Intel®Server Board SE7501HG2

Troubleshooting Guide

A Guide for Technically Qualified Assemblers

of Intel®Identified Subassemblies/Products

Intel order number C40869-001

Revision 1.0

April 14, 2003

Revision History Intel® Server Board SE7501HG2 Troubleshooting Guide

Revision 1.0

Revision History

Date Revision

Number

Modifications

4/14/2003 1.0 Initial release.

Intel® Server Board SE7501HG2 Troubleshooting Guide Disclaimers

Revision 1.0

Disclaimers

Information in this document is provided in connection with Intelproducts. No license, express

or implied, by estoppel or otherwise, to any intellectual property rights is granted by this

document. Except as provided in Intel’s terms and conditions of sale for such products, Intel

assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to

sale and/or use of Intel products including liability or warranties relating to fitness for a particular

purpose, merchantability, or infringement of any patent, copyright or other intellectual property

rights. Intel products are not intended for use in medical, life saving, or life sustaining

applications.

Intel may make changes to specifications and product descriptions at any time, without notice.

Designers must not rely on the absence or characteristics of any features or instructions marked

“reserved” or “undefined”. Intel reserves these for future definition and shall have no

responsibility whatsoever for conflicts or incompatibilities arising from future changes to them.

The IntelSE7501HG2 server board may contain design defects or errors known as errata

which may cause the product to deviate from published specifications. Current characterized

errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications before

placing your product order.

Copies of documents which have an ordering number and are referenced in this document, or

other Intel literature, may be obtained from:

Intel Corporation

P.O. Box 5937

Denver, CO 80217-9808

or call in North America 1-800-548-4725, Europe 44-0-1793-431-155, France 44-0-1793-421-777,

Germany 44-0-1793-421-333, other countries 708-296-9333

Intel, Pentium, and Xeon are trademarks or registered trademarks of Intel Corporation or its

subsidiaries in the United States and other countries.

*Other brands and names may be claimed as the property of others.

Table of Contents Intel® Server Board SE7501HG2 Troubleshooting Guide

Revision 1.0

Table of Contents

1. Introduction .......................................................................................................................... 5

2. Server Board Tools and References .................................................................................. 5

3. Questions and Answers ......................................................................................................8

Intel®Server Issue Report Form .............................................................................................. 12

Intel® Server Board SE7501HG2

1. Introduction

This guide is provided to help the user of the Intel®Server Board SE7501HG2 troubleshoot and

identify possible problem areas encountered in configuring or maintaining their server system.

This guide is to be used in conjunction with other information that is available on public Intel

websites.

2. Server Board Tools and References

As part of Intel’s commitment to provide outstanding technical support several documents,

drivers, and diagnostic tools are included with your purchase of the server board SE7501HG2.

These references and tools, along with information updates published to Intel’s public support

site, help to minimize downtime if an issue occurs. Below is a summary of references and tools

provided and where they are located.

Tested Hardware and OS List

The Tested Hardware and OS list is located on the web at:

http://support.intel.com/support/motherboards/server/SE7501HG2/testedhw_os.htm. This list

contains a comprehensive list of operating systems and hardware components tested by Intel

with the Intel Server Board SE7501HG2. This list does not contain information about memory,

processors, or non-Intel chassis. It does contain the following:

• PCI cards (Example: RAID controllers, Network Interface Cards, SCSI controllers)

• USB devices

• CD, DVD, floppy drives

• Removable devices

• Hard drives

• Keyboard / video / mouse switch boxes

This list is updated periodically.

Supported Processors

Intel tests and publishes all processors that can be installed on the server board SE7501HG2.

This list is located on the web at:

http://support.intel.com/support/motherboards/server/se7501hg2/procsupp.htm. This list is

updated when processor speeds are increased, a new generation of processors becomes

available, or the stepping of the processor changes. If a processor is not on this list, it is not

supported on the server board SE7501HG2.

Intel® Server Board SE7501HG2 Troubleshooting Guide

Revision 1.0

Supported Memory

Intel tests and publishes all memory that has been tested on the SE7501HG2. This list is

located on the web at:

http://support.intel.com/support/motherboards/server/se7501hg2/tested_memory.htm.

This list is updated periodically.

Product Documentation

The Intel Server Board SE7501HG2 features are described in several documents. The two key

documents are as follows:

• The Intel®Server Board SE7501HG2 Product Guide is shipped with the product on the

Resource CD. It is also posted on the web at

http://support.intel.com/support/motherboards/server/se7501br2/prod_guide.htm.

Translated versions of this document may be also be available on the web. The Product

Guide is a reference document that describes the key feature of the server board and its

components and instructions on how to integrate the server board into a chassis.

• The Intel®Server Board SE7501HG2 Technical Product Specification is posted on the

web at http://support.intel.com/support/motherboards/server/SE7501HG2/spec.htm. This

document contains detailed technical information about the features of the server board

SE7501HG2. Updates to this document are posted on a regular basis.

