Logitech Folio i5 Manuale utente

Setup Guide

FabricSkin Keyboard Folio i5

Logitech FabricSkin Keyboard Folio i5

Contents

English. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

www.logitech.com/support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Logitech FabricSkin Keyboard Folio i5

English 3

Know your product

1. iPad holder

2. Protective folio

3. Function keys

4. Keyboard

5. Bluetooth® and battery status light

6. Reset button

7. Micro-USB charging port

8. Bluetooth connect button

9. Micro-USB charging cable

10. Product documentation

PDF

FabricSkin Keyboard Folio i5

www.logitech.com/support/fabricskin-keyboard-folio-i5

1 2

Logitech FabricSkin Keyboard Folio i5

4 English

Setting up the keyboard folio

Getting started

1. Open the keyboard folio, make sure

the edge of your iPad is aligned with

the iPad holder and push down:

2. Move the keyboard folio into the typing

position:

The keyboard turns on automatically.

Establishing connection with your iPad

The keyboard folio links to your iPad via

a Bluetooth connection. The ﬁrst time you use

the keyboard folio, you must pair it with

your iPad.

The status light blinks blue to indicate that the

keyboard is discoverable, ready for pairing

with your iPad.

The ﬁrst time you use the keyboard it remains

discoverable for 15 minutes.

If the status light turns red, charge the battery.

For more information, see “Charging the

keyboard battery.”

To pair your keyboard folio with your iPad:

1. On your iPad:

•Make sure your iPad’s Bluetooth feature

is on. Select Settings > Bluetooth > On.

•Select “FabricSkin Keyboard Folio i5”

from the Devices menu.

Logitech FabricSkin Keyboard Folio i5

English 5

2. If your iPad requests a PIN, enter it using

the folio keyboard (not on your iPad).

When successful connection is made,

the status light turns solid blue for a short

time, and then turns o.

Connecting to another iPad

1. Move the keyboard folio into the typing

position.

2. Make sure your iPad’s Bluetooth feature

is on. Select Settings > Bluetooth > On.

3. Press the Bluetooth Connect button:

The keyboard is discoverable for 3 minutes.

4. Select “FabricSkin Keyboard Folio i5”

on your iPad’s Devices menu.

5. If your iPad requests a PIN, enter it using

the folio keyboard (not on your iPad).

When successful connection is made,

the status light turns solid blue for a short

time, and then turns o.

Using the keyboard folio

Two viewing positions

The keyboard folio provides two viewing

positions—one for typing and another

for browsing.

To type, move the iPad holder into the typing

position, aligning it with the built-in magnet

to secure it. Turn on the keyboard:

To browse, place the iPad holder in the

browsing position remembering to switch o

the keyboard to conserve battery power:

If you don’t use the keyboard for a while

in the typing position, it enters sleep mode

automatically. Pressing any key wakes it.

Closing the keyboard folio powers o

your iPad.

Logitech FabricSkin Keyboard Folio i5

6 English

Detaching your iPad

To detach your iPad from the folio, bend back

one of the iPad holder corners:

Your iPad is then released:

Storing your iPad for travel

1. Insert your iPad in the iPad holder.

2. Close the keyboard folio:

Cleaning your folio

Wipe your FabricSkin Keyboard folio with

a wet cloth. DO NOT use solvent.

Logitech FabricSkin Keyboard Folio i5

English 7

Status light indicators

Your keyboard folio’s status light provides information about the battery power and

Bluetooth connection:

Light Description

Blinking green The battery is charging.

Solid green The battery is fully charged (100%).

Red Battery power is low (less than 10%). Recharge the battery.

Blinking blue Fast: The keyboard is in discovery mode, ready for pairing.

Slow: The keyboard is trying to reconnect to your iPad.

Solid blue Bluetooth pairing or reconnection is successful.

Logitech FabricSkin Keyboard Folio i5

8 English

Function keys

Home = iPad Home screen

Fn + 1 = Lock screen

Locks or unlocks the iPad screen

Fn + 2 = Siri

Use your voice to send messages,

make calls, schedule meetings,

and more

Fn + 3 = Search

Launches the iPad search function

Fn + 4 = Switch language

Switches the keyboard language

Fn + 5 = Virtual keyboard

Shows/hides the virtual keyboard

Fn + 7 = Previous track

Fn + 8 = Play/Pause

Fn + 9 = Next track

Fn + 0 = Mute

Fn + dash = Volume down

Fn + plus = Volume up

Fn + X = Cut

Fn + C = Copy

Fn + V = Paste

Fn + Left cursor = Select left

Selects text on the left, word by word

Fn + Right cursor = Select right

Selects text on the right,

word by word

Fn + Spacebar =

Switch applications

Note: To select a function key, press and hold the Fn key, and then press the key indicated above.

Logitech FabricSkin Keyboard Folio i5

English 9

Charging the keyboard battery

If the status light is red the keyboard folio

battery needs to be charged.

1. Plug one end of the micro-USB cable

into the charging port, and the other end

into a USB port on your computer.

Alternatively, you can use a 5V USB charger,

such as that provided with your iPad,

providing the power output rating is at

least 500mA.

The status light blinks green as the battery

charges.

2. Charge the battery until the status light

turns solid green.

Battery information

•A fully charged battery provides about

three months of use when the keyboard

is used about two hours a day.

•Charge the battery if the status light turns

red brieﬂy after the keyboard turns on.

•When not in use, turn o the keyboard

to conserve battery power.

•The keyboard enters sleep mode

automatically if not used for a while

in the typing position. Press any key

to wake it.

USB

Logitech FabricSkin Keyboard Folio i5

10 English

Battery disposal at product end of life

1. Pry o top cover of keyboard with

screwdriver:

2. Detach battery from circuit board

and remove battery:

3. Dispose of your product and its battery

according to local laws.

Visit Product Central

There’s more information and support online

for your product. Take a moment to visit

Product Central to learn more about your new

keyboard folio.

www.logitech.com/support/fabricskin-

keyboard-folio-i5

Browse online articles for setup help,

usage tips, and information about

additional features.

Connect with other users in our Community

Forums to get advice, ask questions,

and share solutions.

Find a wide selection of content including:

•Tutorials

•Troubleshooting

•Support community

•Online documentation

•Warranty information

•Spare parts (when available)
