Intel® Desktop Board

DQ57TM

Specification Update

December 2010

Order Number: E88215-006US

The Intel®Desktop Board DQ57TM may contain design defects or errors known as errata, which may cause the product to deviate

from published specifications. Current characterized errata are documented in this Specification Update.

2 Intel Desktop Board DQ57TM Specification Update

Revision History

Revision Revision History Date

-001 This document is the first Specification Update for the Intel®Desktop

Board DQ57TM January 2010

-002 Updated the Documentation Changes Section April 2010

-003 Updated the Documentation Changes Section May 2010

-004 Updated the General Information Section July 2010

-005 Updated Errata Section July 2010

-006 Updated the General Information Section December 2010

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. NO LICENSE,

EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS

GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR

SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR

IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR

WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT

OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. INTEL PRODUCTS ARE NOT

INTENDED FOR USE IN MEDICAL, LIFE SAVING, LIFE SUSTAINING APPLICATIONS.

Intel may make changes to specifications and product descriptions at any time, without notice.

Designers must not rely on the absence or characteristics of any features or instructions marked “reserved”

or “undefined”. Intel reserves these for future definition and shall have no responsibility whatsoever for

conflicts or incompatibilities arising from future changes to them.

The Intel®Desktop Board DQ57TM may contain design defects or errors known as errata which may cause

the product to deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your

product order.

Copies of documents which have an ordering number and are referenced in this document, or other Intel

literature, may be obtained from:

Intel Corporation

P.O. Box 5937

Denver, CO 80217-9808

or call in North America 1-800-548-4725, Europe 44-0-1793-431-155, France 44-0-1793-421-777,

Germany 44-0-1793-421-333, other Countries 708-296-9333

Intel and the Intel logo are registered trademarks of Intel Corporation in the U.S. and other countries.

* Other names and brands may be claimed as the property of others.

Intel Desktop Board DQ57TM Specification Update 3

Contents

Specification Update for the Intel®Desktop Board DQ57TM .....4

Terminology ............................................................................................ 5

General Information .................................................................................5

Summary of Changes ............................................................................... 6

Specification Changes...............................................................................7

4 Intel Desktop Board DQ57TM Specification Update

Specification Update for the

Intel®Desktop Board DQ57TM

This document is an update to the specifications contained in the Intel®Desktop Board

DQ57TM Technical Product Specification (Order Number: E83547). It is intended for

hardware system manufacturers and software developers of applications, operating

systems, or tools. It will contain Specification Changes, Errata, Specification

Clarifications, and Documentation Changes.

Refer to the Intel®Core™ i7-800 and i5-700 Desktop Processor Series Specification

Update (Order Number: 42224) for specification updates concerning the Core i7 and

Core i5 processors that may apply to the desktop board DQ57TM. Unless otherwise

noted in this document, it should be assumed that any Processor errata for a given

stepping are applicable to the Altered Assembly (AA) revision(s) associated with that

stepping.

Refer to the Intel®5 Series Chipset and Intel®3400 Series Chipset Specification

Update (Order Number: 386904) for specification updates concerning the Intel®Q57

Express Chipset that may apply to the desktop board DQ57TM. Unless otherwise noted

in this document, it should be assumed that any Platform Controller Hub errata for a

given stepping are applicable to the Altered Assembly (AA) revision(s) associated with

that stepping.

Intel Desktop Board DQ57TM Specification Update 5

Terminology

Specification Changes are modifications to the current published specifications.

These changes will be incorporated in the next release of the specifications.

Errata are design defects or errors. Characterized errata may cause the desktop

board behavior to deviate from published specifications. Hardware and software

designed to be used with any given Altered Assembly (AA) and BIOS revision level

must assume that all errata documented for that AA and BIOS revision level are

present on all desktop boards.

Specification Clarifications describe a specification in greater detail or further

highlight a specification’s impact to a complex design situation. These clarifications

will be incorporated in the next release of the specifications.

Documentation Changes include typos, errors, or omissions from the current

published specifications. These changes will be incorporated in the next release of the

specifications.