Spares, Parts and Configuration Guide

The Spares, Parts, and Configuration Guide assists customers in ordering the necessary

components to configure the server board SE7501HG2 with Intel®Server Chassis SC5200

Knock-down Kit products. The document includes part numbers, order codes, and spares

available for integration.

The document is available at

http://support.intel.com/support/motherboards/server/se7501hg2/sp_config.htm

Platform Confidence Test

The SE7501HG2 Resource CD contains the Platform Confidence Test utility. This test utility

runs diagnostics on your configuration and provides valuable information and troubleshooting

information. The Resource CD contains a document describing the details of the test utility and

how to use them.

Intel® Server Board SE7501HG2

Intel®SMaRT Tool

The SE7501HG2 Resource CD contains the Intel®Server Maintenance and Reference Training

(SMaRT) Tool. The Intel SMaRT Tool contains:

• Virtual system tours

• Step-by-Step parts replacement instructions

• Searchable parts database

• Product spares lists

• Technical information

• Technical support references

LED Information

The Intel®Server Board SE7501HG2 includes LEDs that can aid in troubleshooting your

system. A table of these LEDs with a description of their use is listed below.

LED Name Function Location Color Status

System fault Visible fault warning Front panel and board

rear left corner

Green or

Amber

On = no fault

Green blink = degraded

Amber = critical error or non-

recoverable

Amber blink = non-critical

IDE activity Front panel Front panel and board

left side

Green Blinking = activity

Beep Codes

Sometimes when a system is powered on a sequence of ‘beeps’ may be heard during the boot

sequence. These beeps have a code that identifies system or PCI card events. For example,

some Intel®RAID cards have beep codes. Before checking for a system beep code error make

sure the PCI card is not causing the beeping.

System beep codes are generated by the BMC. The BMC generates beep codes upon

detection of the failure conditions listed in the following table. Each digit in the code is

represented by a sequence of beeps whose count is equal to the digit. The most common beep

codes are listed in the table below

Code Reason for Beep

1 Front panel CMOS clear initiated

1-5-1-1 FRB failure (processor failure)

1-5-2-1 No processors installed or processor socket 1 is empty.

1-5-2-3 Processor configuration error (e.g., mismatched VIDs, Processor slot 1 is empty)

1-5-2-4 Front-side bus select configuration error (e.g., mismatched BSELs)

1-5-4-2 Power fault: DC power unexpectedly lost (e.g. power good from the power supply was deasserted)

1-5-4-3 Chipset control failure

1-5-4-4 Power control failure (e.g., power good from the power supply did not respond to power request)

Intel® Server Board SE7501HG2 Troubleshooting Guide

Revision 1.0

In the case of a Bootblock update, where video is not available for text messages to be

displayed, speaker beeps are necessary to inform the user of errors. For beep codes

associated with a Bootblock update refer to the Intel®Server Board SE7501HG2 Technical

Product Specification located at

http://support.intel.com/support/motherboards/server/SE7501HG2/spec.htm

3. Questions and Answers

Processor Questions and Answers

Does it matter which processor is populated first?

Yes. The socket for Processor 1 must be populated first. The Processor 1 socket is the closest

to the outside edge of the board and is labeled “CPU1”. The Processor 2 socket is closer to the

center of the board and is labeled “CPU2”. If a single processor is used and is installed in the

Processor 2 socket instead of the Processor 1 socket, this product will not.

The system bus is automatically terminated, which means if a single processor is used, the

empty Processor 2 socket does not require a terminator.

Will the system always boot from Processor 1, even if two processors are installed?

Not necessarily. When two processors are installed, the Intel®Server Board SE7501HG2 will

boot from either processor using a technique called Fault Resilient Booting (FRB). If the primary

processor fails to respond in a designated amount of time during POST, the secondary

processor is used to complete the boot-up sequence.

If a processor error occurs in a single processor configuration, the board will halt during the boot

process and display a message for the user indicating that it is forcing itself to boot from a

potentially bad processor. The system will attempt to continue the boot process after the user

acknowledges the message.

For more information on FRB, refer to the Intel® Server Board SE7501HG2 Technical Product

Specification located on the Intel Support Website

How do I disable hyper-threading?

Hyper-threading can be disabled in BIOS setup, under the “Advanced” menu. Disabling hyper-

threading will cause performance degradation on some applications.

If I only install one processor, what do I do with the standoffs around the Processor 2

socket?

All eight CPU standoffs on the chassis base plate must be installed when the board is being

integrated in a chassis. These standoffs are required even if the system is will be operated with

only a single processor in order to withstand shock and vibration.

Intel® Server Board SE7501HG2

Which way should the processor wind tunnels be installed?

When configuring the board in a dual-processor configuration, both processor wind tunnels and

their fans must be installed with the same orientation. Proper installation requires that both fans

push air through the processor wind tunnel. Refer to the Intel®Server Board SE7501HG2 Quick

Start User’s Guide for installation instructions.

