Linksys ProConnect USBHUB04 Manuale utente

USB 4-Port

Hub

o you have a USB port on your com-

puter? The USB 4-Port Hub from

Linksys offers instant connectivity for

up to four USB devices. Plug in peripherals like

digital cameras, modems, printers, mice, key-

boards, scanners, and portable data storage

devices in seconds. Ready to run right out of

the box, the 4-Port Hub makes high-speed, low-

cost expansion a snap. Equipped with advanced

hot swap technology, the hub even lets you

attach or detach USB devices while your com-

puter is on, making it possible to switch devices

on the fly! The 4-Port hub offers data transfer

rates of up to 12Mbps, which makes it perfect

for speed-hungry multimedia, gaming, and

Ethernet networking applications. For added

expandability, you can daisy-chain the 4-Port

Hub to additional USB hubs - you can use up to

127 USB devices at the same time! Expand the

capabilities of your PC or Macintosh in one

easy step -- it’s never been easier to connect your

peripheral devices!

• Use Up to 4 Universal Serial Bus Devices

Simultaneously by Connecting the USB Hub to

Your PC’s USB Port

• Offers Simultaneous Access to All Peripheral

Devices -- Printers, Scanners, Mice and More

• Ready to Run With Any USB-Equipped PC,

Notebook, iMac or Power Macintosh G3

• Fast Data Transfer Rate of 12Mbps

• No Memory Addresses or Interrupt

Assignments Required -- Just Plug Them

Into the Hub!

• Fully Hot Swappable -- Attach or Remove

Devices with Power On

• Connect up to 127 USB Devices

• Runs in Bus-Powered or Self-Powered Mode

• Free Technical Support

• 1-Year Limited Warranty

•Connect Any USB Devices -- Digital

Cameras, Joysticks, Network Adapters,

Modems, Disk Drives and More!

•Use Four USB Devices Simultaneously

From Any USB-Ready PC or Macintosh

•Offers Low-Cost and Easy Expansion for

Notebook and Desktop Computers

•Constant Connections LetYou Hot Swap

Peripherals Without TurningYour PCs Off

•Free Technical Support

•1-Year Limited Warranty

UUSSBB44--PPoorrttHHuubb((UUSSBBHHUUBB0044))

Instantly Connect Up to 4 Universal Serial Bus Devices

toYour USB-Ready Notebook or Desktop Computer

ExpandwithUSB!

Features

Benefits

Specifications

Standards OHCI, UHIC, and USB Standard v1.1

Protocol CSMA/CD

Ports 1 USB Root Port

4 USB Device Ports

Transfer Rate 12Mbps (High Speed, Self-Powered)

1.5Mbps (Low Speed, Host Powered)

Max. Devices 127 (Daisy-chaining Hubs Together)

Cabling Standard Shielded USB Cable

5 meters (16.4 feet) Maximum

LEDs Power (PWR),

RDY/OVR per Port

Environmental

Dimensions 140mm x 75mm x 35.5mm

Unit Weight 5.2 oz.

Power Input 6V Bus Power in Host-Powered Mode

6V DC, 2.1A Max. in Self-Powered Mode

Certifications FCC Class B

CE Mark, Commercial

Operating Temp. 32ºF to 104ºF (0ºC to 40ºC)

Storage Temp. -4ºF to 158ºF (-20ºC to 70ºC)

Operating Hum. 10% to 85% Non-Condensing

Storage Hum. 5% to 90% Non-Condensing

Package Contents

USB 4-Port Hub

• USB 4-Port Hub

• 5-foot USB Cable

• AC Power Adapter

• One User Guide and Registration

Card

(Model No.: USBHUB04)

Linksys

17401 Armstrong Ave.

Irvine, CA 92614 USA

Information (800) 546-5797

Technical Support (800) 326-7114

(949) 261-1288

Fax (949) 261-8868

World Wide Web http://www.linksys.com

Email [email protected]

[email protected]

China

Tech Support (10) 6432 1920

Sales (10) 6432 1923

Fax (10) 6437 6891

Germany

Telephone (0) 8166 684279

Fax (0) 8166 68274

Japan

Telephone (03) 5259-5139

Fax (03) 5259-5117

Singapore

Telephone 552-8998

Fax 552-1024

Thailand

Telephone 717-0770

Fax 717-0738

United Kingdom

Tech Support 0870 7393939

Sales 01245 352403

Fax 0870 7393938
