Life Span TR8000i Manuale utente

TR7000i/TR8000i

Treadmill

Owner’s Manual

For safe use and product knowledge, please

completely read this product OWNER’S MANUAL

TR7000i/TR8000i

Treadmill

Welcome to LifeSpan,

Congratulations on choosing the LifeSpan Pro Series for your tness or exercise area. Performance and durability are at

the heart of each Pro Series model, which include commercial warranties that cover institutional use up to six hours per

day.

We start with a heavy gauge robotically welded steel frame, then add top-of-the-line components like a heavy-duty motor

and heavy duty deck. e results are treadmills that deliver a smooth and consistent workout for every user that will last

for years to come.

To make the Pro Series easy to use, we include our Intelli-KeyTM system that simply and easily steps the user through the

program set-up process. For motivation, we include a variety of pre-set programs, including heart rate control programs.

is gives your customers the programming variety they appreciate.

Please read this manual thoroughly before assembly and operation of your LifeSpan Pro Series treadmill. It includes

assembly and maintenance information, as well as a detailed operation guide.

To keep your treadmill in optimal condition, please pay attention to the maintenance and cleaning section of this manual.

Remember that some kinds of service should only be performed by a qualied service technician. If service is required,

please contact your authorized LifeSpan dealer. If a question or problem arises that cannot be answered by your dealer,

please complete a customer support form at www.lifespantness.com/support/customer-service:

North America:

785 West 1700 South

Salt Lake City, UT. 84104

Phone: 801.973.9993

www.LifeSpanFitness.com

International:

Contact your local distributor

Neither LifeSpan nor its representatives can accept responsibility for any damages or injury incurred as a

result of information presented in this manual except under the terms of the product warranty.

TR7000i/TR8000i

Treadmill

Welcome

Specications

Warranty Information

Important Safety Precautions

Grounding and Power Requirements

Assembly Instructions

Display Console Overview

Reading Your Heart Rate

Operating Your Treadmill

Innovative Features

Cleaning and Maintenance

Moving Your Treadmill

Belt Tension and Aligning the Running Belt

Troubleshooting

Engineering Mode

Test Mode

Table of Contents

Certications: CE/ETL US and CA /FCC Class SB EN 20957-1, EN 957-6

Large 6.5”back-lit LCD screen with scrolling alphanumeric messaging,

program prole, showing workout progress, and simultaneous display

of all readouts. Three additional LED displays with readouts for time,

speed, and incline

Program name, date and time, speed, incline, distance, calories, steps,

heart rate, and pace

Two heart rate control programs, and 42 programs grouped by

exercise motivation type for weight loss, healthy living, and sports

training

Yes

2 USB ports to automatically save your exercise data and charge your

wireless mobile device simultaneously

Grip pulse and heart rate receiver

Book, magazine, and tablet computer holder

Button lighting system prompts users through program set-up and

operations

Mechanical safety clip, when detached, immediately turns o power,

bringing the treadmill to a gentle stop

Standard and metric settings

English

22”W x 62” L (56cm W x 157.5cm L)

3.5 HP Continuous Duty AC

Multi-ply polyester belt with PVC non-slip surface

1000 lbs. (453.6 kg) thrust

3.0” (7.5cm) crown rollers keep belt centered

0.5 - 12 MPH (0.8 - 20 KPH)

0 - 15

Independent shock absorbers

1” (2.54cm) melamine laminated reversible deck medium-density

ber board

80.5” L x 36.5”W x 61” H (204.5cm L x 93.2cm W x 154.9cm H)

8” (20cm)

400 lbs. (181.4 kg)

368 lbs. (167 kg)

422 lbs. (191.8 kg)

Specications (TR7000i)

Display:

Readouts:

Programs:

Quickstart:

USB Ports:

Heart Rate:

Media Holder:

Intelli-Key™:

Emergency Stop:

Units of Measure:

Language Support:

Belt Size:

Drive Motor:

Belt Type :

Incline Motor:

Rollers:

Speed:

Incline:

Deck Suspension:

Deck:

Dimensions:

Step-Up Height:

Max. User Weight:

Net Weight:

Gross Weight:

TR7000i/TR8000i

Treadmill

Certications: CE/ETL US and CA /FCC ID: 2AB9OTR8000I/ Class SA EN 20957-1, EN 957-6

Large 6.5”back-lit LCD screen with scrolling alphanumeric messaging,

program prole, showing workout progress, and simultaneous display

of all readouts. Three additional LED displays with readouts for time,

speed, and incline

Program name, date and time, speed, incline, distance, calories, avg.

heart rate, heart rate, and pace

Two heart rate control programs, reverse walking, and 42 programs

grouped by exercise motivation type for weight loss, healthy living,

and sports training

Yes

2 USB ports to automatically save your exercise data and charge your

wireless mobile device simultaneously

Grip pulse and heart rate receiver

Book, magazine, and tablet computer holder

Button lighting system prompts users through program set-up and

operations

Mechanical safety clip, when detached, immediately turns o power,

bringing the treadmill to a gentle stop

Standard and metric settings

English

22”W x 62”L (56cm W x 157.5cm L)

