LOGITECH ZONE 750

Setup Guide

Guide d’installation

CONTENTS

English . . . . . . . . . . . . . . . . .3

Français . . . . . . . . . . . . . . . .8

Español . . . . . . . . . . . . . . . . 13

Português . . . . . . . . . . . . . . 18

KNOW YOUR PRODUCT

Adjustable

headband

Padded leatherette

ear cups

Adjustable

noise-canceling

microphone boom

INLINE CONTROLLER

Microphone mute

Call controls

&Voiceassistant

Volume up

Volume down

USB-C connector

USB-A adapter

Media controls

3English

USB-A

USB-C

WHAT’S IN THE BOX

1. Headset with in-line controller and USB-C connector

2. USB-A adapter

3. Travel bag

4. User documentation

CONNECTING THE HEADSET

Connect via USB-C

1. Plug the USB-C connector into your computer

USB-C port.

Connect via USB-A

1. Plug the USB-C connector into the USB-A adapter.

2. Plug the USB-A connector into your computer

USB-A port.

Note: Only use the USB-A adapter with the provided

headset.

HEADSET FIT

Adjust headset by sliding headband open or closed

onboth sides.

ADJUSTING THE MICROPHONE BOOM

1. Microphone boom rotates 270 degrees. Wear it on

either left or right side. To activate audio channel

switching, download Logi Tune at:

www.logitech.com/tune

2. Adjust exible microphone boom location to capture

voice better.

1 2

4English

UNMUTE - - - 1x - - - MUTE ON

MUTE - - - 1x - - - MUTE OFF

INCOMING CALLS

ANSWER CALLS

REJECT CALLS

END CALLS

MEDIA CONTROLS

TRIGGER VOICE ASSISTANT

2 sec.

ONGOING CALLS

* Voice assistant functionality may depend on device models.

Button Usage Indicator Light Action

Mute

Mute on Solid RED

Short press to mute / unmute

Mute o No light

Call Controls Incoming calls Flashing WHITE Short press to answer calls

2 seconds press to reject calls

Ongoing calls Solid WHITE Short press to end calls

Voice Assistant No light 2 seconds press to trigger voice assistant*

Media Controls No light

Short press to play / pause

Double press to track forward

Triple press to track backward

+Volume No light Short press to volume up

-Short press to volume down

HEADSET INLINE CONTROLS AND INDICATOR LIGHT

5English

LOGI TUNE PC COMPANION APP

Logi Tune helps boost your headset performance with periodic software

and rmware updates, helps you adjust what you hear with 5 band EQ

customization, and helps you control how you are heard with mic gain,

sidetone controls, and more. Thedistraction-free mini-app allows you

tomake audio adjustments while in an active video call.

Learn more & download Logi Tune at:

www.logitech.com/tune

ADJUSTING SIDETONE

Sidetone lets you hear your own voice during conversations so you are

aware of how loud you are talking. In Logi Tune, select the sidetone feature,

andadjust the dial accordingly.

— A higher number means you hear more external sound.

— A lower number means you hear less external sound.

UPDATE YOUR HEADSET

It is recommended to update your headset. To do so, download

Logi Tune from www.logitech.com/tune

6English

Europe S.A. and/or its aliates in the U.S. and other countries. Logitech assumes noresponsibility

for any errors that may appear in thismanual. Information contained herein issubject to change

without notice.

www.logitech.com/support/zone750

DIMENSION

Headset:

Height x Width x Depth: 165.93 mm x 179.73 mm x 66.77 mm

Weight: 0.211 Kg

Ear pad dimensions:

Height x Width x Depth: 65.84 mm x 65.84 mm x 18.75 mm

Adapter:

Height x Width x Depth: 21.5 mm x 15.4 mm x 7.9 mm

SYSTEM REQUIREMENTS

Windows, Mac or ChromeTM based computer with available USB-C

or USB-A port. USB-C compatibility with mobile devices depends on

device models.

TECHNICAL SPECIFICATIONS

Input Impedance: 32 Ohms

Sensitivity (headphone): 99 dB SPL/1 mW/1K Hz (driver level)

Sensitivity (microphone): Main mic: -48 dBV/Pa, Secondary mic: -40 dBV/Pa

Frequency response (Headset): 20-16 kHz

Frequency response (Microphone): 100-16 kHz (mic component level)

Cable length: 1.9 m

PRÉSENTATION DU PRODUIT

Bandeau réglable

Oreillettes

rembourrées

ensimilicuir

Tige de microphone

anti-parasite

réglable

CONTRÔLEUR INTÉGRÉ

Mise en sourdine

dumicrophone

Contrôle des appels

etassistant vocal

Volume +

Volume -

Connecteur USB-C

Adaptateur USB-A

Commandes

multimédia

8Français

USB-A

USB-C

CONTENU DU COFFRET

1. Casque avec contrôleur intégré et connecteur USB-C

2. Adaptateur USB-A

3. Pochette de transport

4. Documentation utilisateur

BRANCHEMENT DU CASQUE

Connexion via USB-C

1. Branchez le connecteur USB-C dans le port USB-C

del'ordinateur.

Connexion via USB-A

1. Branchez le connecteur USB-C à l'adaptateur USB-A.

2. Branchez le connecteur USB-A dans le port USB-A de

votre ordinateur.

Remarque: utilisez uniquement l’adaptateur USB-A

avec le casque fourni.

AJUSTEMENT DU CASQUE

Réglez le casque en faisant glisser le bandeau ouvert

oufermé de chaque côté.

AJUSTEMENT DE LA TIGE DU MICROPHONE

1. La tige du micro pivote sur 270 degrés. Portez-la

àgauche ou à droite. Pour activer la commutation

ducanal audio, téléchargez Logi Tune à l'adresse:

www.logitech.com/tune

2. Réglez l'emplacement de la tige du microphone

exible pour mieux capter votre voix.

1 2

9Français

* La fonctionnalité de l'assistant vocal peut dépendre des modèles.

Bouton Utilisation Témoin lumineux Action

Sourdine

Sourdine activée Témoin ROUGE

encontinu Brève pression pour mettre en sourdine/activer

le micro

Sourdine désactivée Aucun signal

lumineux

Commandes

desappels

Appels entrants Témoin BLANC

clignotant

Brève pression pour prendre les appels

Pression de 2 secondes pour rejeter les appels

Appels en cours Témoin BLANC

encontinu Brève pression pour mettre n aux appels

Assistant vocal Aucun signal

lumineux

Pression de 2 secondes pour déclencher

l'assistant vocal*

Commandes multimédia Aucun signal

lumineux

Brève pression pour lire/mettre en pause

Deux pressions pour passer à la piste suivante

Trois pressions pour passer à la piste

+Volume Aucun signal

lumineux

Brève pression pour augmenter le volume

-Brève pression pour baisser le volume

COMMANDES INTÉGRÉES ET TÉMOIN LUMINEUX DU CASQUE

DÉSACTIVER LA SOURDINE - - - 1x - - -

SOURDINE ACTIVÉE

SOURDINE - - - 1x - - -

SOURDINE DÉSACTIVÉE

APPELS ENTRANTS

RÉPONDRE AUX APPELS

REJETER DES APPELS

METTRE FIN AUX APPELS

COMMANDES MULTIMÉDIA

DÉCLENCHER L'ASSISTANT VOCAL

2 sec.

APPELS EN COURS

10 Français
