fast data logger with 50 mS sampling time

DC WATT METER

Model : DW-6064

Your purchase of this

DC WATT METER marks

a step forward for you

into the field of

precision measurement.

Although this METER is

a complex and delicate

instrument, its durable

structure will allow

many years of use if

proper operating

t e c h n i q u e s a r e

developed. Please read

t h e f o l l o w i n g

instructions carefully

and always keep this

manual within easy

reach.

OPERATION MANUAL

Caution Symbol

Caution :

* Risk of electric shock !

Caution :

* Do not apply the overload

voltage, current to the input

terminal !

* Remove test leads before open

the battery cover !

* Cleaning - Only use the dry

cloth to clean the plastic case !

Environment Conditions

Installation Categories III-60V.

Pollution Degree 2.

* Altitude up to 2000 meters.

* Indoor use.

* Relative humidity 80% max.

TABLE OF CONTENTS

1. FEATURES..............................................................................................

2. SPECIFICATIONS..................................................................................

2-1

General specifications.........................................................................

2-2

Electrical specifications.......................................................................

3. FRONT PANEL DESCRIPTION....................................................................

3-1 Display.............................................................................................

3-2 POWER/Backlight button....................................................................

3-3 FUNCTION/SETUP button..................................................................

3-4 HOLD button....................................................................................

3-5 RECORD button ( MAX. / MIN. )..........................................................

3-6 LOAD terminal...................................................................................

3-7 POWER SOURCE terminal.................................................................

3-8 RS-232 output terminal......................................................................

3-9 DC 9V Power Adapter input socket......................................................

3-10 Battery Cover / Compartment...........................................................

3-11 Stand.................................................................................................

4. MEASURING PROCEDURES......................................................................

4-1

Power ON / OFF...............................................................................

4-2

DCV measurement procedure..........................................................

4-3

DCA measurement procedure...........................................................

4-4

DC WATT measurement procedure...................................................

4-5

Fast data logger measurement procedure.............................................

4-6

Data Hold...........................................................................................

4-7

Data Record ( Max. , Min. reading ).....................................................

4-8

LCD Backlight ON/OFF......................................................................

5. ADVANCED SETTING.............................................................................

5-1

Auto Power Off Default Setting..........................................................

5-2

Set beeper sound ON / OFF...............................................................

6. MAINTENANCE......................................................................................

7. RS232 PC SERIAL INTERFACE...............................................................

8. BATTERY REPLACEMENT......................................................................

9. THE ADDRESS OF AFTER SERVICE CENTER............................................

1. FEATURES

* Professional precision DC WATT meter with 0.001W

resolution special digital display , battery operated .

* LSI - circuit provides high reliability and durability .

* Directly operation.

* DCV input impedance : 10MΩ.

* Measurement

WATT ( DC ) : 600 W x 0.01 W/60.000 W x 0.001 W.

DCV : 60V x 0.01 V .

DCA : 10 A x 10 m A/2 A x 1 m A.

* Low Watt measurement , 60.000 W x 0.001W .

* Fast data logger with 50mS sampling time.

* Data hold , Record ( Max. , Min.) .

* Super large LCD , Dual display at same time .

* Full function Auto range .

* RS232 / USB Computer interface .

* Built-in low battery indicator .

* Built-in backlight easy to readout .

* Power : DC 9V ( 006P ) or AC to DC 9V adapter input.

2. SPECIFICATIONS

2-1 General Specifications

Circuit Custom one-chip of microprocessor LSI

circuit.

Display Large LCD display max. reading 60000.

Digit size : 21.8 x 8.5 mm.

Dual value display with backlight

Measurement DCV 0.02 V - 60.00 V

Unit DCA 1 mA to 10.00 A.

WATT 0.002 W to 600 W

Over input " ---- " mark indication .

Zero Automatic adjustment

Display Approx. 0.5 second.

Sampling Time

Data Hold Freeze the display reading .

Memory Recall Maximum & Minimum value .

*Just for DC Watt and DC Ampere

function only.

Data output RS232 / USB PC Computer interface.

* Connect the optional RS232 cable

UPCB - 02 will get the RS232 plug.

* Connect the optional USB cable

USB - 01 will get the USB plug.

Operation 0℃ to 50℃ ( 32℉ to 122℉).

Temperature

Operation Less than 80% RH

Humidity

Power Supply * Alkaline or Heavy duty type DC 9V battery

006P , MN1604 (PP3) or equivalent.

* DC 9V adapter ( adapter is optional ).

Power Approx. DC 8.5 mA

Consumption * If the LCD backlight on, the power

consumption will increase approx. 2 mA.

Weight 364 g / 0.80 LB * Meter only.

Dimension 190 x 88 x 40 mm ( 7.5 x 3.5 x 1.6 inch ).

