Intel PMB-601LF Manuale utente

USER’S

MANUAL

PMB-601LF

Intel®Core2Duo

ATXMotherboard

WithVGA/Sound/2LAN

PMB-601LF M1

PMB-601LF Intel® Core 2 Duo

ATX Motherboard

With VGA/ Sound/ 2LAN

OPERATION MANUAL

This operation manual is meant to assist both Embedded Computer

manufacturers and end users in installing and setting up the system. The

information contained in this document is subject to change without any

notice.

This manual is copyrighted in January, 2007. You may not reproduce or

transmit in any form or by any means, electronic, or mechanical, including

photocopying and recording.

ACKNOWLEDGEMENTS

All trademarks and registered trademarks mentioned herein are the

property of their respective owners.

CE NOTICE

This is a class A product. In a domestic environment this product may

cause radio interference in which case the user may be required to take

adequate measures.

FCC NOTICE

This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is

likely to cause harmful interference in which case the user will be

required to correct the interference at his own expense.

You are cautioned that any change or modifications to the equipment not

expressly approve by the party responsible for compliance could void

your authority to operate such equipment.

Contents

TABLE OF CONTENTS

CHAPTER 1 INTRODUCTION

1-1 About This Manual ........................................................ 1-2

1-2 System Specification ...................................................... 1-3

1-3 Safety Precautions ......................................................... 1-6

CHAPTER 2 HARDWARE CONFIGURATION

2-1 Jumper & Connector Quick Reference Table ................ 2-2

2-2 Component Locations .................................................... 2-3

2-3 How to Set the Jumpers ................................................. 2-4

2-4 COM Port Connector ……..…………………………... 2-6

2-5 COM3 RI & Voltage Selection …………..……………. 2-8

2-6 COM4 RI & Voltage Selection ……………………… 2-9

2-7 RS232/422/485(COM2) Selection ................................ 2-10

2-8 Keyboard and PS/2 Mouse Connector .....................….. 2-11

2-9 Reset Connector ............................................................ 2-11

2-10 Hard Disk Drive LED Connector .................................. 2-12

2-11 ATX Power Button ….................................................... 2-12

2-12 External Speaker Connector .......................................... 2-12

2-13 PLED Connector …….................................................... 2-13

2-14 KeyLock Connector ..………………………………… 2-13

2-15 External SMI Connector ……………………………… 2-13

2-16 Clear CMOS Data Selection ………………………… 2-14

2-17 CPU Fan Connector ………………………………….. 2-14

2-18 System Fan Connector ………………………………… 2-15

2-19 Power Fan Connector ………………………………….. 2-15

2-20 NB Fan Connector …………………………………….. 2-15

2-21 VGA Connector …………………..…………………… 2-16

2-22 Serial ATA Connector ………………………………… 2-17

2-23 Floppy Disk Drive Connector ....................................... 2-19

2-24 Printer Connector .......................................................... 2-20

2-25 Universal Serial Bus Connector ……………………… 2-21

2-26 IrDA Connector ………………………………………. 2-22

2-27 USB & LAN Connector ……………………………… 2-23

2-28 ATX Power Connector ………………………………. 2-25

2-29 Sound Connector ……………………………………… 2-26

2-30 CD Audio-In Connector ………………………………. 2-27

2-31 Memory Installation ………………………………….. 2-27

Contents

CHAPTER 3 SOFTWARE UTILITIES

3-1 Introduction …………..........................................…....... 3-2

3-2 VGA Driver Utility ……………………………….…… 3-3

3-3 Flash BIOS Update ..............................................…....... 3-4

3-4 LAN Driver Utility …...........................................…...... 3-6

3-5 Sound Driver Utility …………………………………… 3-7

3-6 Intel Chipset Software Installation Utility …..……..….. 3-8

3-7 USB2.0 Software Installation Utility ………………….. 3-9

3-8 Watchdog Timer Configuration ……………………….. 3-10

CHAPTER 4 AWARD BIOS SETUP

4-1 Introduction ................................................................... 4-2

4-2 Entering Setup ............................................................... 4-3

4-3 The Standard CMOS Features ………............................ 4-4

4-4 The Advanced BIOS Features ....................................... 4-8

4-5 Advanced Chipset Features ........................................... 4-12

4-6 Integrated Peripherals …............................................... 4-14

4-7 Power Management Setup ............................................. 4-19

4-8 PNP/PCI Configuration …............................................. 4-21

4-9 PC Health Status …….................................................... 4-23

4-10 Frequency Control ....................................…………...... 4-24

4-11 Load Fail-Safe Defaults ................................................. 4-25

