DEMO MANUAL DC1780A-A

DESCRIPTION

LTM4620EV: High Efficiency,

PolyPhase 50A Step-Down

Power µModule

Regulator

Demonstration circuit 1780A-A features PolyPhase

design using the LTM

4620EV, the high efficiency, high

density, dual 13A, switch mode step-down power module

regulator. The input voltage is from 4.5V to 16V. The

output voltage is jumper selectable from 1.0V to 2.5V.

DC1780A-A can deliver nominal 50Aoutput current with 2×

LTM4620sin parallel.As explainedin thedata sheet,output

current derating is necessary for certain VIN, VOUT, and

thermal conditions. The LTM4620 on DC1780A-A always

operate in continuous conduction mode. The switching

frequency can be programmed through a resistor or can

be synchronized to an external clock signal. The board

allowstheusertoprogramhowits outputvoltage rampsup

and down through the TRACK_CONTROL pin. The output

voltage is tightly regulated between “VOUT+” and “VOUT–”

through remote output voltage sensing which improves

output voltage regulation at heavy loads. These features

and the availability of the LTM4620EV in a compact 15mm

× 15mm × 4.41mm LGA package make it ideal for use in

many high-density point-of-load regulation applications.

The LTM4620 data sheet must be read in conjunction with

this demo manual prior to working on or modifying the

demo circuit DC1780A-A.

Design files for this circuit board are available at

http://www.linear.com/demo

L, LT, LTC, LTM, Linear Technology, the Linear logo, µModule and PolyPhase are registered

trademarks of Linear Technology Corporation. All other trademarks are the property of their

respective owners.

Figure 1. 50A PolyPhase LTM4620/DC1780A-A Demo Board

Downloaded from Arrow.com.

dc1780aafa

DEMO MANUAL DC1780A-A

QUICK START PROCEDURE

Demonstration circuit DC1780A-A is easy to set up to

evaluate the performance of PolyPhase operation of the

LTM4620EV. Due to the high input/output current, select

a proper input supply/load/cable which can sustain the

full load operation. Please refer to Figure 2 for proper

measurement setup and follow the procedure below:

1. Place jumpers in the following positions for a typical

1.0VOUT application:

JP1 JP2 JP4-JP8

CLK RUN VOUT SELECT

INT_CLK OFF ON JP4/1.0V

2. With power off, connect the input power supply, load

and meters as shown in Figure 2. Preset the load to 0A

and VIN supply to 12V.

3. Turn on the power supply at the input. Place JP2 to

ON position. The output voltage between VOUT+and

VOUT–should be 1.0V ± 1.5% (0.985V to 1.015V).

4. Oncetheproper outputvoltage isestablished, adjustthe

load within the operating range and observe the output

voltage regulation, output voltage ripple, efficiency

and other parameters. Output voltage ripple should

be measured at J7 with BNC cables. 50Ω termination

should be set on the oscilloscope or BNC cables.

5. (Optional) For optional load transient test, apply an

adjustable pulse signal between IOSTEP CLK and GND

testpoint.The pulseamplitude (3Vto 3.5V)sets the load

step current amplitude. The output transient current can

be monitored at the BNC connector J8 (5mV/A). The

pulse signal should be very small duty cycle (< 10%)

to limit the thermal stress on the transient load circuit.

PERFORMANCE SUMMARY

Specifications are at TA= 25°C

PARAMETER CONDITIONS/NOTES VALUE

Input Voltage Range 4.5V to 16V

Output Voltage VOUT VIN = 4.5V to 16V, IOUT = 0A to 50A, JP4: 1.0V 1.0V ± 1.5% (0.985V to 1.015V)

Maximum Continuous Output Current Derating is necessary for certain VIN, VOUT and thermal

conditions, see data sheet for detail.

50A

Default Operating Frequency 500kHz

Resistor Programmable Frequency Range 400kHz to 780kHz

External Clock Sync. Frequency Range 400kHz to 780kHz

Efficiency VIN = 12V, VOUT = 1.0V, IOUT = 50A, fSW = 500kHz 82.4% See Figure 4

Load Transient VIN = 12V, VOUT = 1.0V, ISETP = 25A to 50A <138mV, See Figure 5

Output Voltage Ripple VIN = 12V, VOUT = 1.0V, IOUT = 50A <10mV, See Figure 6

Table 1. LTM4620 Demo Cards for up to 100A Point-of-Load Regulation

MAXIMUM

OUTPUT CURRENT

NUMBER OF OUTPUT

VOLTAGES

NUMBER OF LTM4620 μMODULE

REGULATORS ON THE BOARD DEMO CARD NUMBER

13A, 13A 2 1 DC1498A

50A 1 2 DC1780A-A

75A 1 3 DC1780A-B

100A 1 4 DC1780A-C

Downloaded from Arrow.com.Downloaded from Arrow.com.

dc1780aafa

DEMO MANUAL DC1780A-A

Figure 2. Test Setup of DC1780A-A

* Note: The output current is measured with a mV-voltage meter across a 1% accurate shunt resistor.