Accessories

Instruction manual..........................................

1 PC

Included

Test lead (Red & Black).......................................

1 Pair

Optional AC to DC 9V adapter

Accessories USB cable , USB - 01

RS232 cable , UPCB - 02

Data acquisition software, SW-U801-WIN

Excel data acquisition software, SW-E802

Data transfer software, DL-2005

Excel data transfer software, SW-E2005

2-2 Electrical Specifications (23±5

℃

)

DC WATT

Range Resolution Accuracy

600 W 0.01 W ± ( 0.6% reading+ 10d )

60 W 0.001 W

* Auto range.

* Measuring signal come from the front LOAD plug terminals.

* Max. input value, DC voltage : 60V, DC current : 10 A.

* Accuracy @ 23℃ ±5℃.

V/A

Range Resolution Accuracy

DCV 60 V 0.01 V ±( 0.3 % reading+ 5d )

DCA 2 A 0.001 A

DCA 10 A 0.01 A

* Auto range.

* Max. input value :

DC voltage : 60V , DC current : 10 A .

* Accuracy @ 23℃ ±5℃

@ Above specification tests under the environment RF Field Strength

less than 3 V/M & frequency less than 30 MHz only.

3. FRONT PANEL DESCRIPTION

Fig. 1

3-1 Display

3-2 POWER / Backlight button

3-3 FUNCTION / SETUP button

3-4 HOLD button

3-5 RECORD button ( MAX. / MIN. )

3-6 LOAD terminal

3-7 POWER SOURCE terminal

3-8 RS-232 output terminal

3-9 DC 9V Power Adapter input socket

3-10 Battery Cover / Compartment

3-11 Stand

4. MEASURING PROCEDURE

4-1 Power ON/OFF

1) Press the " POWER button " ( 3-2, Fig. 1 ) more than 1.5

seconds to Turn ON the meter.

2) Press the " POWER button " ( 3-2, Fig. 1 ) more than 1.5

seconds to Turn OFF the meter.

4-2 DCV measurement procedure

1) Press the " POWER button " ( 3-2, Fig.1 ) more than 1.5

seconds to Turn ON the meter.

2) Connect Red test lead to the " V " input terminal and

Black test lead to " COM " input terminal .

3) Then use the test lead measurement unknown DC voltage.

4) Read the value from top display. The value indicated

corresponds to the position selected. If the LCD show

" ---- ", it indicates an Out-of-range measurement.

5) If the LCD show in " dcv Error " , and the beeper is

continuously turn on, please change voltage polarity .

4-3 DCA measurement procedure

1) Press the " POWER button " ( 3-2 , Fig.1) more than 1.5 seconds

to Turn ON the meter.

2) Connect red test lead to the " COM " input terminal and

black test lead to " 10A " input terminal .

Then use the test lead measurement unknown DC current.

4) Read the value from bottom display . The value

indicated corresponds to the position selected. If the

display shows " ---- " it indicates an Out-of-range

measurement.

4-4 DC WATT measurement procedure

1) Press the " POWER button " ( 3-2 , Fig.1) more than 1.5

seconds to Turn ON the meter.

2) Turn OFF the DC POWER SOURCE.

Plug in the DC POWER SOURCE to " WATT " terminal

and " 10A " terminal ( 3-7 , Fig.1).

Turn ON the DC POWER SOURCE.

4) Read the value from top display. The value indicated

what voltage to test.

Then turn OFF the DC POWER SOURCE.

5) Make sure your unknown elements or equipment

working voltage and voltage polarity .

6) Press the " FUNCTION button " ( 3-3 , Fig.1) once then

change function for measuring DC WATT.

7) Plug in the LOAD ( element or equipment ) to " V "

terminal and " COM " terminal ( 3-6 , Fig.1).

8) Turn ON the DC POWER SOURCE. ( Turn ON the

equipment power switch, let it work.)

9) Then you can read out the POWER value from the top of

the LCD display .

10) Then you can read out the CURRENT CONSUMPTION

from the bottom of the LCD display .

11) At the same time push the " FUNCTION button " ( 3-3 ,

Fig.1) once then change function for measuring DCV/

DCA.

4-5 Fast data logger measurement procedure

1) Press the " POWER button " ( 3-2 , Fig.1) more than 1.5

seconds to Turn ON the meter.

2) Press the " FUNCTION button " ( 3-3 , Fig.1) and " HOLD

button " ( 3-4 , Fig.1) at the same time more than 3

seconds, will into Fast data logger mode and LCD will

show in " FASt " at the top of display, on the bottom

side of LCD will show in " DATALOGGER " .

3) On the bottom side will show in " 2.000 A ", means

maximum work current are 2 A, you can press " HOLD

button " ( 3-4, Fig. 1 ) once to change for maximum

current 10 A, and LCD will show in " 10.00 A " .