4-12 Load Optimized Defaults .........................................…. 4-25

4-13 Password Setting ……………………………………… 4-26

4-14 Save & Exit Setup ......................................................... 4-27

4-15 Exit Without Saving ………………………………… 4-28

APPENDIX A EXPANSION BUS

PCI Bus Pin Assignment ..............................................…......... A-2

APPENDIX B TECHNICAL SUMMARY

Block Diagram ........................................................................... B-2

Interrupt Map ............................................................................ B-3

RTC & CMOS RAM Map ........................................................ B-4

Timer & DMA Channels Map .................................................. B-5

I/O & Memory Map ...............................................…................ B-6

Page:1-1

INTRODUCTION

This chapter gives you the information for PMB-601LF. It also

outlines the System specifications.

Section includes:

zAbout This Manual

zSystem Specifications

zSafety Precautions

Experienced users can skip to chapter 2 on page 2-1

for a Quick Start.

CHAPTER

Chapter 1 Introduction

Page: 1-2 PMB-601LF USER

′

S MANUAL

1-1. ABOUT THIS MANUAL

Thank you for purchasing our PMB-601LF Intel® Core 2 Duo ATX

Motherboard enhanced with VGA/Sound/2LAN, which is fully PC / AT

compatible. The PMB-601LF provides faster processing speed, greater

expandability and can handle more tasks than before. This manual is

designed to assist you how to install and set up the system. It contains four

chapters. The user can apply this manual for configuration according to the

following chapters:

Chapter 1 Introduction

This chapter introduces you to the background of this manual, and the

specifications for this system. The final page of this chapter will indicate

how to avoid damaging this board.

Chapter 2 Hardware Configuration

This chapter outlines the component locations and their functions. In the

end of this chapter, you will learn how to set jumper and how to configure

this card to meet your own needs.

Chapter 3 Software Utilities

This chapter contains helpful information for proper installations of the

VGA utility, LAN utility, Sound utility, and Flash BIOS Update. It also

describes the Watchdog-timer configuration.

Chapter 4 Award BIOS Setup

This chapter indicates you how to set up the BIOS configurations.

Appendix A Expansion Bus

This Appendix introduces you the expansion bus for 1 x PCI-E16 BUS, 1

x PCI-E4 BUS, 4 x PCI Bus and 1 x ISA BUS.

Appendix B Technical Summary

This section gives you the information about the Technical maps.

Chapter 1 Introduction

PMB-601LF USER

′

S MANUAL Page: 1-3

1-2. SYSTEM SPECIFICATIONS

zCPU (mPGA775):

Intel® Celeron®-D, Pentium® 4, Pentium®-D, Core 2 Duo processor in

mPGA775 Socket.

2.8~3.8 GHz clock generator for Pentium 4

1.86~2.66GHz clock generator for Core 2 Duo

Front Side Bus 533/667/800/1066 MHZ.

Auto detect voltage regulator.

zCHIPSET :

Intel Q965 + ICH8DO+FWH

zMEMORY :

Supports up to 8GB DDR SDRAM.

Four 240-pin DDR2 DIMM sockets on board.

zCACHE :

Built-in CPU.

zREAL-TIME CLOCK :

Build in South Bridge.

zBIOS :

Phoenix-AwardBIOS™for plug & play function.

8Mb with VGA BIOS.

Easy update 1MB flash EEPROM.

Support S/IO Setup.

zKEYBOARD CONNECTOR :

Mini DIN connector.

Supports for AT/PS2 keyboard.

zMOUSE CONNECTOR :

Mini DIN connector.

Supports for PS/2 Mouse.

zBUS SUPPORT :

1 PCI-E16 Slot, support Graphic Card

1 PCI-E4 Slots, support I/O card

4 PCI Slots

Chapter 1 Introduction

Page: 1-4 PMB-601LF USER

′

S MANUAL

1 ISA Slot

zDISPLAY :

Built-in Intel Q965, support for CRT.

Onboard 15-pin VGA D-SUB connector, support for resolution on SVGA

Monitor.

zSATA INTERFACE :

6 SATA ports, support RAID 0,1,5,10.

zSERIAL PORT :

Four serial connectors.

COM1/3/4 for RS-232, COM2 for RS-232/422/485.

