Introduction Huma-i white (HI-100)
Main functions
①
②
③
④
⑥
⑤
Thank you for purchasing our products.
Huma-i white (HI-100) model is a portable air quality monitor for
particulate matter in real time. In-house designed built-in fine dust
sensor module allows you to measure ultra-fine dust(PM2.5) and
fine dust(PM10) at the same time.
You can check the air quality around you anytime and anywhere
with Huma-i.
① Power and mode selection button
- Power button
If you press the button for 1 second, it will be in power-on state.
It automatically switches to power-off state when not in use for
10 minutes to protect battery life.
The status LED will blink 1 minute before automatic power-off.
At this time, if you press the button lightly, it will be switched on
again for 10 minutes, and the mode will not change.
- Mode selection button
Each time you press the mode select button, the display mode
changes cyclically in the following order.
The status LED lets you know the status of ultra-fine dust and
fine dust.
② Status LED
WHO Mode => Single Display Mode (PM2.5)
=> Dual Display Mode (PM2.5 & PM10)
Unit of measure
μg/㎥
(WHO
Guideline)
ultra-fine dust
fine dust
Good
0~15
0~30
Moderate
16~25
31~50
Poor
26~35
51~70
Unhealthy
36~
71~
③ Icon indicating fine dust concentration
4 kinds of icons, which indicate fine dust concentration, will
help you to catch out easily fine dust concentration.
④Battery status indicator
Icon shows remaining battery status.
⑤Display mode
WHO Mode (Icon Mode): You can easily recognize the good
and poor state of fine dust by 4 kinds of icons.
In this mode, it automatically displays the worst between PM2.5
and PM10.
Single Display Mode: This mode displays PM2.5 measurement
values.
Dual Display Mode: Simultaneously displays PM2.5 and PM10
measurement values in one screen.
⑥Fine dust / ultra-fine dust density indication
Displays the concentration of fine dust (PM10) and ultra-fine
dust (PM2.5).
Red : Unhealthy air quality.Yellow : Poor air quality.
Green : Moderate air quality.Blue : Good air quality.
65
Specifications
Product
Portable Air Quality Monitor
HI-100
Measurement range: 0~500㎍/㎥ (PM2.5/PM10)
Resolution: 1 ㎍/㎥
Li-Polymer Battery
USB micro 5 Pin
91 X 41 X 37mm (3.6 X 1.6 X 1.5 inches)
60g (0.13 pound)
CE FCC KC
Model No.
PM
Power Supply
Charge Mode
Dimension
Weight
Certification
1. This device is a product that measures in real time while carrying
when air quality measurement is needed.
The OLED display has good visibility, but if it is turned on
continuously, a burn-in phenomenon may occur, so it is not
recommended to use it continuously unless it is absolutely
necessary.
2. Do not expose to direct sunlight or subject it to high
temperature and high humidity.
It may change appearance or cause malfunction.
3. Do not use for long periods in high concentration fine dust
environment.
Note that the measurement may not be smooth.
4. Do not disassemble the product if you’re not an authorized
engineer and/or a technician.
The disassembled products without authorization are out of
warranty in any case.
5. Do not allow drinks or water to enter the product.
It may cause malfunction, electric shock or fire.
6. This product may cause errors depending on the environment
(temperature, humidity, wind) and usage.
7. The measured values of this product are for personal use only
and are not responsible for the manufacturer and the seller.
Limited Warranty
MADE IN KOREA V.2.0
