Intel Atom Pine Trail-D525 Manuale utente

User’s Manual

Manual revision: 1.0

Release Date：January, 2011

USER’S NOTICE

INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT MAY BE REPRODUCED, TRANSMITTED

OR TRANSLATED INTO ANY LANGUAGE IN ANY FORM OR BY ANY MEANS WITHOUT WRITTEN

PERMISSION OF THE MANUFACTURER.

THIS MANUAL CONTAINS ALL INFORMATION REQUIRED TO USE THIS MOTHER-BOARD SERIESANDWE

DO ASSURE THIS MANUAL MEETS USER’S REQUIREMENT BUT WILL CHANGE, CORRECT ANY TIME

WITHOUT NOTICE. MANUFACTURER PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY

KIND, AND WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTIAL OR CONSEQUENTIAL

DAMAGES (INCLUDING DAMANGES FOR LOSS OF PROFIT, LOSS OF BUSINESS, LOSS OF USE OF DATA,

INTERRUPTION OF BUSINESS AND THE LIKE).

PRODUCTS AND CORPORATE NAMES APPEARING IN THIS MANUAL MAY OR MAY NOT BE

REGISTERED TRADEMARKS OR COPYRIGHTS OF THEIR RESPECTIVE COMPANIES, AND THEY ARE

USED ONLY FOR IDENTIFICATION OR EXPLANATION AND TO THE OWNER’S BENEFIT, WITHOUT

INTENT TO INFRINGE.

Environmental Protection Announcement

Do not dispose this electronic device into the trash while discarding. To minimize

pollution and ensure environment protection of mother earth, please recycle.

Environmental Safety Instruction

lAvoid the dusty, humidity and temperature extremes. Do not place the product in

any area where it may become wet.

l0 to 60 centigrade is the suitable temperature. (The figure comes from the request

of the main chipset)

lGenerally speaking, dramatic changes in temperature may lead to contact

malfunction and crackles due to constant thermal expansion and contraction from

the welding spots’ that connect components and PCB. Computer should go

through an adaptive phase before it boots when it is moved from a cold

environment to a warmer one to avoid condensation phenomenon. These water

drops attached on PCB or the surface of the components can bring about

phenomena as minor as computer instability resulted from corrosion and oxidation

from components and PCB or as major as short circuit that can burn the

components. Suggest starting the computer until the temperature goes up.

lThe increasing temperature of the capacitor may decrease the life of computer.

Using the close case may decrease the life of other device because the higher

temperature in the inner of the case.

lAttention to the heat sink when you over-clocking. The higher temperature may

decrease the life of the device and burned the capacitor.

iii

USER’S NOTICE.................................................................................................................. i

ENVIRONMENTAL PROTECTION ANOUNCEMENT...........................................................i

ENVIRONMENTAL SAFETY INSTRUCTION ....................................................................... ii

1 FEATURE OF MOTHERBOARD............................................................................ 1

2 SPECIFICATION .................................................................................................... 2

3 LAYOUT DIAGRAM ...............................................................................................3

3-1 INTERNAL DIAGRAM OF THE BOARD ......................................................3

3-2 THE BACK SIDE OF THE BOARD...............................................................4

3-3 REAR PANEL I/O CONNECTORS............................................................... 5

3-4 FRONT PANEL I/O CONNECTORS.............................................................5

4 I/O CONNECTOR FUNCTION................................................................................6

4-1 REAR I/O CONNECTOR FUNCTION............................................................. 6

4-2 FRONT I/O CONNECTOR FUNCTION........................................................... 7

TABLE OF CONTENT

1. Feature of Motherboard

lINTEL® Atom Pine Trail-D525 + NM10 chipset

lOnboard Atom CPU, with low power consumption never denies high performance.

lSupport DDRIII DIMM800 up to 4GB

lOnboard Gigabit LAN Chip

lSupport 2-CH Audio

lSupport USB 2.0 data transport demands

lCompliance with ERP(Energy Using Product) standard

lMini-ITX form factor(170mm x 182mm)

2. Specification

CPU

INTEL® Atom Pine Trail-D525

Clock:1.83GHz

Chipset

/ GPU

INTEL® Atom Pine Trail-D525 + NM10 chipset

NVIDIA® ION2(GT218) GPU

Front Side Bus:200 MHz

Memory

(Optional)

2 * SO-DIMMs Sockets for DDRIII 800 up to 4 GB

Ethernet LAN

Realtek Gigabit LAN Chip

Expansion S

lots

1 * PCI Express Mini Card slot

Storage

1 * Serial ATA II 3Gb/s connectors

Audio

2-CH Audio

BIOS

AMI 8MB flash ROM

Front

Panel I

2 * USB 2.0/1.1 ports

1 * Power button

1 * card reader (SDC/MMC/MS)

1 * Mic and headphone

1 * Power LED

Rear Panel

2 * USB 2.0 ports

1 * LAN port

1 * Antenna Hole

1 * HDMI port & 1 * DVI-I port

1 * Power connector

1 * e-SATA port

Power

1*12V DC-in

Form Factor

Mini-ITX Form Factor (170mm x 182mm)

Certificate

CE,FCC for barebone

CE,FCC,TUV,UL,CCC,CB for power adapter

Comply with ERP stardards

3. Layout Diagram

3-1 Internal Diagram of the Board

3-2 The Back Side of the Board:

3-3 Rear Panel I/O Connectors

3-4 Front Panel I/O Connectors

Card Reader Slot

USB Connectors

Line-out /Optical SPDIF out

shared connector

MIC

Power

Switch

/Power LED

mote Sensor

Antenna Hole

HDMI

Connector

DVI

Connector

E-SATA/USB

Connector

RJ-

45 LAN

USB Connectors

DC12V Jack

4. I/O Connector Function

4-1 Rear Panel I/O Connector Function

USB Connector:

There are 3*USB connectors on rear IO panel (one is USB/E-SATA shared connector that functions

according to device connected) to connect USB mouse, keyboard and other USB storage devices to

the system.

RJ-45 Connector:

The connector is standard RJ-45 connector for network. Please connect to the network cable to this

connector.

USB/E-SATA Shared Connector:

The function of this connector depends on different devices connected to this connector through

different cable.

It could function as:

nE-SATA connector when a compatible ESATA hard disk is connected to it through SATA cable.

nUSB connector when a compatible USB device is connected to it through USB cable.

DVI (Digital Visual Interface) Connector:

This interface standard designed to maximize the visual quality of digital display devices such as flat

panel LCD computer displays and digital projectors.

HDMI (High-Definition Multimedia Interface):

This point-to-point interface is for audio and video signals designed as a single-cable solution for home

theater and consumer electronics equipment.

DC12V Jack:

Use this to connect the power adapter to DC12V jack after connecting connector power cord to adapter.

Then Turn on the system either by power switch on front panel or remote control when all necessary

hardware configuration are made.