QUICK START PROCEDURE

6. (Optional) LTM4620 can be synchronized to an external

clock signal. Place the JP1 jumper on EXT_CLK and

apply a clock signal (0V to 5V, square wave) on the

EXT_CLK test point.

7. (Optional) The outputs of LTM4620 can track another

supply. The output voltage tracks the voltage on

TRACK_CONTROL when a valid signal is applied on

the test point.

8. (Optional) DC1780A-A can be configured to a dual

outputs configuration with VOUT at 37A load current

and VOUT2 at 13A load current. Stuff 0 resistor on

R61 and 0.1µF on C14. Remove R22, R23, R24, R26,

R27, R28, R32, R33, R35. Output voltage VOUT2 is set

by R37 based on the equation VOUT2 = 0.6V(1 + 60.4k/

R37).

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

dc1780aafa

DEMO MANUAL DC1780A-A

QUICK START PROCEDURE

Figure 3. Measured Efficiency VIN = 5V, fSW = 500kHz Figure 4. Measured Efficiency VIN = 12V, fSW = 500kHz

LOAD CURRENT (A)

EFFICIENCY (%)

100

60 4010

DC1780A-A F03

503020

VIN = 5V, VOUT = 2.5V

VIN = 5V, VOUT = 1.8V

VIN = 5V, VOUT = 1.5V

VIN = 5V, VOUT = 1.2V

VIN = 5V, VOUT = 1V

LOAD CURRENT (A)

EFFICIENCY (%)

100

60 4010

DC1780A-A F04

503020

VIN = 12V, VOUT = 2.5V

VIN = 12V, VOUT = 1.8V

VIN = 12V, VOUT = 1.5V

VIN = 12V, VOUT = 1.2V

VIN = 12V, VOUT = 1V

Figure 5. Load Transient 25A to 50A (VIN = 12V, VOUT = 1V) Figure 6. Measured Output Voltage Ripple at 12VIN, 1VOUT,

50A on J7 with Standard Demo Circuit Default Setup

DC1780A-A F05

1V OUTPUT (20MHz BW)

100mV/DIV

25A TO 50A LOAD

DC1780A-A F06

1V OUTPUT (20MHz BW)

10mV/DIV

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

dc1780aafa

DEMO MANUAL DC1780A-A

Figure 7. Thermal Capture at 12VIN, 1.0VOUT at 50A (Ambient

Temperature = 23.3°C, No Airflow and No Heat Sink)

Figure 8, Thermal Capture at 12VIN, 1.0VOUT at 50A (Ambient

Temperature = 23.3°C, 200LFM Airflow and No Heat Sink)

QUICK START PROCEDURE

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

dc1780aafa

DEMO MANUAL DC1780A-A

PARTS LIST

ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER

Required Circuit Components

1 8 CIN3, CIN4, CIN5, CIN6, CIN7, CIN8, CIN9, CIN10 Cap., X5R 22µF 25V 10% 1210 Murata GRM32ER61226KE15

2 4 COUT1, COUT7, COUT11, COUT15, Cap., X5R 100µF 10V 20% 1210 Taiyo Yuden LMK325BJ107MN-T

3 4 COUT4, COUT10, COUT12, COUT19 Cap., POSCAP 470µF 4V 20% 7343 SANYO 4TPE470MCL

4 1 R14 Res., Chip 90.9k 0.06W 1% 0603 Vishay CRCW060390K9FKEA

5 2 R9, R31 Res., Chip 121k 0.06W 1% 0603 Vishay CRCW0603121KFKEA

6 2 R1, R3 Res., Chip 10 0.06W 5% 0603 Vishay CRCW060310R0JNEA

7 2 C4, C10 Cap., X5R 2.2µF 10V 20% 0603 Taiyo Yuden LMK107BJ225MA

8 1 C7 Cap., X7R 0.1µF 25V 10% 0603 AVX 06033C104KAT2A

9 2 U1, U2 I.C., Volt. Reg. LGA(144)

15MMX15MMX4.41MM(1873-REV0)

Linear Technology Corp.

