McCrometer FlowConnect Manuale utente

30122-22 Rev. 1.1 | 05DEC2019

• Read the user documentation required for

installation or retrot. You will nd a ow

meter manual and a FlowConnect manual

specic for the product you received.

• Perform an inventory of the parts using the

parts list in the IOM manual.

• Assemble the tools you will need.

• Prepare the site if necessary. Plan where to

install the ow meter, sensors and solar panel.

This is a brief overview of what is involved in installing a new ow meter or retrotting an existing ow

meter with a FlowConnect unit. All of the steps listed below are described in full detail the IOM manual.

Before you begin, read this sheet carefully.

Install the new ow meter or perfrom the

retrot as described in the IOM manual.

1 2

Prepare for installation

Install the ow meter or

perform the retrot

Activate the FlowConnect unit

START HERE

Read this before you proceed

After the FlowConnect is installed, you will need to attach the antenna, connect the batteries, and attach the

tamper evident seal.

Activation steps:

1. Attach the antenna.

2. Remove the battery cover with a 5/32”

hex driver.

1 2

CONTINUED ON NEXT PAGE

30122-22 Rev. 1.1 | 05DEC2019

Log on to the web site to view the data the

FlowConnect device will transmit.

You may choose to install a pressure sensor, a rain gauge, or a

solar panel.

If you have rechargeable batteries, you will need to install a solar

panel or an external power supply.

Connect the sensors and solar power cable to the FlowConnect

unit on the connection plate.

Non-rechargeable batteries Rechargeable batteries

Install and connect the sensors and solar panel (if applicable)

Log on to the web site

IMPORTANT

IMPORTANT!

The batteries need to be connected in the order described below. If this is not followed, the FlowConnect unit

will not activate properly. This will result in the FlowConnect failing to transmit data.

First

Second

First

4 5

3. Set the batteries in place

according to their type.

Plug in the batteries in the

order shown at right.

4. Replace the battery cover, making

sure the O-ring is set in place

properly, and tighten the four

screws hand tight.

5. Attach the tamper

evident seal.