Memory Questions and Answers

What are the memory / DIMM requirements?

The SE7501HG2 supports only registered DDR266 SDRAM memory. DIMMs must be installed

in pairs and must be populated by bank, starting with Bank1 (DIMM1A and DIMM1B contiguous

sockets). Although the board allows the user to mix various sizes of DIMMs between banks,

DIMMs must be identical within the banks. Memory Bank1 is the pair of DIMMs located closest

to the edge of board; refer to the board drawing on the Intel®Server Board SE7501HG2 Quick

Start User’s Guide.

On Board Component Questions and Answers

Which 10/100/1000 NIC connector is for server management?

The server board SE7501HG2 board provides two RJ45 connectors for the on-board Network

Interface Controllers. The two NICs are stacked with NIC1 on the bottom. NIC1 is the

designated Server Management NIC.

How do I disable the integrated components?

Onboard controllers can be disabled through the server board BIOS setup. To enter BIOS

setup, press F2 when prompted during the boot up process.

How should the system fans be connected?

The SE7501HG2 board ships with five system fan headers. Sys Fan 1, Sys Fan 2, Sys Fan 3,

and Sys Fan 4 are used when integrating the server board SE7501HG2 in the Intel®Server

Chassis SC5200 Base. Sys Fan 5 is used in addition to Sys Fans 1 through 4 when the server

board is integrated in the Intel®Server Chassis SC5200 650W Hot-Swap Redundant Power

(HSRP).

The following table describes how the fans should be connected on the board when integrated

into the SC5200 450W Base Chassis.

Rear Chassis Fans Front Epac Fans

Reference Designator Silkscreen Reference Designator Silkscreen

J5A1 Sys Fan1 J2K2 Sys Fan3

J4A1 Sys Fan2 J4K3 Sys Fan4

Intel® Server Board SE7501HG2 Troubleshooting Guide

Revision 1.0

Some of my devices are not recognized under the Windows* 2000 Device Manager. What

might be wrong?

After installing Microsoft* Windows 2000 Advanced Server, the Device Manager might display

unrecognized devices. This is because the operating system does not include all of the drivers

for the Intel®E7501 chipset, on-board NICs, and the SCSI Hot Swap Backplane. Installing the

Intel Chipset Utility (INF files), NIC drivers, and HSBP drivers that are available on the Resource

CD will allow the operating system to properly recognize these devices.

Altri manuali per SE7501HG2

Indice

Altri manuali Intel Scheda madre

Intel

Intel DQ77MK Manuale utente

Intel

Intel D946GZIS - Desktop Board Motherboard Manuale utente

Intel

Intel D865GSA Manuale utente

Intel

Intel DX58SO2 Manuale utente

Intel

Intel DG965RY Manuale utente

Intel

Intel 440BX Manuale utente

Intel

Intel DQ965CO Manuale utente

Intel

Intel EV80Cl96KB Manuale utente

Intel

Intel S5000PSLROMB Istruzioni per l'installazione

Intel

Intel D845GEBV2 - OCTOBRE 2002 Manuale utente

Intel

Intel D945PVS Manuale utente

Intel

Intel AN430TX - Motherboard - ATX Guida alla configurazione

Intel

Intel BLKDH57DD Guida alla configurazione

Intel

Intel DQ965GF - Desktop Board Motherboard Manuale utente

Intel

Intel DQ87PG Manuale utente

Intel

Intel Celeron 1047UE/847 Manuale utente

Intel

Intel DDR266 (PC2100) Manuale utente

Intel

Intel DH57DD Manuale utente

Intel

Intel DG41KR Manuale utente

Intel

Intel D915PLWD Manuale utente

Intel

Intel DH61AGL Manuale utente

Intel

Intel D845PESV Manuale tecnico

Intel

Intel S1200BTL Manuale utente

Intel

Intel NUC5i3MYHE Manuale utente

Manuali Scheda madre popolari di altre marche

DFI

DFI SD170 Manuale utente

ASROCK

ASROCK ROMED8-2T Manuale utente

Asus

Asus P2L97A Manuale utente

Winmate

Winmate IC70 Manuale utente

Asus

Asus MES-B Manuale utente

Grantech

Grantech SYS8F377VGGA-3OMN Manuale utente

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuale utente

Gigabyte

Gigabyte GA-9IVDT Manuale utente

Texas Instruments

Texas Instruments ADS8372EVM Manuale utente

Commell

Commell MS-C73 Manuale utente

IBT Technologies

IBT Technologies MB860 Manuale utente

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuale utente

Biostar

Biostar M7VIT Bravo Istruzioni per l'uso e l'installazione

Asus

Asus F1A55-M LX PLUS R2.0 Manuale utente

EPC

EPC EPC9147C Manuale utente

Asus

Asus EX-B760M-V5 D4 Manuale utente

EPOX

EPOX MU-8KHA0010 Manuale utente

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuale utente
