The AD350 is more than a simple battery discharger. It is a powerful test instrument that
measures, graphs and compares the parameters of various batteries. It allows for the precise
measuring of battery capacity and performance.
No more guesswork when choosing the best battery for your RC activities.
Notice:
As the time of release, (01/2023) the AD350 Discharger only works with the Hitec RDX2 1000 Charger.
Thanks for choosing the Hitec AD350 Analyzer & Discharger.
The AD350 Discharger supports most RC batteries and works with Hitec’s RDX2 1000* Charger
with a discharge current of up to 40A and discharge power of 350W.
* Hitec anticipates this Discharger will work with other Hitec charger models in the future.
Introduction
Explanation of LED Status
Working Voltage:
Discharge Power:
Discharge Current
Over Temp. Protection
Working Temp.:
Working Humidity:
Size (L x W x H)
Net Weight:
DC 5V
350W
0.1-40A
> 95º
32º ~ 104ºF
0% ~ 75%
6.2 x 4.1 x 3.7 in.
43.2 oz.
Specifications
Analyze via the Charge Master PC Software
Part No. 44405
Instruction Manual
Discharge Operation Instructions
1. Connect the power supply to the RDX2 1000 Charger. The main menu screen will
automatically appear.
2. Connect the AD350 Discharger to the RDX2 1000 Charger.
3. Connect the battery to Port A or through the Parallel
connection.
4. Select DISCHARGE to
discharge only. Set the
voltage cut-o in CONDITION
and amperage in CURRENT.
5. To Cycle: Select Balance or
Parallel charging, set Cycle
to 1 or more and select
the Charge and Discharge
Amperage. (20A max in
Balance/35A max in Parallel).
Notice: The Cycle function will always discharge rst and then charge so the pack will be ready to use
when complete. (This is typically used for Stock Racing to lower the internal resistance of the pack to
increase power.)
LED Status
Solid Green Standby
Solid Red Discharging
Flashing Red Error
-1- -2-
PLEASE BE AWARE THAT HIGH AMPERAGE CHARGING AND DISCHARGING
CAN REDUCE THE LIFE OF THE BATTERY.
BEFORE YOU BEGIN CONNECTING YOUR BATTERY, MAKE SURE YOU HAVE
READ AND UNDERSTOOD ALL OF THE WARNINGS AND SAFETY INFORMATION
CONTAINED IN THIS MANUAL.
Warning
Warning
Maximum discharge power chart
-3- -4-
This symbol indicates that when this type of electronic device reaches the end of its service life, it cannot be disposed
of with normal household waste and must be recycled. To nd a recycling center near you, refer to the internet or your
local phone directory for electronic waste recycling centers.
STATE OF CALIFORNIA PROPOSITION 65 WARNING:
This product contains chemicals known to the State of California to cause cancer. Use caution when handling this product and avoid
exposure to any electronic components or internal assemblies.
Battery
Type
No. of
Cells
Min. Cut-off
Voltage Voltage Min. Discharge Current (A)
Discharging power: 350W
Max. Discharge Current (A)
Discharging power: 350W
LiPo 2S 68.4 40 40
3S 912.6 27.77 38.88
4S 12 16.8 20.83 29.16
5S 15 21 16.66 23.33
6S 18 25.2 13.88 19.44
7S 21 29.4 11.9 16.66
8S 24 33.6 10.41 14.58
LiHV 2S 6.2 8.7 40 40
3S 9.3 13.05 26.81 37.63
4S 12.4 17.4 20.11 28.22
5S 15.5 21.75 16.09 22.58
6S 18.6 26.1 13.4 18.81
7S 21.7 30.45 11.49 16.12
8S 24.8 34.8 10.05 14.11
NiMH 6S 5.4 938.88 40
7S 6.3 10.5 33.33 40
8S 7.2 12 29.16 40
9S 8.1 13.5 25.92 40
10S 915 23.33 38.88
11S 9.9 16.5 21.21 35.35
12S 10.8 18 19.44 32.4
13S 11.7 19.5 17.94 29.91
14S 12.6 21 16.66 27.77
15S 13.5 22.5 15.55 25.92
16S 14.4 24 14.58 24.3
17S 15.3 25.5 13.72 22.87
18S 16.2 27 12.96 21.6
19S 17.1 28.5 12.28 20.46
20S 18 30 11.66 19.44
LIABILITY EXCLUSION
This discharger is designed and approved exclusively for use with the types of batteries stated in this Instruction Manual. Hitec RCD USA
accepts no liability of any kind if the discharger is used for any purpose other than that stated.We are unable to ensure that you follow the
instructions supplied with the discharger, and we have no control over the methods you employ for using, operating and maintaining the
device. For this reason, we are obliged to deny all liability for loss, damage or costs which are incurred due to any misuse or operation of our
products. Unless otherwise prescribed by law, our obligation to pay compensation, regardless of the legal argument employed, is limited to
the invoice value of Hitec RCD USA products which were immediately and directly involved in the event in which the damage occurred.
