Keysight Technologies MY53280000 Guida rapida

Option HL6, External Mixing Upgrade Kit,

Serial Prefix ≥MY/SG/US5328 to <MY/SG/US5606

Keysight Technologies

MXA Signal Analyzer

Installation Note

Notices

The information contained in this document is subject to change without notice.

Keysight Technologies makes no warranty of any kind with regard to this material, including but

not limited to, the implied warranties of merchantability and fitness for a particular purpose.

Keysight Technologies shall not be liable for errors contained herein or for incidental or

consequential damages in connection with the furnishing, performance, or use of this material.

Manual Part Number

N9020-90230

Edition

Edition 2, September 2018

Supersedes Edition 1, September 2018

Printed in USA/Malaysia

Published by:

Keysight Technologies, Inc.

1400 Fountaingrove Parkway

Santa Rosa, CA 95403

Installation Note N9020-90230 3

Option HL6, External Mixing Upgrade Kit, Serial Prefix ≥MY/SG/US5328

Option HL6, External Mixing Upgrade Kit,

Serial Prefix ≥MY/SG/US5328

Introduction

This installation note explains how to install the hardware and provides guidelines for adjustment

and verification for Option HL6, External Mixing Upgrade for MXA signal analyzers with serial

number prefixes from MY/SG/US5328 to <MY/SG/US5606. A similar kit, Option EXM, is available

for MXA signal analyzers serial number prefix = MY/SG/US5233 and ≥MY/SG/US5606. There is no

external mixing upgrade available for MXA signal analyzers with serial number prefix

< MY/SG/US5233.

The A13 Front End Assembly that was originally installed in MXAs with serial number prefixes listed

in the box above does not support External Mixing. Therefore, a new A13 Front End Assembly is also

included in the kit, along with the necessary license, cables and connectors required for External

Mixing.

Depending upon what other options are already installed, the A15 Front End Controller board

currently installed in the MXA may also need to be replaced with the Enhanced Front End Controller

(EFEC) board included in this kit. To allow the necessary adjustments the EFEC requires, a license

for Option CR3, 2nd IF Output is also included.

Software and test equipment is required for making adjustments and for performance verification

testing. Information on how to obtain this software can be found at:

www.keysight.com/find/calibrationsoftware

Products Affected: N9020A, MXA Signal Analyzer

Serial Numbers: ≥ MY53280000 to <MY56060000

≥ SG53280000 to <SG56060000

≥ US53280000 to <US56060000

To Be Performed By: (X) Keysight Service Center

(X) Personnel Qualified by Keysight

( ) Customer

Estimated Installation Time:

Estimated Adjustment Time:

Estimated Verification Time:

2.0 Hours

4.0 Hours

Instrument software revision A.14.00 or later is required to install this upgrade.

The instrument must be readjusted and the performance tested to assure the instrument meets

specifications following the hardware installation. The X-Series Performance Verification and

Adjustment Software must be used and have revision E.11.04 or later. All adjustments are

automated. This software is included in the N7814A, Keysight X-Series Signal Analyzer

Calibration Application software.

4Installation Note N9020-90230

Option HL6, External Mixing Upgrade Kit, Serial Prefix ≥MY/SG/US5328

Installation Kit Parts List

Quantity Description Keysight Part

Number

1 A13 Front End Assembly N9020-60314

1 A15 Front End Controller w/ IF MUX N9020-60172

1 Adapter-Coaxial Straight Female-SMA to Female-SMA, 50 Ω1250-1666

1 Washer, Lock, Internal Tooth, ¼-inch 2190-0067

1 Nut-Hex-Double-Chamfer ¼-36-THD .125-IN-THK Stainless Steel 2950-0223

150ΩTermination, SMA male 1810-0118

1 Cable Assembly, External Mixing, Front Panel (W27) N9020-20166

1CableAssembly,μW Front End to W27 (W28) N9020-20241

1 Opt EXM/HL6 Cable Kit with Wire Markers

(includes W26, W36, W37, and W39, listed below)

N9020-60212

1 Cable Assembly, Coaxial 350 mm LG (W26) 8121-2027awith ends

labeled ‘903’ and ‘13’

a. This cable is included in the Opt EXM/HL6 Cable Kit with Wire Markers, p/n N9020-60212.