5 HP Permanent Magnet AC

Multi-ply polyester belt with PVC non-slip surface

1000 lbs. (453.6 kg) thrust

3.0” (7.5cm) crown rollers keep belt centered

Forwards: 0.1 to 12 MPH / 0.2 to 20 KPH

Backwards: -0.1 to -3 MPH / -0.2 to -5KPH

3 decline - 12 incline

Independent shock absorbers

1” (2.54cm) melamine laminated reversible deck medium-density

ber board

Hospital grade cord (US/CA only)

80.5” L x 39”W x 62” H (204.5cm L x 99cm W x 157.5cm H)

9.5” (24cm)

500 lbs. (225 kg)

408 lbs. (185 kg)

454 lbs. (206 kg)

Specications (TR8000i)

Display:

Readouts:

Programs:

Quickstart:

USB Ports:

Heart Rate:

Media Holder:

Intelli-Key™:

Emergency Stop:

Units of Measure:

Language Support:

Belt Size:

Drive Motor:

Belt Type :

Incline Motor:

Rollers:

Speed:

Incline:

Deck Suspension:

Deck:

Power Cord:

Dimensions:

Step-Up Height:

Max. User Weight:

Net Weight:

Gross Weight:

Warranty Information

The LifeSpan TR7000i/TR8000i Treadmill comes with the following limited warranty.

*Warranties outside of North America may vary.

Treadmill Frame: Lifetime

Motor: Lifetime

Parts: 7 Years

Labor: 1 Year

LifeSpan warrants that the equipment it manufactures is free from defects in materials and workmanship under

normal use and services. The periods above are based on the date of purchase. During these periods, LifeSpan

will repair or replace any defective part. Free labor is included on all parts that are not normally assembled or

replaced by the customer, within the labor period.

If within the time frames specied above, any part fails to operate properly, login to our website at

www.lifespantness.com, click on Customer Support and complete the form to request assistance, or call

877.654.3839 x4 for a Customer Support Agent.

LifeSpan reserves the right to make changes and improvements to our product without incurring any obligations

to similarly alter any product purchased. In order to insure our product warranty and to ensure the safe and

ecient operation of your LifeSpan product, only authorized parts can be used. The warranty is void if any parts

other than those provided by LifeSpan are used.

Exclusions and Limitations:

• This warranty does not apply to any defects caused by negligence, misuse, improper assembly, or

maintenance, accident, or “act of God.”

• This warranty does not apply to discoloration of paints or plastics.

• LifeSpan shall not be responsible for incidental or consequential damages.

• This warranty is nontransferable from the original owner.

TR7000i/TR8000i

Treadmill

Important Safety Precautions

When using exercise equipment, basic precautions should always be followed, including:

• Never drop or insert any object into any opening. If an object falls into an opening, turn the

power o and unplug the power cord from the outlet. Remove the object or call customer

service.

• Never operate this treadmill if it has been damaged or even partially submersed in water.

• To reduce the risk of electric shock, unplug the treadmill from the wall outlet when not in use,

before performing any maintenance, or before moving the treadmill.

• Do not use outdoors or in areas of high humidity or extreme temperature changes.

• Do not lean against or climb on the treadmill.

• Wear shoes with high traction rubber soles. Do not wear shoes with heals, leather soles, cleats or

spikes.

• Do not operate where aerosol spray products are being used or where oxygen is being

administered.

• Never place the power cord under carpeting or place any object on top of the cord, this may

pinch or damage the cord causing re damage or personal injury.

• Use this exercise product for its intended use as described in this Owner’s Manual. Do not use

attachments that are not recommended by LifeSpan.

• Do not leave your treadmill running while not in use.

• Keep the treadmill on a solid surface, with the sides and front a minimum of 2 feet (0.61m)

from any walls or furniture. Make sure that the area behind the treadmill remains completely clear

during use. A minimum of 7 feet (2.1m) of clearance is required for safety reasons.

2 feet

0.61m

eet

0.61m

Running

Surface

55” x 21”

138cm x 53cm

2 f

7 feet

2.10m

Children and Pets

• Keep children from playing on your treadmill at all times.

• When in use children and pets should be kept at least 10 feet (3m) away.

• This appliance can be used by children ages 8 years and above and persons with reduced

physical, sensory or mental capabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning use of the appliance in a safe way and understand

the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance

shall not be made by children without supervision.

Other Safety Tips

• Always consult a physician before beginning this or any exercise program.

• If you experience chest pains, nausea, dizziness or shortness of breath, stop exercising

immediately and consult your physician before continuing.

• Do not wear clothing or jewelry that might catch on any part of the treadmill.

• This treadmill is equipped with a safety key. Always clip the cord that is attached to the safety key

to a part of your clothing so the key will be pulled, stopping the treadmill, in case of emergency.

Warning! Heart rate monitoring systems may not always be accurate. Over exercising may result in

serious injury or death. If you feel faint stop exercising immediately.

Note: Read all instructions and save for future use.

Safety Stop Key

• With the safety key engaged (pushed in) the treadmill is operational.

• Disengaging (pulling) the safety key turns power o to the motor making the treadmill

inoperable.

