Jacuzzi Capella BE60 Manuale utente

The Capella’s®unique corner conﬁguration

allows for roomy relaxation.

features:

• Exclusive 360º Balanced Airﬂow™ system

• 600 watt variable speed heated air blower

• Thermal Lumbar Comfort™ (TLC)

• Timed purge cycle

• Safely use salts and aromatic oils

• PrO

™

Ozone Sanitation System standard

capella®60 pure air®ll bath

model number: BE60

exterior dimensions:

60" long x 60" wide x 20½" high

interior dimensions:

50" long x 34" wide(mid)

operating gallons:

73 gallons

Detail: The Capella®Pure Air®ll bath features integral

neck and backrests, and Jacuzzi’s exclusive TLC system.

capella® 60 corner pure air®ll bath

capella means “chapel” in Italian. and like the chapel—a place of reverence, contemplation—the capella®pure air®ll bath is a tranquil retreat.

Capella® 60” Corner Pure Air II™ Bath

Model: BE60

Installation Notes

Refer to installation instructions included with ﬁxture before beginning installation.

Please conﬁrm product availability and speciﬁcations before commencing with any

installation work.

PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE

WITHOUT NOTICE.

Ordering Information

Product Code:

BE60 Capella® 60” Corner Pure Air II™

Bath Right Hand

• Center Drain Location

• Accessories / Hardware:

Trim Kit Rotary: #BN21

• Trim Kit Finishes Available:

(827) – Chrome

(898) – Brushed Chrome

(815) – Satin Nickel

(829) – Bright Brass

(805) – Platinum

(826) – Brushed Nickel

(845) – Oil Rubbed Bronze

Technical Speciﬁcations

Dimensions

60” L x 60” W x 20-1/2” H

(1524 mm) L x (1524 mm) W x (521 mm) H

Drain/Overﬂow

A: 18” (457 mm) B: 12-1/8” (308 mm)

Cutout

See Illustration Below

Total Weight

1197 lb (543 kg) / 55.8 lb/sq. ft. (272 kg/m2)

Operating Gallonage

73 U.S. Gal. (276 Liters),

Min. 55 U.S. Gal. (208 Liters)

Max. 90 U.S. Gal. (341 Liters)

Product Weight

150 lb (80 kg)

Skirt Mounting

Optional

Electrical Speciﬁcations

Requires a dedicated GFCI protected separate circuit.

Blower: 120 VAC, 15 AMP, 60 Hz.

Heater

No water heater is available on this unit. Blower has integral air heater.

27"

46-5/8"

27"

60"

43-1/8"

60"

34-15/16"

14" X 4"*

33-1/2"

Blower

Service

Access

Opt.

Service

Access

90˚

(50,8 mm)

20-3/4"

FRONT VIEW SIDE VIEW

(Blower)

#FQ86 12/06

DRAIN/OVERFLOW

Product Shown: Capella® 60” Pure Air II™ Bath Right Hand Shown Model: BE60

* Measurements inside unit represent cutout in ﬂoor to allow for drain/overﬂow.

Minimum Service Access dimensions given.

25-1/2"

58"

25-1/2"

45-9/16"

Drain

Overflow

Blower

CUTOUT
