4 Programmable parameters
The MFC-200/N was developed to provide the user with the greatest possible flexiblity,
such that all supervision and configuration can be executed on-site or remotely through
the existing communication channels.
We define all user-configurable parameters as follows:
Parameter:Set Point[1-12]
Options: 0 to 100%, in 1% increments.
Description: Set point for relays 1-12.
Parameter:Hysteresis[1-12]
Options: 1 to 50%, in 1% increments.
Description: Hysteresis for the activation/deactivation of relays 1-12. A hysteresis value
of at least 1% is required to prevent relays from switching on and off intermittently
whenever the indication remains over an activation threshold.
Parameter:Delay[1-12]
Options: 0.1 to 25.5 minutes, in 0.1 minute increments.
Description: Activation delay for relays 1-12.
Parameter:Forced Activation[1-12]
Options: Normal, Activated.
Description: Selects if a relay responds to level variations (Normal) or if it is constantly
activated (Activated).
Parameter:Activation Logic[1-12]
Options: Normal, Inverted.
Description: Defines whether a relay’s activation logic is Normal (relay closes when its
set point is exceeded) or Inverted (relay opens when its set point is exceeded).
Parameter:Associated Channel[1-12]
Options: 1 to 6.
Description: Input associated with a particular relay.