1 Cable Assembly, Coaxial 240 mm LG (W36) 8121-1862awith ends

labeled ‘902’ and ‘7’

1 Cable Assembly, Coaxial 530 mm LG (W37) 8121-1401awith ends

labeled ‘900’ and ‘100’

1 Cable Assembly, Coaxial 525 mm LG (W39) 8121-2028awith one

end labeled ‘1100’

1 Label, Warning N9030-80018

5 Cable Ties 1400-0249

1 Entitlement Certificate 5964-5178

1 Entitlement Certificate Envelope 5967-7169

1 Installation Note This note

Installation Note N9020-90230 5

Option HL6, External Mixing Upgrade Kit, Serial Prefix ≥MY/SG/US5328

Tools Required

— T-10 TORX Driver

— T-20 TORX Driver

— 5/16-inch torque wrench

— ¼-inch open-end wrench

— 9/16-inch nut driver

— ¼-inch socket on 4-pound torque wrench

— Scissors or knife

—Diagonalcutters

— Keysight Calibration and Adjustment Software, N7814A (revision E.11.04 or later)

— Test equipment and computer supported by the X- Series Performance Tests and Adjustment

Software

— MXA Signal Analyzer Service Guide. This manual is available as:

— N9020A Option OBW or

— Keysight part number N9020-90218

— Microsoft Windows based personal computer with internet access and USB port

— USB storage device with > 2 GB free memory

Initial Instrument Functionality Check

Power on the instrument and allow the instrument to boot up. Run an alignment and display the

measurement screen. (The instrument will probably display a spectrum analyzer screen and you will

see the instrument sweeping.)

There should be no alignment failures. If there are failures, investigate and fix the problem before

continuing.

Before you disassemble the instrument, turn the power switch to Standby. After the instrument

has completely shut down, unplug the instrument. Failure to unplug the instrument can result in

personal injury.

Electrostatic discharge (ESD) can damage or destroy electronic components. All work on

electronic assemblies should be performed at a static-safe workstation. Refer to the

documentation that pertains to your instrument for information about static-safe workstations

and ordering static-safe accessories.

6Installation Note N9020-90230

Option HL6, External Mixing Upgrade Kit, Serial Prefix ≥MY/SG/US5328

Installation Procedure

Analyzer Information

1. Connect a power cord to the analyzer and turn on the analyzer.

2. After the analyzer has completed turning on, press System, Show, System. Make note of the

following information from the Show System screen:

Product Number: _____________

Serial Number: ______________

Instrument S/W Revision: ______________

3. Check for the presence of one of the following options listed below in the Show System. Put a

check mark or “X” after the option listed below that appears in the Show System menu.

N9020A-B40_____

N9020A-CR3_____

N9020A-CRP_____

N9020A-DP2_____

N9020A-MPB_____

N9020A-BBA_____

4. On the analyzer, press System, Show, Hardware. Note the Part #, Matl Rev, Rev, OF Rev, and

Hw Id of the Front End Controller and Front End in the table below.

5. Refer to the data in step 2 above. If the Product Number is not N9020A, do not proceed with

the installation of this kit. This kit is to be installed only on N9020A signal analyzers.

6. Refer to the data in step 2 above. If the Serial Number prefix (the first six characters of the

serial number) is earlier than MY5328, SG5328, or US5328, or is later than MY/SG/US5606 do

not proceed with the installation of this kit. This kit is to be installed only on N9020A signal

analyzers with serial prefixes from ≥MY/SG/US5328 to <MY/SG/US5606.

7. Refer to the data in step 3 above. If option N9020A-BBA is present, there will be additional

steps required to remove and replace the front panel assembly.

8. Refer to the data in step 3 above. If option N9020A-B40, N9020A-MPB and/or N9020A-DP2 is

already present, the EFEC is already installed and you do not need to perform the Replace

Front End Controller procedure.

Assembly Name Part # Matl Rev Rev OF Rev Hw Id

Front End Controller

Front End

Installation Note N9020-90230 7

Option HL6, External Mixing Upgrade Kit, Serial Prefix ≥MY/SG/US5328

9. Refer to the data in step 4 above. Verify that the Front End assembly has a HW ID of 70.

10.Refer to the data in step 3 and step 4 above. If the analyzer has N9020A-CR3 and/or

N9020A-CRP installed, verify that it also has a Front End Controller with Hw Id of 75. If the

Front End Controller has a Hw Id of 75, you do not need to perform the Replace Front End

Controller procedure.

Update Instrument Software

Updating the instrument software and installing the necessary licenses before installing the new

hardware will help ensure that the hardware installation was successful.

Go to the following website and determine whether or not the analyzer has the latest instrument

software already installed:

http://www.keysight.com/find/xseries_software

If the analyzer does not have the latest instrument software already installed, download and install

the latest version.

8Installation Note N9020-90230

Option HL6, External Mixing Upgrade Kit, Serial Prefix ≥MY/SG/US5328

Licensing the New Options

1. Locate the Option Upgrade Entitlement Certificate (5964-5178) from the kit.

2. Redeem the Option Upgrade Entitlement Certificate by following the instructions on the

Certificate.

3. After redeeming your Option Upgrade Entitlement Certificate you will receive an email with an

attached License File.

4. Locate a USB storage device. Perform a virus scan on this device before use.

5. Save the License File to the root directory of the USB Storage Device.

6. Connect the USB Storage Device to one of the analyzer’s USB ports. Connect a mouse to

another USB port. Windows will detect the new hardware and may display the configuration

menu shown in Figure 1. This menu may be configured according to your preferences.

