Ordering Information

Catalog No. Finish Mounting Lamps

22SS8WH Matte White All Lytespan Track Systems. PAR38 Maximum 150W

22SS8BK Matte Black Does not mount on ProSpec Track.

22SS8AL Metallic Aluminum

1 3/4"

(44mm)

3 11/16"

(94mm)

3/16"

(5mm)

5 7/16"

(138mm)

6 7/8"

(175mm)

4 15/16"

(125mm)

1 1/16

(27mm)

5 13/16"

(148mm)

8 1/2"

(216mm)

5 1/2"

(140mm)

Lytespan®Track Lighting System 22SS8

Page 1 of 2 Alcyon™Enclosed Step Spot PAR38

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Lightolier a Genlyte company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Features

1. Track Attachment Fitting: Locking lever for mechanical/electrical

connection

2. Brass Contact: Extends for connection to second circuit

(Advent Lytespan track only)

3. Horizontal Pivot: Wireless stem profile with 365° horizontal rotation

4. Vertical Pivot: 0-90° vertical adjustment

5. Socket: Porcelain socket, medium base, nickel-plated screw shell

6. Housing: Die cast aluminum

7. Accessory Cartridge: Hinged and captive; retaining ring included

Finish

All Painted finishes are baked enamel.

Dimming

Fixture may be used on a track with a dimmer.

Consult dimmer manufacturer for correct dimmer selection.

Accessories

Accessory Holder: Integral

Accessories: Accepts two total

(1 lens + 1 louver or 2 lenses)

Lens: AF4, ADF4. Not compatible with AF4IR

Louver: AL4HC

Labels

UL, cUL

123

DFC L W DC FC L W DC FC L W DC FC L W

LAMP BeamSpread CBCP Rated

(To 50% CBCP) Life (Hrs.)

Lightolier a Genlyte company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Job Information Type:

Lytespan® Track Lighting 22SS8

Page 2 of 2 Alcyon™Enclosed Step Spot PAR38

AIMING ANGLE: 0° 30° Horizontal 30° Vertical 45° Vertical

L Beam length DDistance

WBeam Width AAiming Angle

CDistance to center beam FC Footcandles

Land Ware the outer points where the candle power

drops to 50% of the maximum. FC are the initial footcan-

dles at the center of the beam.

Lamp data shown is typical. Consult lamp manufacturers

for availability and performance. CBCP= Center Beam

Candle Power.

6’ 139 1.0’ 1.0’

8’ 78 1.4’ 1.4’

10’ 50 1.7’ 1.7’

12’ 35 2.1’ 2.1’

5’ 2.9’ 130 1.2’ 1.0’

7’ 4.0’ 66 1.6’ 1.4’

9’ 5.2’ 40 2.1’ 1.8’

11’ 6.4’ 27 2.6’ 2.2’

3’ 3.0’ 196 1.1’ 0.7’

5’ 5.0’ 71 1.6’ 1.2’

7’ 7.0’ 36 2.5’ 1.7’

9’ 9.0’ 22 3.2’ 2.2’

2’ 3.5’ 156 1.4’ 0.7’

3’ 5.2’ 69 2.1’ 1.0’

4’ 6.9’ 39 2.9’ 1.4’

5’ 8.7’ 25 3.6’ 1.7’

5,000 2,000

60W PAR16

NSP 10˚

3’ 144 1.6’ 1.6’

5’ 52 2.7’ 2.7’

7’ 27 3.8’ 3.8’

9’ 16 4.8’ 4.8’

3’ 1.7’ 94 2.2’ 1.9’

5’ 2.9’ 34 3.7’ 3.1’

7’ 4.0’ 17 5.1’ 4.3’

9’ 5.2’ 10 6.6’ 5.6’

2’ 2.0’ 115 2.3’ 1.5’

3’ 3.0’ 51 3.5’ 2.3’

4’ 4.0’ 29 4.6’ 3.0’

5’ 5.0’ 18 5.8’ 3.8’

1’ 1.7’ 163 2.7’ 1.1’

2’ 3.5’ 41 5.5’ 2.1’

3’ 5.2’ 18 8.2’ 3.2’

4’ 6.9’ 10 10.9’ 4.3’

1,300 2,000

60W PAR16

NFL 30˚

6’ 106 2.7’ 2.7’

