Loctite Zeta 7021 Manuale utente

Loctite®

Zeta®7021 Spot Radiometer

Part Number 98048

EQUIPMENT

Operation Manual

985706 Zeta 7021 Rev A 4/17/02 4:15 PM Page 1

Contents

Page No.

1 Please observe the following. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

1.1 Emphasized Sections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

1.2 For Your Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

1.3 List of Parts Supplied . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

2 Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6

2.1 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8

3.1 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3.2 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

4 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

4.1 Unpacking and Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

4.2 Installation and Start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

5 Operations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

5.1 Controls and Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

6 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

7 Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

7.1 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

8 Spare Parts List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

9 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

985706 Zeta 7021 Rev A 4/17/02 4:15 PM Page 2

1. Please Observe the Following

1.1 Emphasized Sections

Warning!

Refers to safety regulations and required safety measures that protect the

operator or other persons from injury or danger to life.

Caution!

Emphasizes what must be done or avoided so that the unit or other

property is not damaged.

Notice:

Gives recommendations for better handling of the unit during operation or

adjustment as well as for service activities.

1.2 For Your Safety

IMPORTANT! DO NOT OPERATE THE UNIT BEFORE READING

THIS SECTION.

The Loctite®UV Spot Radiometer will be used to measure the output of UV

Wand Products. Always assure that the Wand is held securely in the Wand

Sensor Head, and inserted to the stop inside the Sensor Head.

☞

985706 Zeta 7021 Rev A 4/17/02 4:15 PM Page 3

1. Please Observe the Following (continued)

1. UV protective glasses with side shields should be worn when working

with and around UV Wand systems. Glasses should meet ANSI Z87.1

certification. UV protective glasses should be available with the system

being tested. If they are not available, they may be purchased from

Loctite. Safety Glasses Item # 97210.

2. Potentially exposed skin should be covered. Long sleeves and

protective gloves should be worn when measuring UV Wand intensity.

3. Never look directly at the output from the UV Wand.

4. Make Sure that the Radiometer reading is Zero, before removing the

UV Wand from the Sensor Head.

When in doubt about UV safety, consult a Loctite technical specialist at:

1-800-LOCTITE (562-8483).

1.3 List of Parts Supplied

• UV Sensor Head

• Meter

• Operators Manual

985706 Zeta 7021 Rev A 4/17/02 4:15 PM Page 4

2. Description

The ZETA®7021 spot Radiometer Measures the UV Intensity emitted from

a 3 mm or a 5 mm UV wand. The Intensity is measured from

280-400 nm (UV A+B). The Radiometer is traceable to the National

Institute of Standards and Technology (NIST).

985706 Zeta 7021 Rev A 4/17/02 4:15 PM Page 5

2. Description (continued)

Spectral Response:

Peak Response:

Accuracy:

Sensor:

Power:

Irradiance Range:

Resolution:

280-400nm ( V A+B)

370nm

±5% to 10% max.

GaAsP Photodiode

9V Battery

0-19.99W/cm

10mW/cm

0.00

Sensor Connector

Panel

Magnet

Digital Panel Meter Display

On/Off

Rocker

Switch

Front View Side View Back View

Top Cover Battery Door

Figure 1.

985706 Zeta 7021 Rev A 4/17/02 4:15 PM Page 6

2. Description (continued)

Sensor Head Assembly

Sensor Head Cap

Sensor Head

Magnet

3mm and 5mm Light Guide

Sensor Plug

Filter Glass

Figure 2.

985706 Zeta 7021 Rev A 4/17/02 4:15 PM Page 7

2. Description (continued)

2.1 Operation

The Loctite®UV Spot Radiometer is well suited for most production

operations. The UV Spot Radiometer can be used to verify that the output

from the wand system, under test, is proper for the curing process. When

making measurements the wand should be held as straight as possible,

and the ends should be clean.

985706 Zeta 7021 Rev A 4/17/02 4:15 PM Page 8

3.1 Specifications

Loctite Model: ZETA®7021

Loctite Part Number: 98048

Electrical Power Required: 9 Volt Alkaline Battery (Not Included)

Dimensions L x W x D (inches): 3.0" x 2.5" x 1.05"

Total Weight: 5.6 oz.

Spectral Range: 280-400 nm (UV A+B)

Range: 0-19.99 Watts/cm-squared

Resolution: 10 mw/cm-squared

Accuracy: +/-5% typical; +/-10% max.

Traceable to

(NIST)

Wand Choices: 3 mm and 5 mm

3. Technical Data

985706 Zeta 7021 Rev A 4/17/02 4:15 PM Page 9

3.2 Calibration

The ZETA®7021 has been factory calibrated, prior to shipment, directly to

the National Institute of Standards and Technology (NIST) primary physical

standard for UV photodiodes.

The recommended calibration frequency is every 12 months.

Contact Loctite Corporation at 1-800-571-5174 for re-calibration services.

3. Technical Data (continued)