Figure 1 USB Storage Device Configuration Menu

Installation Note N9020-90230 9

Option HL6, External Mixing Upgrade Kit, Serial Prefix ≥MY/SG/US5328

7. The signal analyzer will automatically consume the License File. (This may take a few minutes)

When the License File is consumed the Keysight License Manager will display a “Successful

License Installation” message as shown in Figure 2. Since the license file contains multiple

licenses, multiple “Successful License Installation” messages will appear. Wait until all

licenses have been consumed before removing the USB Storage Device.

Figure 2 Successful License Installation

Verify the License Installation

1. Before the licenses will be recognized, the XSA application must be restarted. Press File, Exit.

An Exit Analyzer dialog box will appear; press Enter to confirm the exit.

2. Double-click on the LaunchXSA icon on the Windows desktop. Wait for the XSA application to

finish starting (the analyzer should be sweeping).

3. Press System, Show, System on the analyzer to display a list of all displayed options. You

should see the following options listed:

—N9020A-EXM External Mixing

—N9020A-CR3 Connector Rear, 2nd IF Output

—N9060A-3FP Amplitude Correction and Limit Lines

—N9060A-4FP TOI and Harmonics

—N9060A-5FP ACP 18 Carrier Measurement

—N9060A-6FP TV Trigger and IQ Analyzer Enhancement

—N9060A-7FP Zero Span, Register, Trace, and Spurious Enhancements

10 Installation Note N9020-90230

Option HL6, External Mixing Upgrade Kit, Serial Prefix ≥MY/SG/US5328

Analyzer Disassembly

If the instrument is placed on its face during any of the following procedures, be sure to use a soft

surface or soft cloth to avoid damage to the front panel, keys, or input connector.

If the analyzer has Option PRC, Portable Configuration, refer to the “Portable Instrument

(Option PRC)” section on page 12 to remove the outer case.

Make sure any adapters on the front panel are removed.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Keysight Technologies Strumento di misura

Keysight Technologies

Keysight Technologies EXA N9010B Manuale di installazione e funzionamento

Keysight Technologies

Keysight Technologies M9260A Guida utente

Keysight Technologies

Keysight Technologies N9030B Guida rapida

Keysight Technologies

Keysight Technologies N9020A Manuale di installazione e funzionamento

Keysight Technologies

Keysight Technologies 34980A Manuale utente

Keysight Technologies

Keysight Technologies E8364-60108 Manuale di installazione e funzionamento

Keysight Technologies

Keysight Technologies N524 A Series Manuale di installazione e funzionamento

Keysight Technologies

Keysight Technologies N9020A Manuale di installazione e funzionamento

Keysight Technologies

Keysight Technologies E4980A Guida rapida

Keysight Technologies

Keysight Technologies B1507A Manuale utente

Keysight Technologies

Keysight Technologies U5855A Manuale utente

Keysight Technologies

Keysight Technologies M9391A PXIe Manuale utente

Keysight Technologies

Keysight Technologies N9020B Manuale di installazione e funzionamento

Keysight Technologies

Keysight Technologies U4164A Manuale utente

Keysight Technologies

Keysight Technologies N9340B Manuale utente

Keysight Technologies

Keysight Technologies M9203A Guida rapida

Keysight Technologies

Keysight Technologies N5251A Series Manuale utente

Keysight Technologies

Keysight Technologies E5072A Manuale utente

Keysight Technologies

Keysight Technologies N5250C PNA Series Manuale utente

Keysight Technologies

Keysight Technologies MXA N9020A-508 Manuale utente

Keysight Technologies

Keysight Technologies N9000B Manuale di installazione e funzionamento

Keysight Technologies

Keysight Technologies N9340B Manuale utente

Keysight Technologies

Keysight Technologies N8480 Series Manuale di servizio

Keysight Technologies

Keysight Technologies X Series Manuale di installazione e funzionamento

Manuali Strumento di misura popolari di altre marche

Suaoki

Suaoki D40 Manuale utente

Elster

Elster BK-G1.6 Manuale utente

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuale

Duratool

Duratool D03128 Manuale utente

Vega

Vega VEGAPULS 65 Manuale utente

Tonghui

Tonghui TH2618B Manuale utente

Tenmars

Tenmars TM-801 Manuale utente

MSR

MSR 145 Manuale utente

TPS

TPS WP-82 Manuale utente

ELMETRON

ELMETRON CP-511 Manuale utente

PCB Piezotronics

PCB Piezotronics 003C30 Manuale utente

Tenma

Tenma 72-10465 Manuale utente

Endress+Hauser

Endress+Hauser Proline Promag 50 Specifiche tecniche

Siemens

Siemens SITRANS F Coriolis FCT030 Manuale elenco delle parti

KLINGER

KLINGER CMF V Series Manuale utente

EXFO

EXFO FTB-2 Manuale operativo e di manutenzione

Keysight

Keysight M8290A Manuale utente

ADTEK

ADTEK MW-5 Manuale utente
