Logitech UE6000 Manuale utente

Setup Guide

6000

设置指南

UE 6000

English. . . . . . . . . . . . . . . . . . 3

简体中文 . . . . . . . . . . . . . . . . . 9

UE 6000

English 3

AAA

Setup Guide

6000

2 4 7

Package contents

1. Headphones

2. Detachable audio cable with

in-line remote

3. Travel case

4. Sharing splitter

5. 2 AAA alkaline batteries

(pre-installed)

6. Y-cable adapter

7. ¼-inch (6.35 mm) adapter

8. Documentation

设置指南

UE 6000

4 English

Know your product

1. Adjustable headband

2. Memory foam cushions

3. Battery LED

4. On/O slider

5. Volume up

6. Media/calling controls

•One click:

Play/pause (audio)

Call answer/hang up (phone)

•Double click:

Next track (audio)

•Triple click:

Previous track (audio)

•One click, then click and hold:

Fast forward (audio)

•Two clicks, then click and hold:

Rewind (audio)

•Click and hold:

Activate/deactivate voice dial1

7. Volume down

8. Microphone

9. Battery door release (Press button

toopen battery door.)

10. Battery compartment

11. 3.5 mm input

1 Function varies by phone. Activates Siri® on iPhone® 4S.

UE 6000

English 5

Set up your product

1. Pull the tab to activate batteries.

2. Move the slider to “On.” The Battery

LED turns green to indicate Active Noise

Cancellation mode.

3. Connect the headphone to begin

listening to music.

For devices with a ¼-inch (6.35 mm) input

jack, use the ¼-inch (6.35 mm) adapter.

For PC with headphone and microphone

jacks, use the Y-cable adapter to chat or

make calls. (Works with most PCs.)

Note: When using on a PC, the media/calling

controls will not work.

UE 6000

6 English

Product features

Answering a call

• On your phone, the music fades and

a ring tone sounds.

• You can pick the call up on your phone

or press the center button.

• To hang up, press the center button.

Sharing your music

1. Remove the cap.

2. Plug in the sharing splitter and connect.

Listen to music together.

Active Noise Cancellation

Battery LED

No light: headphone o

Green: Power on; batteries good

Red: Low power; change the batteries

If the power runs out, Active Noise

Cancellation ends and music stops.

Move the slider to the “O” position

to keep listening to music (without Active

Noise Cancelling and equalization).

Replace batteries for optimal performance.

Storage

The headphone folds easily for storage.

UE 6000

English 7

Visit Product Central

There’s more information and support

online for your product. Take a moment

tovisit Product Central to learn more about

your new Ultimate Ears headphone.

Browse online articles for setup help,

usage tips, or information about additional

features.

Connect with other users in our Community

Forums to get advice, ask questions,

andshare solutions.

At Product Central, you’ll ﬁnd a wide

selection of content:

• Tutorials

• Troubleshooting

• Support community

• Software downloads

• Online documentation

• Warranty information

• Spare parts (when available)

Go to www.logitech.com/support/ue6000

UE 6000

8 English

Troubleshooting

No sound or faint sound

• Check the cable connection. Make sure

the straight connector is connected

to the headphone and the angled

connector is connected to your device.

• Try increasing the volume for the

headphone and your media application.

• Restart your media application.

• If the Battery LED is red, replace the

2 AAA alkaline batteries.

Headphones not working with a computer

• Specify audio settings for your operating

system:

Windows® (Control Panel)

•Voice playback and recording:

Computer’s soundcard

•Sound playback: Computer’s speakers

Mac® OS X (Preferences)

•Sound input: Internal microphone

•Sound output: Internal speakers

Refer to your operating system

documentation. For more information,

go to www.logitech.com/

support/ue6000.

简体中文 9

UE 6000

AAA

Setup Guide

6000

2 4 7

包装内容

1. 耳机

2. 可拆卸音频线，带有内置麦克风和线

控功能

3. 收纳盒

4. 共享分线器

5. 2 节 AAA 碱性电池

(预装）

6. Y型接头

7. ¼ 英寸（6.35 毫米）适配器

8. 文档

设置指南

10 简体中文

UE 6000

了解您的产品

1. 可调节头带

2. 记忆海绵垫

3. 电池 LED 指示灯

4. 开启/关闭滑动开关

5. 调高音量

6. 媒体/通话控制键

•单击一下：

播放/暂停（音频）

接听电话/挂断电话（手机）

•双击：

下一曲目（音频）

•单击三下：

上一曲目（音频）

•单击一下，之后单击并按住：

快进（音频）

•双击，之后单击并按住：

倒带（音频）

•单击并按住：

启用/禁用语音拨号1

7. 调低音量

8. 麦克风

9. 电池盖按钮（按下按钮可打开电池盖）

10. 电池存放槽

11. 3.5毫米音频输入插孔

1 功能依手机而异。在 iPhone® 4S 中激活 Siri®。
