Kolcraft Jeep S45J-T Manuale utente

Jeep®Liberty 3-Wheel Stroller

Instruction Sheet

Instrucciones para carriola de 3 ruedas

Jeep®Liberty

Feuillet d'Instructions pour Poussette

à Trois Roues pour Jeep®Liberty

Avoid serious injury from falling or sliding out. Always use Restraint System.

Your child's safety depends on you. Proper stroller use cannot be assured

unless you follow these instructions. DO NOT USE STROLLER UNTIL YOU

READ AND UNDERSTAND THESE INSTRUCTIONS.

IMPORTANT SAFETY INFORMATION:

How to Keep Your Child Safe While Using this Stroller

•Adult Assembly Required.

•NEVER LEAVE YOUR CHILD UNATTENDED WHILE IN STROLLER.

Accidents can happen quickly while your back is turned. You must

always keep your child in view while your child is in the stroller,

even when sleeping. Do not use this product as a bed. Your child

may become tangled in straps or pads and suffocate.

•Always use restraint systemto keep child fromstanding up or

falling out of the stroller. Do not use product without full 5-point

Harness Restraint. Removing the shoulder straps will not

adequately restrain child.

•Always lock the stroller open before allowing your child in or near

the stroller.This prevents injuries caused by stroller collapsing.

•

Onlyuse this stroller with children who weigh less than 40 lbs. (18.1

kg)or are less than 40” (1 meter)tall,and who’s head rests below the

top of the seat back. Use by larger children may damage the stroller,

or cause a hazardous unstable condition to exist.

•

Use this stroller in the reclined position until child can sit up unassisted.

•Always set the wheel brakes when stroller is not moving,especially

on an incline.This prevents the stroller from rolling away.

•Always fasten the canopyonto the seat back when using the

stroller in the reclined position.

What to Avoid While Using this Stroller

•Always balance the weight of the stroller evenly. To prevent the

stroller from becoming unstable or tipping:

• Do not place parcels or accessory items on the stroller canopy,

seat, or over the handle.

• Do not put more than 10 lbs. (4.54 kg) in the basket.

• Do not put more than 3 lbs. (1.36 kg) in each cargo bag (select

models).

• Do not allow children to play with or hang onto the stroller.

WARNING

Continued on next page

•Never use this stroller on stairways or escalators.

•DO NOT lift by trayor toys.

•Make sure children are clear of any moving parts if you adjust the

stroller, otherwise they may be injured.

•THIS IS NOT AN EXERCISE STROLLER! Do not use this product

while running, jogging, in-line skating or participating in other

athletic activities.

•DO NOT put child in basket.

•DO NOT use any infant car seats with this stroller. Serious injury

could occur.

•Take care when folding and unfolding to prevent finger pinching.

• Product may become unstable if a parcel bag, other than the one

recommended by the manufacturer is used.

•DO NOT allow children to climb into stroller unassisted. Stroller

may tip over and injure child.

• Keep wheels at a recommended tire pressure of 35 p.s.i. (241 kPa)

(select models).

• Only use replacement parts supplied by the manufacturer. If you

have a flat tire, you may use a standard bicycle tire repair kit or

take it to a bicycle shop to be repaired.

Parts List

Stroller Frame

Front WheelRear Wheels (2)

Music On The Move®

Parent Tray

(Select Models)

Footrest

½” Screws (2)

Air Pump

(Select Models)

Brake Assembly with

Rear Axle

Front Tray

Electronic Toys

(Select Models)

Non Electronic Toys

(Select Models)

Parent Tray

(Select Models)

1” Screws (2)

Cargo Bags (2)

(Select Models)

How to Assemble Your Stroller

To Open Stroller

Remove any cardboard inserts or plastic

ties used to protect the product during

shipment.

Release the locking latch.

Unfold, making sure both side locks snap

into place.

To Assemble Rear Wheels

Remove and discard protective plastic

sleeve from ends of rear axle assembly.

Position rear brake assembly as shown,

with brake levers pointing towards

stroller handle.

Push both brake assemblies onto rear

leg tubes at the same time until spring

loaded buttons click into place.

Lay stroller on its side. Slide wheel onto

axle.

Push down on wheel until you hear a

click. Pull up on wheel to make sure it is

properly secured. If wheel pulls off, push

wheel onto axle again but push metal

clip in at the same time. Make sure

wheel is secure. Failure to secure wheels

may result in injury to your child.

Repeat for second side.

