Lexmark MS710 Series Guida di riferimento rapido

Media Guide

The printer supports the following paper and specialty media sizes. Select custom sizes up to the maximum measurements

specified for the Universal setting.

Paper sizes supported by the printer

Paper size1Dimensions Standard or

optional 250‑or

550‑sheet trays

Optional

2100‑sheet tray

Multipurpose

feeder

Duplex

A4 210 x 297 mm

(8.3 x 11.7 in.)

A5 148 x 210 mm

(5.8 x 8.3 in.)

A6 105 x 148 mm

(4.1 x 5.8 in.)

JIS B5 182 x 257 mm

(7.2 x 10.1 in.)

Letter 216 x 279 mm

(8.5 x 11 in.)

Legal 216 x 356 mm

(8.5 x 14 in.)

Executive 184 x 267 mm

(7.3 x 10.5 in.)

Oficio 216 x 340 mm

(8.5 x 13.4 in.)

Folio 216 x 330 mm

(8.5 x 13 in.)

Statement 140 x 216 mm

(5.5 x 8.5 in.)

Universal2105 x 148 mm to 216

x 356 mm (4.13 x

5.83 in. to 8.5 x 14 in.)

70 x 127 mm to

216 x 356 mm

(2.76 x 5 to 8.5 x 14 in.)

XX X

1If your preferred default paper size cannot be set in the printer control panel, then you may select common paper sizes that

correspond to the position of the length guide in the tray from the Paper Size/Type menu. If the paper size is not available, then select

Universal or turn off tray size sensing. For more information, contact customer support.

2To support two‑sided (duplex) printing, the Universal width must be between 105 mm (4.13 inches) and 216 mm (8.5 inches); the

Universal length must be between 148 mm (5.83 inches) and 356 mm (14 inches).

Media Guide

Page 1 of 4

Storing paper

Use these paper storage guidelines to help avoid jams and uneven print quality:

•For best results, store paper where the temperature is 21°C (70°F) and the relative humidity is 40 percent. Most label

manufacturers recommend printing in a temperature range of 18–24°C (65–75°F) with relative humidity between 40 and 60

percent.

•Store paper in cartons, on a pallet or shelf, rather than on the floor.

•Store individual packages on a flat surface.

•Do not store anything on top of individual paper packages.

•Take paper out of the carton or wrapper only when you are ready to load it in the printer. The carton and wrapper help keep

the paper clean, dry, and flat.

Avoiding jams

Load paper properly

•Make sure paper lies flat in the tray.

Correct loading of paper Incorrect loading of paper

•Do not remove a tray while the printer is printing.

•Do not load a tray while the printer is printing. Load it before printing, or wait for a prompt to load it.

•Do not load too much paper. Make sure the stack height is below the maximum paper fill indicator.

Media Guide

Page 2 of 4

•Do not slide the paper into the tray. Load paper as shown in the illustration.

•Make sure the guides in the tray or the multipurpose feeder are properly positioned and are not pressing tightly against the

paper.

•Push the tray firmly into the printer after loading paper.

•If you are loading prepunched paper for use with the staple finisher, then make sure the holes on the long edge of the paper

are on the right side of the tray. For more information, see the “Loading paper and specialty media” section of the User’s Guide.

Allow the paper to enter the optional mailbox bins properly

•When using A4‑, folio‑, or legal‑size paper, make sure to adjust the bin extender fully so that the paper enters the bin properly.

Notes:

–If the bin extender is shorter than the size of the paper you are printing on, then the paper causes a jam in the

mailbox bin. For example, if you are printing on a legal-size paper and the bin extender is set to letter-size, then a jam

occurs.

–If the bin extender is longer than the size of the paper you are printing on, then the edges become uneven and the

paper is not stacked properly. For example, if you are printing on a letter-size paper and the bin extender is set to

legal-size, then the paper does not stack properly.

Media Guide

Page 3 of 4

•If paper needs to be returned to the mailbox bin, then insert the paper under the bin arm, and then push the paper all the

way back.

Note: If the paper is not under the bin arm, then a jam occurs due to an overfilled bin.

Use recommended paper

•Use only recommended paper or specialty media.

•Do not load wrinkled, creased, damp, bent, or curled paper.

•Flex the sheets back and forth to loosen them, and then fan them. Do not fold or crease the paper. Straighten the edges on

a level surface.

•Do not use paper that has been cut or trimmed by hand.

•Do not mix paper sizes, weights, or types in the same tray.

•Make sure the paper size and type are set correctly on the computer or printer control panel.

•Store paper according to manufacturer recommendations.

Media Guide

Page 4 of 4
