CNC-machine:
oThe CNC-machine (complete machine) is according to the type mounted on the
machine tool appropriately used. That is, the concrete tool of the CNC machine
specifies the intended use of the machine within the meaning of the Machinery
Directive (Annex I, Section 1.1.2). Under this premise, the CNC-machine is
suitable for milling, drilling, cutting, engraving, metering, measuring or water jet
cutting. The CNC-machine is not suitable for graphite machining.
oAppropriate processing materials are light metals, plastics, wood, glass, platinum
materials, etc.
oNot permitted are materials which produces during processing harmful gases
oThe CNC-machine is prepared for an extraction unit device. This extraction unit is
preferably suitable for dry dust (wood dust, fibreglass / fibreglass dust, platinum
dust, etc.).
The CNC base machine (partly completed machine) can be added by you as the buyer
of the base-machine with a variety of appropriate processing tools to a CNC-machine
(complete machine) in compliance with the requirements of the machinery directive. You
are responsible for CE certification if you use the machine itself resp. sell (bring to
market). The CE certification also includes the legally required identification of a safe
machine by the CE mark.
CNC-machinery for milling processes:
oThe CNC-milling-machines are designed for milling/drilling of the following
materials: aluminium, copper, brass, plastics (e.g. GRP / fibreglass), wood
oThe processing of magnesium is prohibited because of fire.
oDuring the processing of steel / stainless steel only engraving or a processing
with low cutting forces is possible.
oIt shall not be used milling spindles with a tool holder greater than ISO 25 or HSK
25 (hollow shank taper). The speed of the spindle drive may not be higher than
the corresponding processing speed for the material.
oAll machines are designed for milling spindles (spindle machining, induction
motor) with a maximum of 3 kW drive power.
oCutters and drills may be used up to a maximum shaft diameter of 12 mm.
oThe tools form cutters and conical formers for timber industry may be used up to
a maximum cutting diameter of 45mm and a shaft diameter of 12 mm.
The rapid traverse velocity should not exceed the values of 150mm/sec till 200mm/sec
depending on the machine size.
The feed rate of the processing tool in the material must be determined technologically
and should be smaller than the rapid traverse speed.
For the secure clamping of the tools in the tool holder, the user is responsible.
To the reasonably foreseeable misuse belongs the operation of the machine by two
persons. It is prohibited that one person executes a motion of the axis of the CNC
machine via software (manual move or program start) or by pressing the START button
on the operating console / CNC operation panel and another person is touching into the
machines workspace or do work in another way when the safety door is open and an
axis movement is going on.
You are not allowed to manipulate the locking of the safety door.
