BUSINESS SERIES

PRODUCT DATA

24-Port 10/100 Switch

Model: SR224R

High-speed 10/100 Switching for

Rackmount or Desktop Installations

With its advanced switching technology, the Linksys 24-Port 10/100 Switch will boost

your network performance with much more than just full duplex data transfer and

dedicated bandwidth. It features non-blocking, wire-speed switching that forwards

packets as fast as your network can deliver them. Also included are Address Learning

and Aging to prevent data transfer errors and Data Flow Control to help prevent packet

collisions.

The SR224R is designed to fit in a standard equipment rack using the included rack mount

brackets. However, its minimal depth and fanless design makes it suitable to be located

anywhere.

No matter how intensive your network demands, the Linksys 24-Port 10/100 Switch has

speed, flexibility, and reliability that you can count on.

24 Autosensing 10/100 full

duplex, auto MDI/MDI-X

ports

Runs at non-blocking, full

wire speeds up to 200Mbps

Address Learning and

Data Flow Control for

transmission reliability

Suitable for both desktop

or rackmount installations

SR224R

PRODUCT DATA

BUSINESS SERIES

Linksys

A Division of Cisco Systems, Inc.

121 Theory

Irvine, CA 92617 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more

than 50 countries, supported by

12 Linksys Regional Offices throughout

the world. For a complete list of local

Linksys Sales and Technical Support

contacts, visit our Worldwide Web Site

at www.linksys.com.

Check the product package and contents for specific features supported. Specifications are subject to change without notice. Linksys is a registered trademark or

and product names are trademarks or registered trademarks of their respective holders.

7012910NC-RR Model: SR224R

Features

Ideal for integrating your

10BaseT and 100BaseTX

network hardware

24 10/100 Ports provide

dedicated bandwidth in Half

or Full-Duplex Modes

Switched 10/100 ports

run at up to 200Mbps in

Full-Duplex mode

Each port supports Auto

MDI/MDI-X cable detection

Compatible with all major

network operating systems

Advanced Store-and-

Forward packet switching

optimizes data transfers

Auto partitioning protects

PCs from downed network

lines

Signal regeneration ensures

data transfer Integrity

Free Technical Support—24

Hours a Day, 7 Days a Week,

Toll-Free US Calls

Limited lifetime warranty

•

24-Port 10/100 Switch

Specifications

Model SR224R

Standards IEEE 802.3, IEEE 802.3u

Ports 24 10/100 RJ-45 Ports

Cabling Type Category 5 or better

LEDs System, 1-24

Switching Capacity 4.8 Gbps, non-blocking

Security features Security lock slot

Environmental

Dimensions 16.93" x 1.75" x 7.97"

W x H x D (430 x 44.5 x 202.5 mm)

Unit Weight 4.41 lb (2 kg)

Power 100V ~ 240V AC, Internal 3.3V/5A

Certification FCC Class A, CE

Operating Temp. 32 to 104ºF (0 to 40ºC)

Storage Temp. -40 to 158ºF (-40 to 70ºC)

Operating Humidity 20% to 95% relative humidity, noncondensing

Storage Humidity 5% to 90% noncondensing

Package Contents

SR224R 24 Port 10/100 Switch

User Guide

AC Power Cord

Online Registration Card

•
