5-Port 10/100 Switch

This newly redesigned Linksys 5-Port 10/100 Switch

can significantly increase your network traffic’s

speed. A switch serves the same function as a hub in

a network design—tying your network equipment togeth-

er. But unlike a simple-minded hub which divides the net-

work’s bandwidth among all the attached devices, a

switch delivers full network speeds at each port. Installing

this cost-effective 5-Port 10/100 Switch can potentially

increase your network speed by five times!

It’s the perfect way of integrating 10Mbps Ethernet and

100Mbps Fast Ethernet devices, too. All five ports are auto

speed negotiating, and have automatic MDI/MDI-X

crossover detection, so you don’t have to worry about the

cable type. Each port independently negotiates for best

speed and half- or full-duplex mode, for up to 200Mbps of

bandwidth per port. Fast store-and-forward switching pre-

vents damaged packets from being passed on into the net-

work.

The new ultra-compact case design is sure to fit into your

workgroup environment. Let the Linksys 5-Port 10/100

Switch kick your 10/100 network into high gear.

• Ideal for Integrating Your 10BaseT and 100BaseTX

Network Hardware

• Five 10/100 Ports Provide Dedicated Bandwidth in Half-

or Full-Duplex Modes

• Each Port Supports Auto MDI/MDI-X Cable Detection

• Compatible with All Major Network Operating Systems

• Advanced Store-and-Forward Packet Switching

Optimizes Data Transfers

• Auto Partitioning Protects PCs from Downed Network

Lines

• Signal Regeneration Ensures Data Transfer Integrity

• Free Technical Support—24 Hours a Day, 7 Days a

Week, Toll-Free US Calls

• Limited Lifetime Warranty

5-Port 10/100 Switch

Model No.: SD205

High-speed 10/100 switching for your desktop

Features

Benefits

• Five auto-sensing, 10/100 ports with auto

MDI/MDI-X crossover detection

• Up to 200Mbps, full-duplex bandwidth at

each port

• Address Learning and Aging, and Data

Flow Control for enhanced transmission

reliability

• Compact size fits into any environment

Specifications

Model SD205

Standards IEEE 802.3, IEEE 802.3u

Ports Five RJ-45 10/100

Cabling Type Category 5 Ethernet

LEDs System, Port Status 1, 2, 3, 4, and 5

Environmental

Dimensions 3.66" x 1.18" x 3.54"

(93 mm x 30 mm x 90 mm)

Unit Weight 8 oz. (0.23 kg)

Power DC 12V, 500 mA

Certification FCC Class B, CE

Operating Temp. 0ºC to 50ºC (32ºF to 122ºF)

Storage Temp. -40ºC to 75ºC (-40ºF to 158ºF)

Operating Humidity 20% to 95%, Non-Condensing

Storage Humidity 5% to 90%, Non-Condensing

Package Contents

5-Port 10/100 Switch

• One SD205 5-Port 10/100 Switch

• One Power Adapter

• One Printed User Guide

• One Registration Card

• 200MHz or Faster Processor

• 64MB RAM Recommended

• Ethernet Adapter Capable of 10Mbps

• Windows 95/98/Me/NT 4.0/2000/XP

Minimum Requirements

SD205-DS-30522NC JL

Linksys

World Headquarters:

17401 Armstrong Ave.

Irvine, CA 92614 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional

Offices throughout the world. For a complete

list of local Linksys Sales and Technical

Support contacts, visit our Worldwide Web Site

www.linksys.com

Specifications are subject to change without notice. Instant Wireless, Linksys, and the Linksys logo are registered trademarks of Linksys Group, Inc. Other brands and product names are trademarks or regis-
