Lorex SG7518 Manuale utente

Please read Manual before Use

SYSTEM INCLUDES: COLOR NIGHT VISION

CAMERA WITH 6FT CABLE, MOUNTING BRACKET

AND 57FT. CABLE

It’s all on the web

Product Information

User Manuals

Quick Start Guides

Specification Sheets

Software Upgrades

Firmware Upgrades

www.lorexcctv.com

VISIT MODEL:

SG7518

www.lorexcctv.com

ACCESSORY INDOOR / OUTDOOR

NIGHT VISION COLOR CAMERA KIT

Instruction Manual

FEATURES

Technical Specifications:

•Image Device: 1/4” CCD Sensor

•Picture Elements: 510 H x 492 V

•Lens: 6 mm

•Resolution: 350 TV Lines

•Illumination: 0 LUX @ F2.0

•Power Requirement: powered from monitor via cable

•Operating Temperature: -14°F - 122°F (-20ºC to 50ºC)

•Dimensions: 2.1”(W) x 3.2”(D) x 2”(H)

•Weight: 12 oz

Because our products are subject to continuous improvement, SVII

and it’s subsidiaries reserve the right to modify product Design and

Specifications without notice and without incurring any obligation.

E & OE.

•Color Indoor / Outdoor Camera

•1/4” CCD Color Image Sensor

•Listen-in way Audio

•Compatible with all Lorex, Sylvania and Sentinel CCTV

Observation Systems

•6mm angle lens

•Infra-red illuminators ideal for low light viewing (B&W

video in low-light

CAMERA INSTALLATION

TROUBLE SHOOTING

Make sure the camera is not facing

Any direct Light or Sunlight

Picture Flickering

Check the cable for any loose

connection

No Picture

REMEDYPROBLEM

Keep camera installed away from direct sunlight.

Also avoid places where humidity is high or

unable to protect rain. The mounting bracket must

be attached to a structural device such as wall stud

or ceiling rafter using suitable fastener.

NOTE

For more information, please visit our website at

www.lorexcctv.com

1) Attach the Camera to the Metal Bracket and tighten

the swivel.

2) Connect the supplied extension cable to the back of the

camera.

3) Attach the metal stand to the wall or ceiling where

you want to install the camera. Locate a wall stud

or ceiling joist and secure bracket using the supplied

screws.

4) Connect the other end of the cable to the back of the

monitor.