TO REMOVE WHEEL. Press metal clip in

and pull wheel off.

NOTE: Keep wheels at a recommended

tire pressure of 35 p.s.i. (241 kPa) (select

models).

To Assemble Front Wheel

1Place stroller back on handle bar.

Position front wheel assembly over front

frame tubes.

Align and push front wheel assembly on

to frame. NOTE: You may need to

depress the spring loaded buttons

slightly while assembling the tubes.

NOTE: Make sure that spring loaded

buttons pop through frame. If your

spring loaded button becomes out of

place, take pliers and feed button into

hole.

CAUTION: If spring loaded buttons DO

NOT pop through, front wheel assembly

could fall off during use.

Secure Front Wheel Assembly to the

front frame tubes using ½” screws. The

½” screws should be aligned into the 2

holes closest to the spring loaded but-

tons. Secure with a Phillips screwdriver

on both sides.

2 & 3

Spring

Loaded

Buttons

Spring

Loaded

Buttons

To Attach Footrest

4 & 5

Fold stroller (Stroller needs to be in fold

position to properly install footrest. See

page 13 for instructions on how to fold).

Align and place footrest against stroller

frame as shown making sure notch in

footrest snaps over plastic spacers

between seat support tubes.

Return stroller to open position. Lay

entire stroller back onto handle. Footrest

should remain on.

Align bosses on footrest to the two

holes on the metal frame. If bosses DO

NOT line up, the footrest is not correctly

installed. Repeat steps 1-3. If you are still

having trouble, call customer service for

assistance.

Secure footrest through bosses to

frame with 1” screws using a Phillips

screwdriver. Repeat for second side.

Feed straps of basket through slots in

footrest as shown and secure Velcro

straps.

To Attach Cargo Bags (select models)

To attach cargo bags, feed and secure

one end of Velcro strap through footrest.

Feed and secure other end of Velcro

strap through metal clip on oval tubing.

WARNING

DO NOT put more than 3 lbs.

(1.36 kg) in each cargo bag.

To Attach Non Electronic Toys

(select models)

Position toy steering wheel on front tray

as shown.

Align rear toy tabs with rear tray slots.

Hook into place.

Place your thumbs underneath tray and

with fingers, snap front portion of toy

steering wheel into front tray slots.

To remove toys from tray, press down on

front tabs to release and pull up on toys.

Rear Toy Tabs

Rear Tray Slots

Plastic Tab

1 & 2

To Attach Front Tray

Align tray between plastic tabs onto

metal tubing as shown.

Snap tab in place.

Repeat for second side.

To insert batteries, use a Phillips head

screwdriver to unfasten battery cover.

Insert batteries as shown. Requires 2

“AA” batteries (Not Included). Secure

battery cover.

Turn switch on ‘I’ to play sounds. To turn

off, move switch to ‘O’.

CAUTION: Do not mix old and new

batteries. Do not mix alkaline, standard

(carbon-zinc) or rechargeable (nickel

cadmium). Remove battery(ies) before

storing this product for a prolonged

period of time.

To Install Batteries in Electronic Toys (select models)

Place electronic toys so that they face

the child in the stroller.

Tilt toys toward stroller and align tabs

with rear tray slots. Lock tabs into slots.

Press down firmly on front of toys until

front tabs lock toys securely in place.

To remove toys from tray, press down on

front tabs to release and pull up on toys.

To Attach Electronic Toys (select models)

Attach mirror to toy as shown.

CAUTION: For your childs safety, remove

the following labels if found on this toy,

before use:

1) “Try Me” on front of unit

2) Protective film on mirror.

To Assemble Electronic Toys (select models)

To Install Batteries into

Music On The Move

®Parent Tray (select models)

Requires 4 “AA” Batteries (Not Included).

Lift up the foam padding in the bottom

of the unit.

NOTE: Foam is used to reduce skipping &

eliminate sliding of your portable unit. If your

player does not fit inside, remove foam.

Use a Phillips screwdriver to remove the

battery door.

Place batteries in the battery

compartment as shown.

Screw the battery door back onto the

unit and replace the foam.

To Attach

Music On The Move

®Parent Tray (select models)

To attach

Music On The Move

®, align tray

holes with posts on handle and snap on.

To remove

Music On The Move

®, pull

each side up and out.

WARNING

• Loud volume can damage your child’s hearing. When

turning on music, gradually adjust the volume to a

comfortable listening level so child is not startled.

