Huawei InZone E960 Manuale utente
Thank you for choosing Optus Wireless
This guide is here to help you set-up your Optus Wireless service.
Contents
About the InZone E960 device 3
6 Step set-up guide 4
Setting up your Optus Member Services Account 7
Setting up an Optus Wireless Broadband Username 7
Optus Member Services – Checking your usage 8
My Usage 9
Optus Email – Webmail 9
Conguring your email 10
• Outlook Express 10
• Outlook 2003 11
• Outlook 2007 11
• Windows Vista 12
• Apple Mac 12
Setting up a WiFi Network (WLAN) 13
How to access WiFi 21
• Windows XP 21
• Windows Vista 21
• Apple Mac 22
Accessing the InZone E960 online User Guide or Online Help 22
Using the Optus Wireless Telephone service 23
• How to obtain your telephone number 23
• General tips 23
• Using Optus Voicemail 23
• Call Waiting 24
• Call Forwarding 25
• Transferring your existing number to Optus 25
• Telephone quick reference guide 26
Troubleshooting 27
What do the indicator lights on the InZone E960 mean? 28
Things you must know about this service 29
Safety Precautions 30
Optus Statement on Customer Service Standards 31
About the InZone E960 device
Phone Cable Connection
Ethernet Cable Connections
Power Adapter Connection
Pedestal
Network Mode Indicator
Signal Strength Indicator
Power Button (ON/OFF key)
WiFi (WLAN) Indicator
Power Indicator
SIM Card Cradle
Reset Button
:
• The InZone E960
• Pedestal
• An Ethernet Cable (Grey)
• A Power Adapter (white)
• User Guide
• 6 Step set-up guide
The InZone E960 uses the Optus Mobile 3G/HSPA (2100MHz) network to deliver your
wireless service.
6 Step set-up guide
The signal light may blink when connecting to the network. If the signal light is red,
your service is not active.
Service activation takes up to 24 hrs from receipt of the device.
Within 24 hours your Home or Business phone number will be allocated, after this
time call from your device to nd out your number.
Remove Telephone Cable from wall
socket.
Plug your Telephone Cable into the
telephone socket on the InZone device.
Your Telephone is now connected
to the InZone device and ready
to make phone calls.
Open your internet browser and enter into the
address eld and hit For your convenience, add to your favorites or bookmark.
Remember, excess usage charges apply once you reach your monthly data
allowance.
• When dialling a number, you will experience a slight delay before you hear the
ringing tone; this is normal for this type of service. To reduce this delay, press
after you have dialled the number.
• To set-up and access WiFi – refer to page 13.
• To port your existing telephone number – refer to page 25.
• Things you must know about this service – refer to page 29.
Congratulations!
You are now set-up to browse the Internet on your Optus Wireless Broadband service
and make calls if you have chosen Optus Wireless Fusion.
, Optus Fusion customers will be able to use the Internet and make telephone
calls straight away, but these will appear as calls made from a mobile number until your
home or business number has been assigned. This may take up to 24 hours.
Read on to nd out how to:
• Set-up an Optus Username and email account
• Access Member Services including the Internet Usage Meter
• Set-up a wireless home network (WiFi)
• Use your Wireless Telephone service
• Troubleshoot
• Use your service safely
Setting up your Optus Member Services Account
Member Services provides you access to a number of service features including:
• An Internet Usage Meter, so you can manage your usage
• An Optus email account
• The ability to personalise the Optus myZOO portal
• The Optus Internet Security Suite
To access these features you will need an Optus Wireless Broadband Username.
With your InZone E960 connected to the Internet, type the below web address into the
address eld of your web browser:
: You can only access the set-up page when you are connected to the Internet via your wireless device.
Follow the online instructions and enter a Username and Password into the elds as
indicated, then click The Username you select will be used as part of your email
address and will allow you to access Member Services.
We have provided a section at the back of this guide for you to record your Username,
Password and email address.
Member Services, allows you to keep track of your usage (via My Usage), access to
Webmail (via Web Services) and download the Optus Internet Security Suite.
To access Member Services go to click on
and then click on .
The page allows you to manage your usage during your billing month.
To access the page, go to the Member Services section of the myZOO portal,
using your Username and Password, sign into Member Services. Then click on
My Usage will display usage in megabytes (MB), however your usage will be counted
in kilobytes (KB) i.e. 1MB = 1024KB and includes both uploads and downloads.
As mentioned in the 6 Step set-up guide, you can also check your usageat
when using your device.
Your Optus bill will show your actual usage during the billing period.
Optus Email - Webmail
You can check your email online by simply accessing Optus Webmail via the myZOO
Homepage. You can also access Optus Webmail by typing the below web address into the
address eld of your web browser:
Simply enter your and your to send and receive email. You
can access this from any Internet connection.
Conguring your email
If you would like to set-up your email program, here are the steps and settings you’ll need:
In Outlook Express, click on the menu and select .
Click the and select
Enter the Display Name you would like to be displayed to others when you send
them an email, then click .
Enter the email address you created when you activated your broadband service,
then click
On the E-Mail Server Names screen, enter the following settings and click :
a. My incoming mail server is a:
b. Incoming Mail Server:
c. Outgoing Mail Server:
In the Internet Mail Logon screen section, enter the following settings and click
a. Enter your Account Name (your Member Services Username).
b. Enter the Password (your Member Services Password) you specied when you
created the email address.
c. Leave ticked,
un-ticked and click .
Click to complete your mailbox setup.
