LEGRAND Belanko 6 171 00 Manuale utente

87045 Limoges Cedex

Telephone: (+33) 05 55 06 87 87 - Fax:(+33) 05 55 06 88 88

Technical data sheet: F01045EN/01 Updated: 09/02/2012 Created: 13/01/2010

BelankoTM

10 AX switches small rocker

Cat. No(s): 6 171 00/01/02/03/04/05

6 171 06/07/08/09/10/15

1. USE

General lighting control mechanisms.

3. PREPARATION

3.1 General preparation (1G, 2G, 3G, 4G, 5G)

2. RANGE

Colours

- front: white

- rear: black

T084

6 171 00/01

6 171 10 6 171 15

Designation

1 gang 1 way 6 171 00 37

10 AX - 250VAC

6 171 01

6 171 02

6 171 03

6 171 04

6 171 05

6 171 06

6 171 07

6 171 08

6 171 10 111

6 171 09

6 171 15

1 gang 2 way

2 gang 1 way

2 gang 2 way

3 gang 1 way

3 gang 2 way

4 gang 1 way

4 gang 2 way

5 gang 1 way

6 gang 1 way

Intermediate

1 gang 1 way

architravete

Cat. No.

Weight

(g)

Weight

(g)

Characteristics

1/3

-flushing

mounting

box:

-surface

mounting

box:

CONTENTS

1. Use.......................................1

2. Range...................................1

3. Preparation.........................1/2

4. Overalldimensions.................2

5. Connection...........................2/3

6. Operation..............................3

7. Technical characteristics......3

8. Cleaning.................................3

9. Conformity - Approvals..................3

5. CONNECTION

5.1 Terminals

Terminal capacity:

Recommended screwdriver size: 4 mm flat blade

Recommended stripping length: 8 mm

1W switch

2W switch

6 171 10

Profile Size: 146 x 86 mm

Distance of installation hole: 120.6 mm

6 171 15

Profile Size: 34 x 86 mm

Distance of installation hole: 60.3 mm

Technical data sheet: F01045EN/01 Updated: 09/02/2012 Created: 13/01/2010

4. OVERALL DIMENSIONS

6171 00/01/02/03/04/05 /06/07/08

Profile Size: 86 x 86 mm

Distance of installation hole: 60.3 mm

3.3 Preparation with architrave

2/3

-flushing

mounting

box:

-flushing

mounting

box:

-surface

mounting

box:

-surface

mounting

box:

9.5

146

9.517

14.1

9.5 17.5

13.6

17.5

3.2 Preparation with 6G

10 AX switches small rocker

Belanko Cat. No(s): 6 171 00/01/02/03/04/05

6 171 06/07/08/09/10/15

3 x 1 mm2

3 x 1.5 mm2

1 x 2.5 mm2

1 x 4 mm2

3/3

6. OPERATION

7. TECHNICAL CHARACTERISTICS

Switch mechanism (handling force: 3.9 N)

Rocker: Polycarbonate

Frame: Polycarbonate

Base: Polyamide

Voltage: 250 VAC

Current: 10 AX

Storage temperatures: -10° C to + 70° C

7.1 Material characteristics

7.2 Electrical characteristics

7.3 Climatic characteristics

Self-extinguishing: 650° C 30s

Operating temperatures: -5° C to + 50° C

Impact test: IK04

Protection against liquids: IP40

Surface cleaning with a soft, slightly damp cloth.

Do not use: acetone, tar remover, trichloroethylene

Conform to BS EN 60669-1; MS/IEC 60669-1; SS227

7.4 Mechanical characteristics

8. CLEANING

9. CONFORMITY - APPROVALS

10AX2W 10AX2W

10AX Intermediate

Switch

5.2 Circuit diagrams (continued)

Technical data sheet: F01045EN/01 Updated: 09/02/2012 Created: 13/01/2010

10 AX switches small rocker

Cat. No(s): 6 171 00/01/02/03/04/05

6 171 06/07/08/09/10/15

BelankoTM