General Information

Basic Desktop Board DQ57TM Identification Information

AA Revision BIOS Revision Notes

E70931-303 TMIBX10H.86A.0025 1,2

E70931-400 TMIBX10H.86A.0025 1,2

E70931-401 TMIBX10H.86A.0029 1,2

E70931-402 TMIBX10H.86A.0029 1,2

E70931-403 TMIBX10H.86A.0029 1,2

E92694-401 TMIBX10H.86A.0037 1,2

E92694-402 TMIBX10H.86A.0037 1,2

Notes:

1. The AA number is found on a small label on the component side of the board.

2. The Intel®Q57 PCH Express Chipset used on this AA revision consists of the following component:

Device Stepping S-Spec Numbers

82Q57 Platform Controller

Hub (PCH) B3 SLGZW

6 Intel Desktop Board DQ57TM Specification Update

Summary of Changes

The following table indicates the Specification Changes, Errata, Specification

Clarifications, or Documentation Changes that apply to the Intel®Desktop Board

DQ57TM. Intel intends to fix some of the errata in a future revision of the desktop

board, and to account for the other outstanding issues through documentation or

specification changes as noted.

The following notations are used in the table:

Doc: Document change or update that will be implemented.

Plan Fix: This erratum may be fixed in a future revision of the desktop board, driver, or BIOS.

Fixed: This erratum has been previously fixed.

No Fix: There are no plans to fix this erratum.

Shaded: This erratum is either new or modified from the previous version of the document.

No. Plans Specification Changes

1 Doc Updated Section 2.9 Environmental to correct the operating temperature in Table 32.

No. Plans Errata

1 Fixed Disabling USB Boot still allows USB devices to be booted.

2 Fixed Enabling USB Backwards Compatibility Mode disables some USB Ports.

3 No Fix Multiple Insert and Removal Cycles of a USB Device May Disable all USB Ports.

Intel Desktop Board DQ57TM Specification Update 7

Specification Changes

The Specification Changes listed in this section apply to the Intel®Desktop Board

DQ57TM Technical Product Specification.

1. Update to Section 2.9 Environmental to correct the operating temperature in

Table 32.

2.9 Environmental

Table 32 lists the environmental specifications for the board.

Table 32. Environmental Specifications

Parameter Specification

Temperature

Non-Operating

-40 °C to +60 °C

Operating

0 °C to +55 °C

Shock

Unpackaged 50 g trapezoidal waveform

Velocity change of 170 inches/second²

Packaged Half sine 2 millisecond

Product Weight (pounds) Free Fall (inches) Velocity Change (inches/sec²)

<20 36 167

21-40 30 152

41-80 24 136

81-100 18 118

Vibration

Unpackaged 5 Hz to 20 Hz: 0.01 g² Hz sloping up to 0.02 g² Hz

20 Hz to 500 Hz: 0.02 g² Hz (flat)

Packaged 5 Hz to 40 Hz: 0.015 g² Hz (flat)

40 Hz to 500 Hz: 0.015 g² Hz sloping down to 0.00015 g² Hz

8 Intel Desktop Board DQ57TM Specification Update

Errata

Errata 1 and 2 below have been fixed in BIOS version TMIBX10H.86A.0038.

1. Disabling USB Boot Still Allows USB Devices to be Booted

Problem: If USB Boot is disabled in BIOS Setup, it does not prevent attached bootable

USB devices from booting. Default setting is Enabled.

Implication: The USB Boot Disable setting is effectively ignored. Any attached bootable

USB device will still be booted.

Workaround: A fix has been found and will be implemented in the next BIOS update.

Status: Fixed.

2. Enabling USB Backwards Compatibility Mode disables some

USB Ports

Problem: The current implementation of the Intel Desktop Board DQ57TML causes

some USB ports to be disabled in the operating system whenever an Intel®

Core™ processor with Intel®Graphics Technology is used in USB Backwards

Compatibility Mode.

Implication: Some USB devices may fail to work unless USB Backwards Compatibility Mode

is enabled. However, certain Intel®vPro™ Technology features, such as KVM

Redirection, require this mode to be disabled in order to function properly.

You cannot use both KVM Redirection and USB Backwards Compatibility Mode

concurrently.

Workaround: A fix has been found that will allow Intel®Core™ processors with Intel®

Graphics Technology to be used in USB Backwards Compatibility Mode with all

USB ports functional. It will be implemented in the next BIOS update.

Status: Fixed.

3. Multiple Insert and Removal Cycles of a USB Device May

Disable all USB Ports

Problem: The USB subsystem may become disabled after several insertion and removal

cycles of a single USB device when no other USB devices are connected. The

failure occurs when running Microsoft Windows* XP and it may require a

system reboot. Both Microsoft Windows Vista* and Microsoft Windows 7

operating systems do not appear to exhibit this failure.

Workaround: Enabling USB Backwards Compatibility Mode in the BIOS menu may reduce

the occurrence or alleviate this issue.

Status: No Fix.