8’ 59 3.5’ 3.5’

10’ 38 4.4’ 4.4’

12’ 26 5.3’ 5.3’

6’ 3.5’ 69 3.6’ 3.1’

8’ 4.6’ 39 4.8’ 4.1’

10’ 5.8’ 25 6.0’ 5.1’

12’ 6.9’ 17 7.2’ 6.1’

4’ 4.0’ 84 3.7’ 2.5’

5’ 5.0’ 54 4.7’ 3.1’

6’ 6.0’ 37 5.6’ 3.8’

7’ 7.0’ 27 6.5’ 4.4’

2’ 3.5’ 119 4.2’ 1.8’

3’ 5.2’ 53 6.2’ 2.7’

4’ 6.9’ 30 8.3’ 3.5’

5’ 8.7’ 19 10.4’ 4.4’

3,800 3,000

75W PAR30

NFL 25°

8’ 219 1.3’ 1.3’

12’ 97 1.9’ 1.9’

16’ 55 2.5’ 2.5’

20’ 35 3.1’ 3.1’

7’ 4.0’ 186 1.5’ 1.3’

10’ 5.8’ 91 2.1’ 1.8’

13’ 7.5’ 54 2.7’ 2.4’

16’ 9.2’ 36 3.4’ 2.9’

5’ 5.0’ 196 1.6’ 1.1’

7’ 7.0’ 101 2.2’ 1.6’

9’ 9.0’ 61 2.9’ 2.0’

11’ 11.0’ 41 3.5’ 2.4’

3’ 5.2’ 194 1.9’ 0.9’

4’ 6.9’ 109 2.6’ 1.3’

5’ 8.7’ 70 3.2’ 1.6’

6’ 10.4’ 49 3.6’ 1.9’

13,000 3,000

75W PAR30

NSP 10°

6’ 39 3.8’ 3.8’

7’ 29 4.4’ 4.4’

8’ 22 5.0’ 5.0’

9’ 17 5.7’ 5.7’

6’ 3.5’ 25 5.2’ 4.4’

7’ 4.0’ 19 6.1’ 5.1’

8’ 4.6’ 14 7.0’ 5.8’

9’ 5.2’ 11 7.8’ 6.6’

2’ 2.0’ 124 2.8’ 1.8’

3’ 3.0’ 55 4.2’ 2.7’

4’ 4.0’ 31 5.6’ 3.6’

5’ 5.0’ 20 7.0’ 4.5’

2’ 3.5’ 44 7.2’ 2.5’

3’ 5.2’ 19 10.8’ 3.8’

4’ 6.9’ 11 14.4’ 5.0’

5’ 8.7’ 7 18.0’ 6.3’

1,400 3,000

50W PAR30

FL 35°

6’ 128 1.0’ 1.0’

8’ 72 1.4’ 1.4’

10’ 46 1.7’ 1.7’

12’ 32 2.1’ 2.1’

8’ 4.6’ 47 1.9’ 1.6’

12’ 6.9’ 21 2.8’ 2.4’

14’ 8.1’ 15 3.3’ 2.8’

16’ 9.2’ 12 3.7’ 3.2’

4’ 4.0’ 102 1.4’ 1.0’

5’ 5.0’ 65 1.8’ 1.2’

6’ 6.0’ 45 2.1’ 1.5’

7’ 7.0’ 33 2.5’ 1.7’

2’ 3.5’ 144 1.4’ 0.7’

3’ 5.2’ 64 2.1’ 1.0’

4’ 6.9’ 36 2.9’ 1.4’

5’ 8.7’ 23 3.6’ 1.7’

4,600 2,500

50W PAR20

SP 10˚

4’ 116 1.9’ 1.9’

6’ 51 2.9’ 2.9’

8’ 29 3.8’ 3.8’

10’ 19 4.8’ 4.8’

3’ 1.7’ 134 2.0’ 1.7’

5’ 2.9’ 48 3.3’ 2.8’

7’ 4.0’ 25 4.6’ 3.9’

9’ 5.2’ 15 5.9’ 5.0’

3’ 3.0’ 73 3.1’ 2.0’

4’ 4.0’ 41 4.1’ 2.7’

5’ 5.0’ 26 5.1’ 3.4’

6’ 6.0’ 18 6.1’ 4.1’