ONE YEAR LIMITED WARRANTY
For a period of one year from the date of purchase, HITEC RCD USA shall REPAIR OR REPLACE, at our option, defective equipment covered by
this warranty. Otherwise, the purchaser and/or consumer is responsible for any charges for the repair or replacement of the discharger.This
warranty does not cover cosmetic damages and damages due to acts of God, accident, misuse, abuse, negligence, improper installation, or
damages caused by alterations by unauthorized persons or entities.This warranty only applies to the original purchaser of this product and
for products purchased and used in the United States of America, Canada and Mexico. Plastic cases are not covered by this warranty.
THISWARRANTY IS IN LIEU OF ANY AND ALL OTHERWARRANTIES, WHETHER FOR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE
ANDWHETHER EXPRESS OR IMPLIED. REPAIR OR REPLACEMENT AS PROVIDED UNDERTHISWARRANTY IS THE EXCLUSIVE REMEDY. HITEC
RCD USA SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIEDWARRANTY
RELATINGTOTHIS PRODUCT, EXCEPTTO THE EXTENT PROHIBITED BY APPLICABLE LAW. ANY IMPLIEDWARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE ONTHIS PRODUCT IS LIMITEDTOTHE DURATION OF THISWARRANTY, REPAIR AND SERVICE.
SERVICE AND REPAIR INFORMATION -To have your Hitec discharger serviced:
1. Visit the Hitec website at www.hitecrcd.com and download the service request form.
2. Fill out the service request form completely and include a copy of your original receipt showing the purchase date.
3. Package your product in its original packaging or use a suspension-type packaging (foam peanuts or crumpled newspaper).
Hitec RCD USA shall not be responsible for goods damaged in transit.
4. Ship prepaid (COD or postage-due returns will not be accepted) via a traceable common courier (UPS, insured parcel post, FedEx, etc.) to:
Hitec RCD USA / Customer Service Center, 9320 Hazard Way, Suite D. San Diego, CA 92123
Warranty, Service and Repair
FAILURE TO FOLLOW THESE EXPLICIT WARNINGS CAN RESULT IN PROPERTY DAMAGE, PHYSICAL
INJURY AND/OR LOSS OF LIFE.
! Never discharge a battery below its recommended cuto voltage. Over-discharge may damage battery and cause FIRE or EXPLOSION.
! Never discharge a battery at a higher discharge rate than it is designed for.
! Never leave the discharger unattended when it is connected to battery. If any malfunction is found,TERMINATETHE PROCESS AT ONCE
! Place the discharger and battery on a non-ammable surface, and keep away from ammable materials.
! Never discharge swollen, leaky, or damaged batteries.
! Batteries shall be discharged within a room temperature range of 50º ~104º F.
! Disconnect the battery and discharger once discharging has nished.
! Recharge batteries immediately with an appropriate battery charger after discharge process is completed.
! Some battery types should not be discharged for extended periods of time.
Warnings and Safety Notes
Distributed by: Hitec RCD USA | 9320 Hazard Way Ste D, San Diego, CA 92123 | (858)748-6948 | www.hitecrcd.com
This manual is subject to change without notice.
Please refer to the Hitec RCD USA website for the latest version.
Made In China
Note
THE AD350 DISCHARGER WARRANTY IS VOID IF SOLD AND/OR OPERATED OUTSIDE THE UNITED STATES.
