ZONE VIBE WIRELESS

Setup Guide

Guide d'installation

CONTENTS

English . . . . . . . . . . . . . . . . . . . 3

Deutsch . . . . . . . . . . . . . . . . . .14

Français . . . . . . . . . . . . . . . . . 25

Italiano . . . . . . . . . . . . . . . . . . 36

Español . . . . . . . . . . . . . . . . . . 47

Português . . . . . . . . . . . . . . . . 58

Nederlands . . . . . . . . . . . . . . . . 69

Svenska. . . . . . . . . . . . . . . . . . 80

Dansk. . . . . . . . . . . . . . . . . . . .91

Norsk . . . . . . . . . . . . . . . . . . .102

Suomi. . . . . . . . . . . . . . . . . . . 113

Ελληνικά . . . . . . . . . . . . . . . . . .124

По-русски. . . . . . . . . . . . . . . . .135

Po polsku . . . . . . . . . . . . . . . . . 146

Magyar . . . . . . . . . . . . . . . . . .157

Česká verze. . . . . . . . . . . . . . . .168

Slovenčina . . . . . . . . . . . . . . . . 179

Українська. . . . . . . . . . . . . . . . .190

Eesti . . . . . . . . . . . . . . . . . . . 201

Latviski . . . . . . . . . . . . . . . . . . 212

Lietuvių . . . . . . . . . . . . . . . . . .223

Български . . . . . . . . . . . . . . . . .234

Hrvatski . . . . . . . . . . . . . . . . . 245

Srpski . . . . . . . . . . . . . . . . . . .256

Slovenščina. . . . . . . . . . . . . . . .267

Română . . . . . . . . . . . . . . . . . 278

Türkçe . . . . . . . . . . . . . . . . . .289

300 . . . . . . . . . . . . . . . . . . 

311 . . . . . . . . . . . . . . . . . . . 

KNOW YOUR PRODUCT

Front view:

Back view:

Microphone

boom

Music control

button (play/

pause/next track)

USB-A

adapter

USB-C

receiver

UC version -

Call button (answer/

end/reject calls)

MSFT Teams version -

Teams/Call button

Volume up/down

3English

Bottom view:

3-position switch (power/

Bluetooth®pairing)

Mute button

USB-C port

LED light

4English

USB-C USB-C USB-AUSB-C

BOX CONTENT

1. Zone Vibe Wireless headphones

2. Charging cable

3. USB-C receiver

4. USB-A adapter

5. Travel bag

6. User documentation

POWER ON/OFF

1. Slide the switch in the arrow’s direction to

the middle to power on the headphones. 1

2. Once powered on, the LED light will slightly

turn white.

3. There will be a voice prompt that tells you

the battery status.

5English

CONNECT YOUR HEADPHONES

a. Connect via USB-C receiver

1. Insert the receiver into the computer USB-C

port. Or insert the USB-C receiver with the

USB-A adapter to the USB-A port.

2. Zone Vibe Wireless is already paired to the

receiver it ships with.

3. Once successfully paired, the LED light on

the receiver will turn solid white then dim.

b. Connect via BLUETOOTH®

1. Slide the switch to the bottom in the arrow’s

direction for 2 seconds to initiate pairing.

2. The LED light will ash white rapidly.

3. Open Bluetooth®settings on your device.

4. Select Logi Zone Vibe Wireless in discoverable

devices.

5. Once successfully paired, the LED light will

turn solid white.

LOGI Zone

Vibe Wireless

2 sec.

USB-C

USB-A

ADJUSTING HEADPHONES

1. Adjust the headphones by sliding earcups

up and down the extended part of the

headband.

2. It may be easier to adjust the headphones

on your head. Slide the earcups up and down

the headband until they sit comfortably on

your ears.

6English

HEADPHONES CONTROLS

Note:

- Teams activities are only functional when Teams is running on an unlocked computer.

- Media control functionality depends on the type of application.

- Call activities are always the rst priority. When two devices are connected, the Bluetooth®connection will be prioritized

over the receiver. When two Bluetooth devices are connected, the last active device will override the other.

UC version:

Usage Button Action

Call controls Answer / End call Call button Short press

Reject call 1.5 sec. press

Music controls Play / Pause Music control button Short press

Track forward Double press

Volume Volume up "+" Short press

Volume down "-"

Connectivity Bluetooth pairing 3-position switch 2 sec. press

MSFT Teams:

Usage Button Action

Call controls

Answer / End call

Call button

Short press

Reject call 1.5 sec. press

Resume call Short press

Transfer active call to other device

Team activities Invoke Teams Call button Short press

Music controls Play / Pause Music control button Short press

Track forward Double press

Volume Volume up "+" Short press

Volume down "-"

Connectivity Bluetooth pairing Power button 2 sec. press

Tip: Music EQ controls available on Logi Tune.

7English

HEADPHONES LIGHT INDICATOR

Note:

- User-triggered behaviors, such as Bluetooth pairing or link lost, will be prioritized then revert back to its previous status

once the behavior is completed.

Category Status Light

White

Power

Power ON Turn solid white and then dim

Battery charging Breathing

Battery fully charged Solid

Connectivity

Bluetooth pairing Fast blinking

Bluetooth / receiver connected Turn solid white and then dim

Link lost Dim white

Calls Active call Solid

Incoming call Slow blinking

Red Calls Mute Solid

Power Low battery (< 10%) Slow blinking

Factory reset Fast blink from red to white for

three times then LED turn o

Voice notications indicate

when the microphone is on/

o mute.

MUTE

There are 2 ways to mute your microphone.

Press the button to mute. Flip up or down the mic

boom to mute or unmute.

L L L

Mute

"Mute on"

"Mute o"

8English

RECEIVER LIGHT INDICATOR

MSFT Teams:

Category Status Light

White Connectivity

Receiver connecting O

Receiver connected

New device paired Turn solid white and then dim

Receiver disconnected O

Purple

Connectivity

Connecting to Teams Breathing

Solid

First time failed connecting

to Teams Fast blinking for 10 seconds and then o

Failed connecting to Teams Fast blinking 3 times then LED o

Calls Active call Solid

Incoming call Repeat "fast blinking 3 times then LED o"

Red Calls Mute Solid

Blue Connectivity New device pairing Fast blinking

Connecting mode

Connected/Paired

Incoming call

Mute on

Pairing mode

Paired

9English

UC version

Category Status Light

White

Connectivity

Receiver connecting O

Receiver connected

New device paired Turn solid white and then dim

Receiver disconnected O

Calls

Active call Solid

Incoming call Repeat "fast blinking 3 times then

LED o"

Red Calls Mute Solid

Blue Connectivity New device pairing Fast blinking

Connecting mode

Connected/Paired

Incoming call

Mute on

Pairing mode

10 English