Caution:

• For your safety always attach safety key clip to an article of clothing prior to use. The safety key

clip needs to be securely attached to clothing parallel to or above the height of the safety key.

• While walking or running always use the correct ergonomic position.

• In case of emergency, grab on to the side hand rails and place your feet on the side rails located

on each side of the running belt.

• Do not walk or run backwards on the treadmill, always face forward while using the reverse

program.

• Allow the running belt to fully stop prior to getting o the treadmill.

Securely attach Safety

Key clip in case of a fall.

TR7000i/TR8000i

Treadmill

CORD SOCKET

SWITCH-

AC POWER

OVERLOAD

SWITCH

FIG. 1

FIG. 2

Grounding and Power Requirements

LifeSpan equipment must be grounded. Improper connection of the equipment’s grounding conductor

can result in the risk of electric shock. Check with a qualied electrician or service person if you are

in doubt as to whether the outlet is properly grounded. Do not modify the plug provided with the

product or use a ground plug adapter to adapt to a non-grounded outlet. If the plug will not t in the

outlet, have the proper outlet installed by a qualied electrician.

An extension cord should not be used between the equipment and the wall outlet.

The unit should not be plugged into a GFI plug or on a GFI circuit. The unit may not work as it may trip

the GFI circuit.

This product should only be run on the proper power designed for this unit. To locate the proper power

outlet for your area please refer to FIG. 2 (example for the U.S. and Canada, these units require a 115 V

NEMA 5 - 15 non GFI circuit.)

Item# Description

1 Main Frame

2 Left Accessory Tray

3 Right

4 Left Support Post

5 Right Support Post

6 Motor Cover

7 Handlebar Assembly

8 Left Support Post Cover

9 Console Access Panel

10 Console

11 Bolts M8 x 55

12 Right Support Post Cover

Accessory Tray

Tools Required

Phillips Screwdriver

5 mm Allen Wrench

6 mm Allen Wrench

Medical Handlebars

(Optional TR7000i)

(Standard TR8000i)

Assembly Instructions

At LifeSpan we strive to make our equipment easy to assemble and start using. Parts that can be pre-assembled

are always assembled and tested on the production line.

Prior to starting the assembly process take all of the parts out of the box, remove plastic bags and lay them out

on the oor to become familiar with the components.

Since your treadmill is a heavy piece of equipment it is recommended that you use two people during assembly

and follow these assembly instructions to reduce any problems that could occur.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Life Span Tapis roulant

Life Span

Life Span TR1000-TV Manuale utente

Life Span

Life Span LIFT Manuale utente

Life Span

Life Span Pursuit Max Treadmill Manuale utente

Life Span

Life Span LS Series Manuale utente

Life Span

Life Span Control Manuale utente

Life Span

Life Span LFT 05 WalkingPad M2 Manuale utente

Life Span

Life Span CHASER Manuale utente

Life Span

Life Span SPORTZ Manuale utente

Life Span

Life Span Access Manuale utente

Life Span

Life Span TR 2000-HR Manuale utente

Life Span

Life Span GOLD 2.0 Manuale utente

Life Span

Life Span PRO Series Manuale utente

Life Span

Life Span CORSAIR FREERUN 100 Manuale utente

Life Span

Life Span SPRINTER XL Manuale utente

Life Span

Life Span Workplace DT-3 Manuale utente

Life Span

Life Span Diamond Manuale utente

Life Span

Life Span TR7000iM Manuale utente

Life Span

Life Span Relay Manuale utente

Life Span

Life Span BOOMER Manuale utente

Life Span

Life Span Chaser 3 Manuale utente

Life Span

Life Span TR1200i Manuale utente

Life Span

Life Span MyTread TR100 Manuale utente

Life Span

Life Span Premier Manuale utente

Life Span

Life Span TR800-DT Manuale utente

Manuali Tapis roulant popolari di altre marche

Treadly

Treadly TREADLY 2 Manuale utente

HEALTH ONE

HEALTH ONE Walk Ro Manuale utente

NordicTrack

NordicTrack NTL12941 Manuale utente

NordicTrack

NordicTrack T7.5 S Manuale utente

Gold's Gym

Gold's Gym ADVANTAGE GGTL12920 Manuale utente

Merax

Merax MS282992 Manuale utente

FYTTER

FYTTER RU-2SX Manuale utente

Precor

Precor 903 Manuale utente

FitLogic

FitLogic freewill d225 Manuale utente

HOP-SPORT

HOP-SPORT ESTIMA HS-3200LB Manuale utente

Horizon Fitness

Horizon Fitness Adventure 5 Plus Manuale utente

Stamia

Stamia InMotion II Manuale utente

Smooth Fitness

Smooth Fitness EVO 3i Manuale utente

NordicTrack

NordicTrack NETL81810.0 Manuale utente

Schwinn

Schwinn 830/Journey 8.0 Manuale utente

Keys Fitness

Keys Fitness HealthTrainer HT-740T Manuale utente

Spirit

Spirit XT8 Manuale utente

NordicTrack

NordicTrack T 14.0 Treadmill Manuale utente