LTM4620EV

Additional Demo Board Circuit Components

10 1 C25 Cap., X7R 0.1µF 25V 10% 0603 AVX 06033C104KAT2A

11 2 COUT5, COUT18, COUT24, COUT38 Cap., X5R 100µF 10V 20% 1210 Taiyo Yuden LMK325BJ107MN-T

12 2 COUT6, COUT25 Cap., POSCAP 470µF 4V 20% 7343 SANYO 4TPE470MCL

13 1 R15 Res., Chip 60.4k 0.06W 1% 0603 Vishay CRCW060360K4FKEA

14 1 R16 Res., Chip 40.2k 0.06W 1% 0603 Vishay CRCW060340K2FKEA

15 1 R17 Res., Chip 30.1k 0.06W 1% 0603 Vishay CRCW060330K1FKEA

16 1 R18 Res., Chip 19.1k 0.06W 1% 0603 Vishay CRCW060319K1FKEA

17 6 R2, R21, R39, R43, R47, R51 Res., Chip 121k 0.06W 1% 0603 Vishay CRCW0603121KFKEA

18 2 R25, R29 Res., Chip 10 0.06W 5% 0603 Vishay CRCW060310R0JNEA

19 2 C18, C22 Cap., X5R 2.2µF 10V 20% 0603 Taiyo Yuden LMK107BJ225MA

20 1 CIN1 Cap., Alum 150µF 25V 25% SUNCON-8 SUNCON 25CE150AX

21 2 CIN2, CIN11 Cap., X5R 1µF 25V 10% 1210 Taiyo Yuden TMK325BJ105KM

22 4 R22, R23, R24, R26 Res., 0Ω 2010 TEPRO(NAKOMA) RNH6083

23 2 R56, R57 Res., 0.010 2W 1% 2512 Vishay WSL-2512-R01000-F-EA

24 0 R58, R59 (OPT) Res., 2512

25 1 R60 Res/Jumper, Chip 0 1/4W 1A 1206 Vishay CRCW12060000ZOEA

26 4 R4, R36, R41, R54 Res., Chip 10k 0.06W 5% 0603 Vishay CRCW060310K0JNEA

27 0 R5, R7, R8, R10, R13, R30, R34, R37, R38, R42,

R44, R48, R49, R50, R52, R53, R55, R61 (OPT)

Res., 0603

28 13 R6, R19, R20, R27, R28, R32, R33, R35, R40, R45,

R46, R62, R63,

Res/Jumper, Chip 0 1/16W 1A 0603 Vishay CRCW06030000Z0EA

29 0 COUT23, COUT29, COUT31, COUT37 (OPT) Cap., “D” Case 7343

30 0 C1, C2, C3, C5, C8, C9, C12, C13, C14, C15, C16,

C17, C20, C21, C26, C29, C30 (OPT)

Cap., 0603

31 6 C6, C11, C19, C23, C27, C28 Cap., X7R 1µF 10V 10% 0603 Taiyo Yuden LMK107BJ105KA

32 1 C24 Cap., X7R 0.01µF 100V 10% 0603 AVX 06031C103KAT2A

33 2 Q1, Q2 Mosfet N-channel, 30V DPAK(TO-252) Vishay Siliconix SUD50N03-09P

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

dc1780aafa

DEMO MANUAL DC1780A-A

PARTS LIST

ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER

34 0 COUT2, COUT3, COUT8, COUT9, CIN12, COUT13,

CIN13, COUT14, CIN14, CIN15, COUT16, CIN16,

COUT17, CIN17, CIN18, CIN19, COUT20, COUT21,

COUT22, COUT26, COUT27, COUT28, COUT30,

COUT32, COUT33, COUT34, COUT35, COUT36 (OPT)

Cap., 1210

Hardware for Demo Board only

35 3 XJP1, XJP2, XJP4 Shunt, 2mm Ctrs. Samtec 2SN-BK-G

36 4 MH1-MH4 STAND-OFF, NYLON 0.5" Tall KEYSTONE, 8833 (SNAP ON)

37 2 J7, J8 BNC Connector Connex 112404

38 2 JP1, JP2 Headers, 3 Pins 2mm Ctrs. Samtec TMM-103-02-L-S

39 5 JP4, JP5, JP6, JP7, JP8 Jumper, 2 Pins 2mm Ctrs. Samtec TMM-102-02-L-S

40 6 J1, J2, J3, J4, J5, J6 Stud, Test Pin PEM KFH-032-10

41 11 E1, E2, E3, E4, E6, E7, E8, E9, E12, E13, E22 Turret, Test Point Mill Max 2308-2-00-80-00-00-07-0

42 0 E5, E10, E11, E14, E15, E16, E17, E18 (Opt) Test Point

43 2 E19, E20 Turret, Test Point Mill Max 2501-2-00-80-00-00-07-0

44 12 NUT, BRASS NUTS #10-32 ANY, #10-32

45 6 RING, LUG RING # 10 KEYSTONE, 8205

46 6 WASHER, #10, Tin Plated Brass ANY, #10 EXT BZ TN

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

dc1780aafa

DEMO MANUAL DC1780A-A

SCHEMATIC DIAGRAM