4) Now you can turn on the equipment power switch or

turn on the DC POWER SOURCE .

5) Then press " REC button " ( 3-5, Fig. 1 ) to execute data

logger function, and LCD will show in " REC " at the top

of display.

When finish data logger function " REC " symbol will

disappear, " SET " symbol will show on LCD left side.

If you press " FUNCTION button " ( 3-3, Fig. 1 ) , meter will

send data from " RS-232 output terminal" ( 3-8, Fig. 1 ).

through RS232 cable ( UPCB - 02 ) or USB cable ( USB -

01) into the computer and recording to the software

SW-E2005 ( optional ) or DL-2005 ( optional ).

When finish data transmit , " EMPTY " symbol will show

show on LCD on left side automatically.

9) If you intend to exit Data logger function. press the

" FUNCTION button " ( 3-3 , Fig.1) and " HOLD button " (

3-4 , Fig.1) at the same time again more than 3 seconds ,

will leave Fast data logger mode.

10) The record numbers of Data logger is 300 records. The

duration time of Data logger is 5 seconds.

4-6 Data Hold

During the measurement, press the " Hold Button " ( 3-4,

Fig. 1 ) once will hold the measured value & the LCD will

display a " HOLD " symbol.

Press the " Hold Button " ( 3-4, Fig. 1 ) once again will release

the data hold function.

4-7 Data Record ( Max., Min. reading )

1) The data record function records the maximum and

minimum readings. Press the " REC button " ( 3-5, Fig.

1 ) once to start the Data Record function and there

will be a " REC. " symbol on the display.

Indice

Altri manuali Lutron Electronics Strumento di misura

Lutron Electronics

Lutron Electronics CD-4318SD Manuale utente

Lutron Electronics

Lutron Electronics SL-4023SD Manuale utente

Lutron Electronics

Lutron Electronics DS-2013SD Manuale utente

Lutron Electronics

Lutron Electronics Radio Powr Sav LRF2-DCRB Istruzioni per l'installazione e il funzionamento

Lutron Electronics

Lutron Electronics LCR-9063 Manuale utente

Lutron Electronics

Lutron Electronics DM-9027T Manuale utente

Lutron Electronics

Lutron Electronics AM-4233SD Manuale utente

Lutron Electronics

Lutron Electronics DW-6093 Manuale utente

Lutron Electronics

Lutron Electronics EM-9300SD Manuale utente

Lutron Electronics

Lutron Electronics PM-9100HA Manuale utente

Lutron Electronics

Lutron Electronics DT-2230 Manuale utente

Lutron Electronics

Lutron Electronics LM-81LX Manuale di installazione

Lutron Electronics

Lutron Electronics GC-2028 Manuale utente

Lutron Electronics

Lutron Electronics vt-8204 Manuale utente

Lutron Electronics

Lutron Electronics CD-4322 Manuale utente

Lutron Electronics

Lutron Electronics AM-4220 Manuale utente

Lutron Electronics

Lutron Electronics EM-1900 Manuale utente

Lutron Electronics

Lutron Electronics PMS-713 Manuale utente

Lutron Electronics

Lutron Electronics EMF-831SD Manuale utente

Lutron Electronics

Lutron Electronics DT-2234BL Manuale utente

Lutron Electronics

Lutron Electronics UV-340A Manuale utente

Lutron Electronics

Lutron Electronics FR-5105 Manuale utente

Lutron Electronics

Lutron Electronics YK-2001PHA Manuale utente

Lutron Electronics

Lutron Electronics FORCE GAUGE FG-6005SD Manuale utente

Manuali Strumento di misura popolari di altre marche

Suaoki

Suaoki D40 Manuale utente

Elster

Elster BK-G1.6 Manuale utente

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuale

Duratool

Duratool D03128 Manuale utente

Vega

Vega VEGAPULS 65 Manuale utente

Tonghui

Tonghui TH2618B Manuale utente

Tenmars

Tenmars TM-801 Manuale utente

MSR

MSR 145 Manuale utente

TPS

TPS WP-82 Manuale utente

ELMETRON

ELMETRON CP-511 Manuale utente

PCB Piezotronics

PCB Piezotronics 003C30 Manuale utente

Tenma

Tenma 72-10465 Manuale utente

Endress+Hauser

Endress+Hauser Proline Promag 50 Specifiche tecniche

Siemens

Siemens SITRANS F Coriolis FCT030 Manuale elenco delle parti

KLINGER

KLINGER CMF V Series Manuale utente

EXFO

EXFO FTB-2 Manuale operativo e di manutenzione

Keysight

Keysight M8290A Manuale utente

ADTEK

ADTEK MW-5 Manuale utente