1’ 1.7’ 231 2.3’ 1.0’

2’ 3.5’ 58 4.6’ 1.9’

3’ 5.2’ 26 7.0’ 2.9’

4’ 6.9’ 14 9.3’ 3.8’

1,500 2,500

50W PAR20

NFL 25˚

10’ 195 1.6’ 1.6’

15’ 87 2.4’ 2.4’

20’ 49 2.4’ 2.4’

25’ 31 3.9’ 3.9’

8’ 4.6’ 198 1.7’ 1.5’

12’ 6.9’ 88 2.5’ 2.2’

16’ 9.2’ 49 3.4’ 2.9’

20’ 11.5’ 32 4.2’ 3.6’

6’ 6.0’ 192 1.9’ 1.3’

9’ 9.0’ 85 2.9’ 2.0’

12’ 12.0’ 48 3.8’ 2.7’

15’ 15.0’ 31 4.8’ 3.3’

4’ 6.9’ 152 2.6’ 1.3’

6’ 10.4’ 60 3.8’ 1.9’

8’ 13.9’ 38 5.1’ 2.5’

10’ 17.3’ 24 6.4’ 3.1’

19,500 2,500

90W PAR38

NSP 9˚

6’ 125 3.0’ 3.0’

8’ 70 4.0’ 4.0’

10’ 45 5.0’ 5.0’

12’ 31 6.0’ 6.0’

5’ 2.9’ 117 3.4’ 2.9’

7’ 4.0 60 4.8’ 4.0’

9’ 5.2’ 36 6.1’ 5.2’

11’ 6.4’ 24 7.5’ 6.3’

3’ 3.0’ 177 3.2’ 2.1’

5’ 5.0’ 64 5.3’ 3.5’

7’ 7.0’ 32 7.4’ 4.9’

9’ 9.0’ 20 9.6’ 6.3’

2’ 3.5’ 141 4.9’ 2.0’

3’ 5.2’ 63 7.4’ 3.0’

4’ 6.9’ 35 9.8’ 4.0’

5’ 6.7’ 23 12.3’ 5.0’

4,500 2,500

90W PAR38

NFL 28˚

6’ 63 6.2’ 6.2’

7’ 46 7.3’ 7.3’

8’ 35 8.3’ 8.3’

9’ 28 9.4’ 9.4’

6’ 3.5’ 41 9.2’ 7.2’

7’ 4.0’ 30 10.7’ 8.4’

8’ 4.6’ 23 12.2’ 9.6’

9’ 5.2’ 18 13.7’ 10.8’

2’ 2.0’ 199 5.7’ 2.9’

3’ 3.0’ 88 8.6’ 4.4’

4’ 4.0’ 50 11.4’ 5.9’

5’ 5.0’ 32 14.3 7.4’

2’ 3.5’ 70 44.5’ 4.2’

3’ 5.2’ 31 66.8’ 6.2’

4’ 6.9’ 18 89.1’ 8.3’

5’ 8.7’ 11 111.3’ 10.4’

2,250 2,500

90W PAR38

WFL 55°

8’ 227 1.7’ 1.7’

12’ 101 2.5’ 2.5’

16’ 57 3.4’ 3.4’

20’ 36 4.2’ 4.2’

7’ 4.0’ 192 2.0’ 1.7’

10’ 5.8’ 94 2.8’ 2.4’

13’ 7.5’ 56 3.7’ 3.2’

16’ 9.2’ 37 4.5’ 3.9’

5’ 5.0’ 205 2.1’ 1.5’

7’ 7.0’ 105 3.0’ 2.1’

9’ 9.0’ 63 3.8’ 2.7’

11’ 11.0’ 42 4.7’ 3.3’

3’ 5.2’ 201 2.6’ 1.3’

4’ 6.9’ 113 3.5’ 1.7’

5’ 8.7’ 73 4.3’ 2.1’

6’ 10.4’ 50 5.2’ 2.5’

14,500 2,500

90W PAR38

SP 12°

6’ 139 3.2’ 3.2’

8’ 78 4.3’ 4.3’

10’ 50 5.4’ 5.4’

12’ 35 6.4’ 6.4’

5’ 2.9’ 130 3.7’ 3.1’

7’ 4.0’ 66 5.1’ 4.3’

9’ 5.2’ 40 6.6’ 5.6’