COM3/4 can output +5V or +12V, and use jumper settings.

zFLOPPY DISK DRIVER INTERFACE :

Support up to two Floppy Disk Drives, 3.5" and 5.25" (360K / 720K / 1.2M /

1.44M / 2.88M).

zUSB CONNECTOR :

Support up to ten USB 2.0 ports.

4 ports with LAN1/ LAN2 on rear panel.

6 ports with external 2.54 connector 2x5-pin headpin.

zLAN ADAPTER :

Dual ports, Intel® 82573V x 2, 10/100/1000 BaseT Ethernet.

LAN1: 10/100/1000 BaseT Ethernet

LAN2: 10/100/1000 BaseT Ethernet

Support wake-on-LAN function.

zSOUND :

Realtek ALC262A (HD Codec), including SPDIF.

Fully Compliant HD Analog I/O Component

16-Bit Stereo Full-Duplex Codec

Four Analog Line-level Stereo Inputs for Connection.

High Quality CD Input with Ground Sense

Stereo Line-Level Output

Interface: Line-In, Line-Out, Microphone, and CD Audio-In.

Chapter 1 Introduction

PMB-601LF USER

′

S MANUAL Page: 1-5

zHARDWARE MONITORING FUNCTION :

Monitor Voltage, CPU temperature, & Cooling fan.

If CPU Temperature is over setting, the buzzer will send out a warming (only

under DOS system).

zIRDA PORT :

5-pin Infrared port, support IrDA v1.0 SIR protocol

zPARALLEL PORT :

SPP / ECP / EPP Function.

1 port, bi-directional parallel port.

zGREEN FUNCTION :

Controlled by hardware and software.

zLED INDICATOR :

System power

Hard Disk access (SATA)

zDMA CONTROLLER :

82C37 x 2

zDMA CHANNELS :

zINTERRUPT CONTROLLERS :

82C59 x 2

zINTERRUPT LEVELS :

zOPERATING TEMPERATURE :

0 to 60°C.

zBOARD DIMENSIONS :

305mm x 344mm, 12” x9.61”

zBOARD NET WEIGHT :

810 gram.

Indice

Altri manuali Intel Scheda madre

Intel

Intel D925XECV2 Manuale utente

Intel

Intel D945GTP Manuale utente

Intel

Intel DQ33HS Manuale utente

Intel

Intel PT-6IBT Manuale utente

Intel

Intel BLKD945GPMLKR Guida alla configurazione

Intel

Intel D945PWM Manuale utente

Intel

Intel BLKDX38BT Guida alla configurazione

Intel

Intel BOXD915GEV - LGA775 800FSB 4DDR2 Aud+Vdo SATA ATX... Manuale utente

Intel

Intel D925XCV Manuale utente

Intel

Intel D845EPI Manuale utente

Intel

Intel VIA K8T800 Manuale utente

Intel

Intel D425KT Guida alla configurazione

Intel

Intel D865PCK Manuale utente

Intel

Intel BLKDH67VR Guida alla configurazione

Intel

Intel DH61DL Manuale utente

Intel

Intel Thin Mini-ITX Guida

Intel

Intel S5000XVNSATA Manuale utente

Intel

Intel D915GLVG Manuale utente

Intel

Intel DH61BE Manuale utente

Intel

Intel D845PESV Manuale utente

Intel

Intel BLKDH67BL Manuale utente

Intel

Intel DZ68PL Manuale utente

Intel

Intel iSBC 80 Guida rapida per l'utente

Intel

Intel BLKDP55KG - LG1156 MAX-16 GB DDR3 ATX... Guida alla configurazione

Manuali Scheda madre popolari di altre marche

DFI

DFI SD170 Manuale utente

ASROCK

ASROCK ROMED8-2T Manuale utente

Asus

Asus P2L97A Manuale utente

Winmate

Winmate IC70 Manuale utente

Asus

Asus MES-B Manuale utente

Grantech

Grantech SYS8F377VGGA-3OMN Manuale utente

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuale utente

Gigabyte

Gigabyte GA-9IVDT Manuale utente

Texas Instruments

Texas Instruments ADS8372EVM Manuale utente

Commell

Commell MS-C73 Manuale utente

IBT Technologies

IBT Technologies MB860 Manuale utente

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuale utente

Biostar

Biostar M7VIT Bravo Istruzioni per l'uso e l'installazione

Asus

Asus F1A55-M LX PLUS R2.0 Manuale utente

EPC

EPC EPC9147C Manuale utente

Asus

Asus EX-B760M-V5 D4 Manuale utente

EPOX

EPOX MU-8KHA0010 Manuale utente

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuale utente
