Etherlink IIIB ISA Network Interface

Card (10BT)

3C509B-TP

Installation Guide

Notice

The information contained in this document is subject to change without notice.

Hewlett-Packard makes no warranty of any kind with regard to this material,

including, but not limited to, the implied warranties of merchantability and

fitness for a particular purpose.

Hewlett-Packard shall not be liable for errors contained herein or for incidental

or consequential damages in connection with the furnishing, performance, or use

of this material.

Hewlett-Packard assumes no responsibility for the use or reliability of its

software on equipment that is not furnished by Hewlett-Packard.

This document contains proprietary information that is protected by copyright.

All rights are reserved. No part of this document may be photocopied,

reproduced, or translated to another language without the prior written consent

of Hewlett-Packard Company.

Microsoft®, Windows® and MS-DOS® are registered trademarks of Microsoft

Corporation.

MMXTM is a trademark of Intel Corporation.

Pentium® is a registered trademark of Intel Corporation.

Hewlett-Packard France

Commercial Desktop Computing Division

38053 Grenoble Cedex 9

France

1 Connecting to a Netware 3.12 Server

Windows for Workgroups

1 Connecting to a Netware 3.12 Server

Windows for

Workgroups

Requirements

• HP Vectra with DOS and MS-Windows for Workgroups 3.11 installed.

• 3COM Etherlink 3C509-B ethernet card and drivers disk ver. 5.0.

DOS ODI - File Name: 3C5X9.COM Size: 42KB Date: 7/21/96

• DOS and MS-Windows for Workgroups 3.11 media.

• Novell Netware server 3.12 that supports Net BEUI, NWLink IPX/SPX,

and NWLink NetBIOS transfer protocols.

• Netware client for DOS and MS-Windows.

Device Configuration

• I/O Base Address 300

• Interrupt Request Level 10

• Boot PROM Disabled

• Transceiver Type Auto Select

• Network Driver Optimization Windows or OS/2 Client

• Maximum Modem Speed 9600 Baud

• Plug and Play Compatibility Disabled

• Full Duplex Disabled

Procedure

1With the HP Vectra turned off install the 3COM Etherlink III 3C509-B

adapter card into an ISA slot.

2Power on the machine and allow it to boot to a DOS prompt.

3Insert the 3COM drivers diskette (ver. 5.0 downloaded from 3COM’s

website) and execute 3C5X9CFG.EXE.

4Select “CONFIGURE NIC,” and verify the resource settings listed above

under the heading “Device Configuration.”

5If changes are required, save those changes and exit.

1 Connecting to a Netware 3.12 Server

Windows for Workgroups

6Remove the 3com cards driver diskette and insert Netware client for DOS

and MS-Windows disk 1.

7Execute INSTALL.EXE and set lines 1-5 as listed below;

8C:\NWCLIENT

9YES

10 YES

C:\WINDOWS

11 NO

12 3COM Etherlink III Parallel Tasking Family.

13 Highlight option 6 to continue with installation.

14 When prompted, insert the corresponding disks to complete file transfer

and driver installation.

15 When the install utility is finished, press <CRTL><ALT><DEL> to restart

the machine.

16 After windows loads, open the “NETWORK” folder, double-click the

“NETWORK SETUP” icon.

17 Select “Networks”, and verify that “Novell Netware (Workstation Shell 4.0

and above)” is listed under “Install Windows support for the following

network only:” and click on “OK.”

1 Connecting to a Netware 3.12 Server

Windows 95 SR2

Windows 95 SR2 Requirements

• HP Vectra with Windows 95 SR2 installed.

• 3COM Etherlink 3C509-B ethernet card and drivers disk ver. 5.0.

File Name: Elnk3.VXD Size: 30KB Date: 7/18/96

• Windows 95 SR2 media.

• Novell Netrware 3.12 server that supports Net BEUI, NWLink IPX/SPX,

and NWLink NetBIOS transfer protocols.

Device Configuration

• I/O Base Address 300

• Interrupt Request Level 10

• Boot PROM Disabled

• Transceiver Type Auto Select

• Network Driver Optimization Windows or OS/2 Client

• Maximum Modem Speed 9600 Baud

• Plug and Play Compatibility Disabled

• Full Duplex Disabled

Procedure

1With the HP Vectra turned off install the 3COM Etherlink III 3C509-B

adapter card into an ISA slot.

2Power on the machine and restart Windows 95 SR2 in MS-DOS Mode.

3Insert the 3COM drivers diskette (ver. 5.0 downloaded from 3COM’s

website) and execute 3C5X9CFG.EXE.

4Select “CONFIGURE NIC,” and verify the resource settings listed above

under the heading “Device Configuration.”

5If changes are required, save those changes and exit.

6Remove the 3com cards driver diskette and restart the machine.

7After windows loads, click on “Start,” to “Settings” and over to “Control

Panel.”

8Double click on “Network” and select “Add.”

1 Connecting to a Netware 3.12 Server

Windows 95 SR2

9Choose to add an adapter, click on “Add” then on “Have Disk.”

10 Insert the 3C509B drivers diskette and set path to “A:\” and hit enter. (If

you have a Hewlett-Packard pre-loaded HDD, set the path statement to

“C:\LANDRV\3C509B\WIN95\”)

11 High light the adapter labeled “3Com Etherlink III ISA (3C509/3C509B) in

ISA Mode” and press “OK.”

