Number
XXXXEJYZXYYYYY
XXXXEJY
ZXYYYYY
Model Engine
VIN
EV
EW
EJ
EJ
Splendor iSmart Electric Start/Drum (Spoke Wheel)
Splendor iSmart Electric Start/Drum (Cast Wheel)
Vehicle Identification Number (VIN)
VIN
VIN
110 kg
8.7 litres
1.8 litres
1965 mm
1095 mm
770 mm
1235 mm
160 mm
0.95 litre
0.80 litre at draining
9.0 :1
NGK-CR7HSA, BOSCH-UR4AC,
Champion-P-RZ9HC (Federal Mogul)
0.6 - 0.7 mm
IN : 0.10 mm EX : 0.10 mm
5.74 kW (7.8 Ps) @ 7500 r/min
97.2 cc
163 ml
Saddle Height 785 mm
ITEM SPECIFICATIONS
PRODUCT SPECIFICATION
Fuel Tank Capacity
r/min
Telescopic Hydraulic Shock Absorbers
Swing Arm with Adjustable Hydraulic Shock Absorber
2.75x18-4 PR/ 80x100-47P (Tyre with Tube/Tubeless Tyre)
2.75x18-6 PR/ 80x100-54P (Tyre with Tube/Tubeless Tyre)
3.722 (67 / 18)
3.071 (43 / 14)
3.181 (35 / 11)
1.706 (29 / 17)
1.238 (26 / 21)
0.958 (23 / 24)
12V-3 Ah **MF Battery
10 A / 15 A
12V 35/35W Trapezoidal Halogen Bulb -MFR*
12V 10W X 4 (Amber Bulb) with clear lens-MFR*
Spoke Wheel / Cast Wheel (optional)
Spoke Wheel / Cast Wheel (optional)
12V 3.0W
Electric Start (i3s Idle Stop Start System)
120 W
5 x 21W MFR*
** MF stands for Maintenance Free
Front Suspension
Trail length
Rear Suspension
Front Wheel
Rear Wheel
Starting System
Turn signal indicator
Tail / Stop Lamp
Headlamp (High/Low)
Meter Illumination
Neutral Indicator
Hi Beam Indicator
i3s Indicator
Battery
Alternator
Turn Signal Lamp
Position Lamp
Side Stand Indicator
ITEM SPECIFICATIONS
12V 1.7W
12V 1.7W
12V 1.7W
W X 2
W X 2
4. Ride defensively and at a steady speed
(between 40-50 km/hr).
2. Always wear a helmet (ISI marked)
with chinstrap securely fastened and
insist on a helmet for your pillion rider.
10. Tightly wrap loose / hanging clothes &
avoid entangling with moving parts.
7. During night time, dip headlamps of
your motorcycle for oncoming traffic,
or when following another vehicle.
11. Get your motorcycle serviced regularly by
the Authorised Hero MotoCorp workshop.
3. While riding, sit in a comfortable posi-
tion with your legs close to fuel tank.
9. To make yourself more visible, wear
bright reflective clothing that fits well.
Do's:
1. Always conduct simple pre-ride
inspections (page no 26).
12. Before riding make sure in which mode
you are riding whether with i3s switch
“ON” or “OFF”.
8. Give way to others on the road and sig-
nal before you make a turn.
5. For stopping motorcycle, use both
brakes simultaneously, keeping throttle
in the close position.
6. Respect road signs and obey traffic
rules for your own safety and that of
others on the road (page nos. 63-64).
motorcycle.
muffler.
SAFE RIDING TIPS
Modifying your motorcycle or using non-
Hero MotoCorp accessories can make
your motorcycle unsafe. Before you
consider making any modifications or
adding an accessory, be sure to read the
following information.
Improper accessories or modifications
can cause a crash in which you can be
seriously hurt or killed.
Follow all instructions in this owner's
manual regarding accessories and
modifications.
• Make sure that the accessory does not
obscure any lamps, reduce ground
clearance, limit suspension travel or
steering travel, affect your riding
position or interfere with operating any
controls.
• Be sure electrical equipment does not
exceed the motorcycle's electrical
system capacity (page 3). A blown fuse
can cause a loss of lights.
Modifications
• Do not pull a trailer or sidecar with
your motorcycle. This motorcycle was
not designed for these attachments,
and their use can seriously impair your
motorcycle's handling.
Removing or modifying your lamps,
mufflers, emission control system or
other equipment can also make your
motorcycle illegal.
We strongly advise you not to remove
any original equipment or modify your
motorcycle in any way that would
change its design or operation. Such
changes could seriously impair your
motorcycle's handling, stability and
braking, making it unsafe to ride.
Accessories
ACCESSORIES & MODIFICATIONS
Regular Servicing: Get your motorcycle serviced at an Authorised Hero MotoCorp
workshop, as per the service schedule, for an optimum performance and keep the
emission level under check.
Genuine Engine Oil: Hero 4T Plus SAE 10W 30 SL grade (JASO MA2) engine oil
recommended by Hero MotoCorp and make sure you change it every 6000 kms.
(with top up every 3000 kilometres) to keep the engine fit and environment healthy.
The following tips shall ensure a healthy motorcycle, healthy environment, and a healthy you.
Genuine Spares: Always insist on Hero MotoCorp genuine parts as spurious or
incompatible spares and accessories can upset or deteriorate your motorcycle’s
running condition.
& fuel efficiency.
Noise Pollution : Noise beyond a certain decibel is pollution. Whether it is from
horns or defective mufflers, excessive noise will cause headaches and discomfort.
Emission Pollution : Get emission of your motorcycle checked by Authorised
agencies atleast once every 3 months or as notified by the government from time to
time.
Fuel Saving & Reduce Pollution : Switch "OFF" the engine while waiting at traffic
signal points to save fuel and reduce pollution, if the waiting period is long.
TIPS FOR HEALTHY ENVIRONMENT
(1) Horn switch
(2) Turn signal switch
(8) Turn signal indicator
(3) Headlamp switch
(7) Rear view mirror
(4) Dimmer switch
(5) Clutch lever
(6) Passing switch
(20) Electric starter switch
steering lock
(23) Leg guard (optional)
(19) Throttle grip
(21) Fuel gauge
(24) Fuel tank cap
(22) Ignition switch with
(18) Front brake lever
(17) i3s switch
14 16
23
22
21
20
24
18
1
2
3
4
5
7
6
1110
8912 15
13 17
19
(16) Tripmeter
(12) Odometer
(9) i3s indicator
(10) Side stand indicator
(13) Trip meter knob
(14) Speedometer
(11) Neutral indicator
(15) High beam indicator
DESCRIPTION
