SmartAX®MA5200F-2000 Broadband IP Access Equipment Product Specification

http://www.huawei.com/products/datacomm/

SmartAX®MA5200F-2000 Broadband IP Access

Equipment Prodcut Specification

Attribute MA5200F-2000

Architecture Box Type

Dimension

(W×D×H)

482.6mm × 381mm × 88.9mm

Backplane capacity ≥10Gbps

Switching capacity Shared cache switching network with the switching capacity of

10Gbps

Forwarding capacity 3Mpps (2GE wire-speed forwarding)

Slot number on the

interface board 1 GE slot, 4 FE slot

Interface type GE interface

FE interface

OC-3/STM-1 POS interface

Routing protocol Support such routing protocols as RIP, OSPF and BGP-4 etc.

QoS Provide complete QoS support based on DiffServ.

Support bandwidth control for each subscriber and WRED

congestion avoidance algorithm.

Multicast Support IGMP, static multicast configuration, PIM-DM/SM

multicast protocols.

Support interoperability of multiple multicast protocols.

Support multicast policy processing, including multicast routing

protocols and multicast forwarding policies.

Support QoS control for multicast.

Reliability All components support hot swap, and power supply 1+1

redundancy.

Number of concurrent

users 2K

Number of VLAN

termination 8K

Supported protocols PPPoE, DHCP/DHCP Relay, DHCP Option 60&82, L2TP LAC,

RADIUS and SNMP

SmartAX®MA5200F-2000 Broadband IP Access Equipment Product Specification

http://www.huawei.com/products/datacomm/

Attribute MA5200F-2000

Security Provide authentication, resource protection, attack shielding and

address anti-counterfeit functions.

IP+MAC+VLAN ID binding, protect the customers against IP

spoofing attack.

Starting from 64K, limit user’s bandwidth by CAR with the step of

8K.

NM Adopt Huawei iManager and Quidview NM platforms as the

framework. Support SNMP and the Client/Server architecture.

Run independently on UNIX (SUN, HP) or ORACLE/SYBASE, or

be nested into the existing NM platform such as HP OpenView.

Provide dynamic topology management, fault management,

performance management, configuration tools, log management,

operation monitoring, security and user management.

Provide VPN management, QoS policy management and other

service management functions.

Provide an optional offline flow engineering tool.

Support multiple languages.

North-bound Interface for 3rd-party APP and Service Provisioning

system

Input power supply DC: -36V to -72V / AC (110V/220V): 90V to 264V

Full-load power

consumption Below 60W

Full-configuration

weight Below 10kg

Mean Time Between

Failures (MTBF) =15 years

Environmental

requirement

Long-term working temperature: 0 to 45°C

Short-term working temperature: -5to 55°C

Storage temperature: -30 °C to 60 °C

Relative humidity: 10% to 90%

Altitude: below 4000m