12 At the “Network” dialogue box, click on the “Identification” folder.

13 Enter your “Computer Name,” “Workgroup,” and “Computer

Description.” (If you do not have a Computer name, Workgroup name and

Computer description, contact your network administrator)

14 Approve the “Basic Configuration Resources” by clicking on “OK.”

15 When prompted, set the path to your Windows 95 SR2 files and click on

“OK.”

16 Click on “YES” to complete installation and restart the machine.

2 Connecting to a Netware 4.11 Server

Windows for Workgroups

2 Connecting to a Netware 4.11 Server

Windows for

Workgroups

Requirements

• HP Vectra with DOS and MS-Windows for Workgroups 3.11 installed.

• 3COM Etherlink 3C509-B ethernet card and drivers disk ver. 5.0.

DOS ODI - File Name: 3C5X9.COM Size: 42KB Date: 7/21/96

• DOS and MS-Windows for Workgroups 3.11 media.

• Novell Netware server 4.11 that supports Net BEUI, NWLink IPX/SPX,

and NWLink NetBIOS transfer protocols.

• Netware client for DOS and MS-Windows.

Device Configuration

• I/O Base Address 300

• Interrupt Request Level 10

• Boot PROM Disabled

• Transceiver Type Auto Select

• Network Driver Optimization Windows or OS/2 Client

• Maximum Modem Speed 9600 Baud

• Plug and Play Compatibility Disabled

• Full Duplex Disabled

Procedure

1With the HP Vectra turned off install the 3COM Etherlink III 3C509-B

adapter card into an ISA slot.

2Power on the machine and allow it to boot to a DOS prompt.

3Insert the 3COM drivers diskette (ver. 5.0 downloaded from 3COM’s

website) and execute 3C5X9CFG.EXE.

4Select “CONFIGURE NIC,” and verify the resource settings listed above

under the heading “Device Configuration.”

5If changes are required, save those changes and exit.

2 Connecting to a Netware 4.11 Server

Windows for Workgroups

6Remove the 3com cards driver diskette and insert Netware client for DOS

and MS-Windows disk 1.

7Execute INSTALL.EXE and set lines 1-5 as listed below;

8C:\NWCLIENT

9YES

10 YES

C:\WINDOWS

11 NO

12 3COM Etherlink III Parallel Tasking Family.

13 Highlight option 6 to continue with installation.

14 When prompted, insert the corresponding disks to complete file transfer

and driver installation.

15 When the install utility is finished, press <CRTL><ALT><DEL> to restart

the machine.

16 After windows loads, open the “NETWORK” folder, double-click the

“NETWORK SETUP” icon.

17 Select “Networks”, and verify that “Novell Netware (Workstation Shell 4.0

and above)” is listed under “Install Windows support for the following

network only:” and click on “OK.”

2 Connecting to a Netware 4.11 Server

Windows 95 SR2

Windows 95 SR2 Requirements

• HP Vectra with Windows 95 SR2 installed.

• 3COM Etherlink 3C509-B ethernet card and drivers disk ver. 5.0.

File Name: Elnk3.VXD Size: 30KB Date: 7/18/96

• Windows 95 SR2 media.

• Novell Netrware 4.11 server that supports Net BEUI, NWLink IPX/SPX,

and NWLink NetBIOS transfer protocols.

Device Configuration

• I/O Base Address 300

• Interrupt Request Level 10

• Boot PROM Disabled

• Transceiver Type Auto Select

• Network Driver Optimization Windows or OS/2 Client

• Maximum Modem Speed 9600 Baud

• Plug and Play Compatibility Disabled

• Full Duplex Disabled

Procedure

1With the HP Vectra turned off install the 3COM Etherlink III 3C509-B

adapter card into an ISA slot.

2Power on the machine and restart Windows 95 SR2 in MS-DOS Mode.

3Insert the 3COM drivers diskette (ver. 5.0 downloaded from 3COM’s

website) and execute 3C5X9CFG.EXE.

4Select “CONFIGURE NIC,” and verify the resource settings listed above

under the heading “Device Configuration.”

5If changes are required, save those changes and exit.

6Remove the 3com cards driver diskette and restart the machine.

7After windows loads, click on “Start,” to “Settings” and over to “Control

Panel.”

8Double click on “Network” and select “Add.”

2 Connecting to a Netware 4.11 Server

Windows 95 SR2

9Choose to add an adapter, click on “Add” then on “Have Disk.”

10 Insert the 3C509B drivers diskette and set path to “A:\” and hit enter. (If

you have a Hewlett-Packard pre-loaded HDD, set the path statement to

“C:\LANDRV\3C509B\WIN95\”)

11 High light the adapter labeled “3Com Etherlink III ISA (3C509/3C509B) in

ISA Mode” and press “OK.”

12 At the “Network” dialogue box, click on the “Identification” folder.

13 Enter your “Computer Name,” “Workgroup,” and “Computer

Description.” (If you do not have a Computer name, Workgroup name and

Computer description, contact your network administrator)

14 Approve the “Basic Configuration Resources” by clicking on “OK.”

15 When prompted, set the path to your Windows 95 SR2 files and click on

“OK.”

16 Click on “YES” to complete installation and restart the machine.