• Do not place more than 3 lbs. (1.36 kg) in this tray to

avoid tipping!

• Do not place hot liquids in this tray. Hot liquids can

burn your child.

Posts

To Attach Parent Tray (select models)

Align tray holes with posts near handle

and snap on.

TO REMOVE, pull each side up and out.

For cleaning, parent tray is top rack

dishwasher safe.

WARNING

DO NOT place more than 3 lbs.

(1.36 kg) in this tray to avoid tipping!

DO NOT place hot liquids in this tray.

Hot liquids can burn your child.

How to Properly Use Your New Stroller

WARNING

Avoid serious injury from falling or sliding

out. Always use restraint system. Do not

use product without full 5-point Harness

Restraint. Removing the shoulder straps

will not adequately restrain child.

Adjust Restraint

System Harness

To Secure Child In Stroller

Lock both foot brakes to keep stroller

from rolling.

Place child in stroller.

Hook shoulder straps to waist belt.

To fasten restraint system buckles - push

together. Be sure both buckles are fas-

tened to secure child safely.

To unsnap restraint system buckles -

press tabs to release.

For proper fit, adjust shoulder straps and

waist band as shown.

To Operate Brakes

1TO LOCK BRAKE: Push 1-Touch brake

bar down to lock wheels.

TEST: Push stroller slightly to make sure

brakes are engaged.

TO UNLOCK BRAKE: Lift up on brake

bar.

Unlock

Lock

Indice

Lingue:

Altri manuali Kolcraft Passeggino

Kolcraft

Kolcraft Cloud Sport KL030 Manuale utente

Kolcraft

Kolcraft S083 Manuale utente

Kolcraft

Kolcraft Jeep Wrangler Twin Sport Series Manuale utente

Kolcraft

Kolcraft Jeep Wrangler All-Weather Umbrella Stroller Manuale utente

Kolcraft

Kolcraft Jeep Liberty 3-Wheel Stroller Manuale utente

Kolcraft

Kolcraft Jeep Liberty S45J-R7 Manuale utente

Kolcraft

Kolcraft S59-R1 Manuale utente

Kolcraft

Kolcraft Jeep Wrangler All-Weather Umbrella Stroller Manuale utente

Kolcraft

Kolcraft Jeep S45J-A-R3 Manuale utente

Kolcraft

Kolcraft Jeep S56J-R3 Manuale utente

Kolcraft

Kolcraft SPRINT pro Manuale utente

Kolcraft

Kolcraft Contours Options Manuale utente

Kolcraft

Kolcraft Travel About Series Manuale utente

Kolcraft

Kolcraft S53-R1 Manuale utente

Kolcraft

Kolcraft Contours Options Manuale utente

Kolcraft

Kolcraft Jeep S50J-R1 Manuale utente

Kolcraft

Kolcraft travel about S51-T Manuale utente

Kolcraft

Kolcraft Jeep Cherokee Sport Series Manuale utente

Kolcraft

Kolcraft Jeep Overland Limited Manuale utente

Kolcraft

Kolcraft Lite sport Manuale utente

Kolcraft

Kolcraft S64-R4 Manuale utente

Kolcraft

Kolcraft Twin Sport Series Manuale utente

Kolcraft

Kolcraft cloud PLUS Manuale utente

Kolcraft

Kolcraft Jeep Wrangler Manuale utente

Manuali Passeggino popolari di altre marche

Hauck

Hauck Priya Trioset Manuale utente

CHILDHOME

CHILDHOME CWQDN Manuale utente

Dreamer Design

Dreamer Design Rebound GST Manuale utente

Britax

Britax STEELCRAFT AGILE Manuale utente

Graco

Graco 7427 Manuale utente

Comfort

Comfort COMPASS Manuale utente

OBaby

OBaby Aura Manuale utente

Tutek

Tutek Tirso Manuale utente

Babify

Babify Dual Plus Manuale utente

Graco

Graco Stroller Manuale utente

Special Tomato

Special Tomato Jogger Manuale utente

Chicco

Chicco CORTINA TOGETHER TWO-PASSENGER STROLLER Manuale utente

Otto Bock

Otto Bock Kimba neo Manuale utente

Milly Mally

Milly Mally ROYAL Guida rapida

Hauck

Hauck DUETT 3 PRAM Manuale utente

BOB

BOB DUALLIE Manuale utente

Nuna

Nuna Pepp Manuale utente

Britax

Britax B2 Manuale utente
