M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：1

M2M‐720‐A



FAQ

Version1.20

M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：2

Contents

Q1: PWR LED indication of M2M-720-A is always turned off…………. 3

Q2: SA1 and SA2 of M2M-720-A is always turned on………………….. 3

Q3: SA1 and SA2 LED of M2M-720-A flash slowly at the same time and

keep the state long…………………………………………………………3

Q4: The audio quality of M2M-720-A is bad……………………………..3

Q5: M2M-720-A can’t send event report………………………………… 3

Q6: If I forgot the network settings, how can I do?.................................... 3

Q7. I can’t open the webpage of the M2M-720-A……………………….10

Q8. Client can’t connect to Server……………………………………….11

Q9: Server and Client can’t establish Com Port connection……………..16

Q10: How to establish an ETM connection?..............................................19

M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：3

FAQ

Q1: PWR LED indication of M2M-720-A is always turned off

A1: The power supply of M2M-720-A has some problems. Please check

the wire connection of the power and the voltage is between 10~30 VDC

Q2: SA1 and SA2 of M2M-720-A is always turned on

A2: Application program has some errors. Please reset the M2M-720-A

and check license whether it is OK or not in “information” page.

Client: Please check server’s DNS and network settings whether they

are all correct or not in “Standard Config” page.

Q3: SA1 and SA2 LED of M2M-720-A flash slowly at the same time and

keep the state long.

A3: It means M2M-720-A can’t establish the connection with the other

M2M-720-A. Please check the network settings and M2M-720-A is

working well on Ethernet.

Client: Please check server’s IP/DNS and network settings whether

they are all correct or not in “Standard Config” page.

Q4: The audio quality of M2M-720-A is bad.

A4: Please turn audio quality output volume and input volume of server

and client in “Audio Config” page.

Q5: M2M-720-A can’t send event report

A5: Please check the settings whether they are all correct or not in “Event

Report” and “Mail Server Setting” page.

Q6: If I forgot the network settings, how can I do?

A6:

[One solution]

a. If the M2M-720-A is in a local network.

The user can use the VxComm Utility or MiniOS7 Utility to

M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：4

scan the network settings of the M2M-720-A.

About VxComm Utility =>

1. please refer to

http://www.icpdas.com/products/Software/VxComm/vxcom

m.htm

2. The user can click “Search Servers” button to start the scan

function.

About MiniOS7 Utility =>

1. please refer to http://www.icpdas.com/download/minios7.htm

2. The user can click “Search” button to start the scan function.

M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：5

b. If the M2M-720-A has a real IP and has an internet connection.

The user can print current network settings by Com Port (RS-

232).

Step1: Connect PC and the M2M-720-A by RS-232 cable.

M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：6

Step2: Open Com Port program. We used “Hyper Terminal” of

Microsoft Window XP to test here.

Step3: Set communication setting of Com Port. (Baud rate =

115200, data bits=8, parity=none, stop bits=1, flow

control=none).

M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：7

Step4: Press Call icon.

Step5: Set SW1=OFF, SW2=OFF.

Step6: Press the Trigger Button about 40 second after power on.

Step7: It will show M2M-720-A’s IP in “Hyper Terminal”(ex:

IP Address = 192.168.0.211).

M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：8

[Another solution]

The user can recover the default network settings by DIP Switch and

Trigger button (ex: SW2= ON, SW1= OFF and press the TB about 40

second after power on).

M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：9

Dip switch and trigger button function

Option State Description

Recover default

setting forever

SW2=ON

SW1=ON

To press the TB about 40

second after power on

All system settings will be cleared and

recover default settings.

(Warning: it will not restore settings

after clear)

IP recover default

setting for this

time

SW2= OFF

SW1= ON

To press the TB about 40

second after power on

After power on, it will set IP to default

setting (192.168.1.217) for this time,

but it will restore original IP at next

time.

IP recover default

setting forever

SW2= ON

SW1= OFF

To press the TB about 40

second after power on

After power on, it will set IP to default

setting (192.168.1.217) and save to

flash.

Display the

current IP and

version

SW2=OFF

SW1=OFF

To press the TB about 40

second after power on

After power on, it will display the

message about current IP and version

information from Com Port(RS-232).

Normal setting The other states Normal state; It will not change any

setting and data.

M2M-720-A FAQ (Version 1.20, Oct/2012) PAGE：10

Q7. I can’t open the webpage of the M2M-720-A.

A7.

Step1: Please confirm the network settings of the M2M-720-A. (The

user can refer to “Q6. If I forgot the network settings, how can I

do?”)

Step2: Confirm the network settings of the PC have the same domain

and different IP with the M2M-720-A.

Ex1=>

M2M-720-A: IP-192.168.1.217, Mask-255.255.255.0

PC: IP-192.168.0.210, Mask-255.255.255.0 (Wrong settings)

Ex2=>

M2M-720-A: IP-192.168.1.217, Mask-255.255.255.0

PC: IP-192.168.1.210, Mask-255.255.255.0 (Right settings)

Ex3=>

M2M-720-A: IP-192.168.1.217, Mask-255.255.0.0

PC: IP-192.168.0.210, Mask-255.255.0.0 (Right settings)
