Linksys EC1000 Manuale operativo

Model No.

Product Data

WIRED

EC1000

Gigabit networking for ExpressCard notebook!

10/100/1000Mbps Ether-

net network interface for

ExpressCard slots

Automatically adjusts to

10Mbps, 100Mbps, or

Gigabit network speeds

Integrated pop-up con-

nector folds flat when

not in use -- no dongles

to lose or break

Low power con-

sumption con-

serves battery life

The Linksys Gigabit ExpressCard Adapter is the

simple, reliable way to get your notebook

connected to a gigabit network. It fits in either

an ExpressCard/34 or ExpressCard/54 slot, and

the RJ-45 network connector is integrated into

the card, so there's no dongle to lose or

break. The pop-up connector folds flat when

not in use for easier storage.

The card automatically negotiates for the net-

work's best speed: 10, 100, or a screaming

1000 megabits per second. The card sup-

ports 802.1p traffic prioritization, and has auto-

matic MDI/MDI-X crossover detection at all

speeds, so you don't have to worry about the

cable type. The easy-to-read LEDs let you

know the link status, your link speed, and net-

work activity. Ultra-low power consumption

minimizes drain on your notebook's battery

life.

Let the Linksys Gigabit ExpressCard Adapter

help you get your notebook connected to

gigabit networks.

Gigabit ExpressCard Adapter

Product Data

Model No.

Features

• Compliant with ExpressCard

standard

• PCI-Express interface with

2.5Gbps signaling

• 10/100/1000Mbps data rate

auto-negotiation

• Automatic MDI/MDIX cross-

over at all speed

• Compact and robust design

perfect solution for all network

users, both desktop and

mobile

• Wake On LAN (WOL) power

management support

Linksys

A Division of Cisco Systems, Inc.

18582 Teller Avenue

Irvine, CA 92612 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional Offices

throughout the world. For a complete list of local

Linksys Sales and Technical Support contacts, visit

our Worldwide Web Site at www.linksys.com.

EC1000

Gigabit ExpressCard Adapter

Specifications

Standards IEEE 802.3, 802.3u, 802.3x, 802.3ab, and 802.3z

Ports 1 RJ-45 Ethernet port

Cabling Type Category 5e or better

LED Indicators 10/100/1000

Connector Type RJ-45, PCI-Express

Environmental

Dimensions 1.34" x 0.20" x 4.25"

(W x H x D) (34 mm x 5 mm x 108 mm)

Unit Weight 0.9 oz (25.51g)

Power 3.3V Power Consumption:

Active: Tx: 600 mA (Maximum)

Rx: 600 mA (Maximum)

Idle: 150 mA (Maximum)

Certifications FCC Part15 Class B /CE/VCCI and ICES-003

Operating Temp. 0ºC to 40ºC (32ºF to 104ºF)

Storage Temp. 0ºC to 70ºC (32ºF to 158ºF)

Operating Humidity 0% to 90% Non-Condensing

Storage Humidity 0% to 90% Non-Condensing

EC1000-DS-51129 KL

Package Contents

• EC1000 Gigabit ExpressCard Adapter

• Start Here Folder with Setup Wizard CD

•Networkcable

Minimum Requirements

• Notebook with PCI-Express slot

• Windows 98SE/ME/2000/XP

• CD-ROM Drive

Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2005
