Kogan KAMN24F7SA Manuale utente

24" FULL HD 75HZ FREESYNC

FRAMELESS MONITOR

(1920 X 1080)

KAMN24F7SA

• Read all instructions before using the appliance and retain for reference.

• Only use the power adapter provided with this product.

• Do not use the power adapter with any other products

• Unplug the monitor before cleaning it.

• Use a clean, slightly dampened cloth to wipe the monitor casing.

• To clean the screen, turn the monitor off, unplug it and wait for it to cool

completely. Then, wipe it with a dry micro-fibre cloth.

• Do not use cleaning alcohol, ammonia-based liquids or other harsh cleaners.

• Do not cover or block the ventilation holes in the monitor casing.

• Do not insert any object or spray any liquid into the vents.

• Do not place the monitor near heaters, stoves, fireplaces or other sources of heat,

as well as in rooms lacking adequate ventilation.

• Do not position the monitor in unsafe locations. If the monitor falls, it may be

damaged and may injure nearby people.

• Unplug the monitor if it is not going to be used for an extended period.

• Do not place heavy objects on the monitor, its power cord or any connected cable.

• Do not open the back panel of the monitor, as it contains a high-voltage current

even when not plugged in.

The Adopted Trademarks HDMI, HDMI High-Definition

Multimedia Interface and the HDMI Logo are trademarks or

registered trademarks of HDMI Licensing Administrator, Inc.

in the United States and other countries.

SAFETY & WARNINGS

Monitor

Stand arm

Stand base

Power adapter

M4x10mm Screw

VESA Screws

M4x10mm (x4)

HDMI cable

User guide

COMPONENTS

Button

Description

• Opens the OSD menu.

• Enters sub menus.

Down

Navigates down in the menu

Navigates up in the menu

Exit

Exits the menu

Power

Turns the monitor On/Off.

OVERVIEW

Monitor Ports

HDMI port

VGA port

3.5mm headphone jack

Power input port

1. Carefully remove the monitor, stand

connector and stand base from the

box.

2. Attach the stand base to the stand

arm using the supplied M4x10mm

screw.

3. Insert the stand assembly into the rear

of the monitor and push down until

firmly connected.

4. Lift the monitor up straight and remove

the bottom foam. Stand the monitor

up on the installed base.

ASSEMBLY

WARNING: The panel of the monitor is fragile. Keep the foam

underneath the screen while assembling the stand.

VESA mounting pattern 75x75mm, screw size M4.

Note: VESA mount or mounting accessories are NOT included.

1. Open the box, remove the monitor with the protection form attached and gently place

it on a desktop or table.

2. Remove any extra parts or foam covering the rear of the monitor.

3. Press the release button to remove the stand plate. If the monitor was already

attached to the stand, remove the stand.

4. Assembly the mount according to instructions provided with the mount.

Stand base

VESA MOUNT

Stand arm

Monitor

Stand plate

Mount not

included

Before connecting the monitor to your computer, please shut down the computer and

ensure the monitor is switched off.

Power Cable

Connect the included power adapter to the monitor power port, then connect the other end

to a power outlet.

HDMI

Connect the supplied HDMI cable from the computer’s HDMI port to the monitor’s HDMI

port.

HDMI Cable (included)

CONNECTIVITY

VGA

Connect a VGA cable (not included) from the computer to the monitor’s VGA port.

Earphones

Plug in earphones (not supplied) into the 3.5mm headphone jack on the monitor.

Note: If audio devices are plugged into the monitor and computer, there will be no sound.

VGA Cable (Not included)

Earphones (Not included)