11’ 6.4’ 27 8.1’ 6.8’

3’ 3.0’ 196 3.5’ 2.3’

4’ 4.0’ 71 5.8’ 3.8’

5’ 5.0’ 36 8.1’ 5.3’

6’ 6.0’ 22 10.4’ 6.8’

2’ 3.5’ 156 5.5’ 2.1’

3’ 5.2’ 69 6.2’ 3.2’

4’ 6.9’ 39 10.9’ 4.3’

5’ 8.7’ 25 13.7’ 5.4’

4,600 3,000

120W PAR38

FL 30˚

2,000 3,000

120W PAR38

WFL 55°

4’ 125 3.7’ 3.7’

6’ 56 5.6’ 5.6’

8’ 31 7.5’ 7.5’

10’ 20 9.3’ 9.3’

3’ 1.7’ 144 4.0’ 3.2’

5’ 2.9’ 52 6.7’ 5.4’

7’ 4.0’ 27 9.4’ 7.5’

9’ 5.2’ 16 12.1’ 9.7’

3’ 3.0’ 79 7.2’ 4.0’

4’ 4.0’ 44 9.5’ 5.3’

5’ 5.0’ 28 11.9’ 6.6’

6’ 6.0’ 20 14.3’ 7.9’

1’ 1.7’ 250 10.7’ 1.9’

2’ 3.5’ 63 21.5’ 3.7’

3’ 5.2’ 28 32.2’ 5.6’

4’ 6.9’ 16 42.9’ 7.5’

10’ 250 1.7’ 1.7’

15’ 111 2.6’ 2.6’

20’ 63 3.5’ 3.5’

25’ 40 4.4’ 4.4’

8’ 4.6’ 254 1.9’ 1.6’

12’ 6.9’ 113 2.8’ 2.4’

16’ 9.2’ 63 3.7’ 3.2’

20’ 11.5’ 41 4.7’ 4.0’

6’ 6.0’ 246 2.1’ 1.5’

9’ 9.0’ 109 3.2’ 2.2’

12’ 12.0’ 61 4.2’ 3.0’

15’ 15.0’ 39 5.3’ 3.7’

4’ 6.9’ 195 2.9’ 1.4’

6’ 10.4’ 87 4.3’ 2.1’

8’ 13.9’ 49 5.7’ 2.8’

10’ 17.3’ 31 7.2’ 3.5’

25,000 3,000

120W PAR38

NSP 10˚

12’ 323 2.1’ 2.1’

16’ 182 2.8’ 2.8’

20’ 116 3.5’ 3.5’

24’ 81 4.2’ 4.2’

12’ 6.9’ 210 2.8’ 2.4’

16’ 9.2’ 118 3.7’ 3.2’

20’ 11.5’ 76 4.7’ 4.0’

24’ 13.9’ 52 5.6’ 4.8’

6’ 6.0’ 457 2.1’ 1.5’

8’ 8.0’ 257 2.8’ 2.0’

10’ 10.0’ 164 3.5’ 2.5’

12’ 12.0’ 114 4.2’ 3.0’

6’ 10.4’ 161 4.3’ 2.1’

8’ 13.9’ 91 5.7’ 2.8’

10’ 17.3’ 58 7.2’ 3.5’

12’ 20.8’ 40 8.6’ 4.2’

46,500 4,500

250W PAR38

SP 10˚

9,000 4,500

250W PAR38

FL 30°

8’ 141 4.3’ 4.3’

10’ 90 5.4’ 5.4’

12’ 63 6.4’ 6.4’

14’ 46 7.5’ 7.5’

8’ 4.6’ 91 5.9’ 5.0’

10’ 5.8’ 58 7.3’ 6.2’

12’ 6.9’ 41 8.8’ 7.4’

14’ 8.1’ 30 10.2’ 8.7’

4’ 4.0’ 199 4.6’ 3.0’

5’ 5.0’ 127 5.8’ 3.8’

6’ 6.0’ 88 6.9’ 4.5’

7’ 7.0’ 65 8.1’ 5.3’

3’ 5.2’ 125 8.2’ 3.2’

4’ 6.9’ 70 10.9’ 4.3’

5’ 8.7’ 45 13.7’ 5.4’

6’ 10.4’ 31 16.4’ 6.4’
