FO N4 Orifice flowmeter
Operating Instructions
Pa e 2 / 20 www.mecon.de Operatin Instructions F O N4
04/2013 OI_FO_N4_EN
Imprint
All ri hts reserved. It is prohibited to reproduce this document, or any parts thereof, withoutprior written
authorization of MECON Flow Control Systems GmbH.
Subject to chan e without notice.
Copyri ht 2013 by
MECON Flow Control Systems GmbH - Rönt enstraße 105 - 50169 Kerpen
Operatin Instructions F O N4 www.mecon.de Pa e 3 / 20
04/2013 OI_FO_N4_EN
Contents
Contents
1 Safety instructions _________________________________________________________ 4
1.1 Intended use .............................................................................................................. 4
1.2 Certifications .............................................................................................................. 4
1.3 Safety instructions for the operator ............................................................................... 5
2 Start-up ................................................................................................................................. 6
3 Installation ............................................................................................................................ 7
3.1 Installation instructions ................................................................................................ 7
3.2 Installation ................................................................................................................. 7
4 Ser ice __________________________________________________________________ 8
4.1 Stora e ...................................................................................................................... 8
4.2 Maintenance and cleanin ............................................................................................ 8
4.3 Returnin the device to the manufacturer ...................................................................... 8
5 De ice description _________________________________________________________ 9
5.1 Scope of delivery ........................................................................................................ 9
5.2 Versions ..................................................................................................................... 9
5.3 Nameplate ................................................................................................................ 10
6 Description code _________________________________________________________ 11
7 Measuring ranges for liquids ________________________________________________ 13
8 Measuring ranges for gases _________________________________________________ 14
9 Technical Data ___________________________________________________________ 15
9.1 Dimensions and wei hts ............................................................................................. 16
10 Contacts _______________________________________________________________ 17
Pa e 4 / 20 www.mecon.de Operatin Instructions F O N4
04/2013 OI_FO_N4_EN
Safety Instructions
1 Safety Instructions
1.1 Intended use
The FO N4 orifice flowmeter is used to measure the flow of transparent liquids and ases in closed
pipes. The flowmeter is suitable for any mountin location, position and flow direction.
The flowmeter can also be used for flow monitorin if equipped with limit contacts.
Warning!
The operator of these measuring devices is solely responsible for the suitability,
intended use and corrosion resistance of the selected materials. It must be particularly
ensured that the materials selected for the etted parts of the flo meter are suitable
for the process media to be measured.
The manufacturer is not liable for any damage resulting from improper or unintended
use of these devices.
The FO N4 may only be operated within the pressure and volta e limits specified on the name
plate.
No external loads may act upon the meter. The flowmeters are primarly desi ned for static
applications.
1.2 Certifications
Classification by
• Pressure equipment directive 97/23/EC
The meter meets the requirements of Article 3, para raph 3 (sound en ineerin practice SEP).
The most hazardous permissable media are
-for liquids and gases: fluids of group 2
Operatin Instructions F O N4 www.mecon.de Pa e 5 / 20
04/2013 OI_FO_N4_EN
Safety Instructions
1.3 Safety instructions from the manufacturer
Disclaimer
The manufacturer will not be liable for any dama e resultin from the use of its product, includin ,
but not limited to direct, indirect , incidental, punitive and consequential dama es
Any product purchased from the manufacturer is warranted in accordance with the relevant
product documentation and our Terms and Conditions of Sale.
The manufacturer reserves the ri ht to revise the content of its documents, includin this
disclaimer, without prior notifica, and will not be liable in any way for possible consequences of
such chan es.
Product liability and warranty
Mecon GmbH assumes no uarantee for repair work carried out by the customer without prior
notification and consulation. Any instruments or parts rejected by a customer must be returned to
us, if no other arran ement has been made.
General information
This manual is intended for the correct installation as well as operation and maintenance of the
devices. Read this instructions carefully before installin the device and placin into operation.
Specially desi ned or customised models and specialised applications are not included in this
manual.
Pa e 6 / 20 www.mecon.de Operatin Instructions F O N4
04/2013 OI_FO_N4_EN
Start-up
2 Start-up
When starting up the unit, the following points must be obser ed:
• Make sure that the actual operatin conditions (pressure and temperature) do not exceed the
limits specified on the nameplate.
• The calibration is carried out for defined conditions. It is essential to ensure compliance with the
calibration conditions. Deviations of the density, pressure or temperature of ases, as well as
density and viscosity of liquids, result in errors.
• Bends, valves and the like must be installed in such a distance of the orifice unit that
disturbances have subsided. Orifice units with lar e diameters are hi hly sensitive to
disturbance.
• When floats with ma nets and contact switches are used, it is recommended durin
commissionin to ensure the correct position of the bistable contact by movin the float alon
the contact in flow direction.
Exceptions for the measurements of gases:
• Provide valves downstream the flowmeter if pabs > 1,013 bar and usually upstream the flow-
meter if pabs = 1,013 bar (no overpressure).
• Install a flow control valve close to the flowmeter (downstream), to prevent oscillations durin
the measurement.
• Adjust the operatin pressure exactly to the reference pressure (durin calibration) to prevent
measurement errors.
Operatin Instructions F O N4 www.mecon.de Pa e 7 / 20
04/2013 OI_FO_N4_EN
Installation
3 Installation
3.1 Installation instructions
Information !
All instruments are carefully checked for proper function before shipment. Check
immediately on receipt, the outer packing carefully for damage or signs of impro
handling.
Report damage to t
he carrier and your competent sales staff. In such cases, a description
of the defect, the type and the serial number of the device is indicated.
Information !
Unpack the unit carefully to avoid damage.
Information !
Check the completeness of the delivery by using the packing list. Check the
name plate, if
the delivered flo meter is according to your order. Especially c
heck units ith electrical
components for the correct supply voltage.
3.2 Installation
The measurin re ulations for the flow DIN EN ISO 5167 not only include the version of orifice
units but also require an installation conformin to standards so that the indicated uncertainty in
measurement can be kept.
The standard installation must already be considered durin the projectin of the pipeline. The
orifice unit must be installed in a strai ht pipeline which is lon enou h.
• Ali n orifice with the sharp ed e (+ markin ) to the entry side
• Insert differential pressure sensor with askets concentrically between the flan es of the
pipeline and ti hten uniformly
• Loosen the union nut, ali n the indicatin part vertically downwards and then ti hten union nut
(Fi .4,
1
)
• In eneral, an inlet pipe of 10 x D and an outlet section of 5 x D is sufficient.
Pa e 8 / 20 www.mecon.de Operatin Instructions F O N4
04/2013 OI_FO_N4_EN
Service
4 Ser ice
4.1 Storage
Keep the device in a dry and dust-free place.
Keep away from direct sun and heat.
Avoid external load to the device
The stora e temperature ran e for standard devices with electrical components is about
-40 … +70 °C (– 40 °F … 158 °F)
4.2 Maintenance and cleaning
The devices were built within scope of low maintenance but periodically the flowmeters should be
inspected for si ns of corrosion, mechanical wear as well as dama e to the fittin and the display
unit.
We advice to carry out inspections at least once a year.
F3,or a detailed inspection and cleanin the device must be removed from the pipin .
Contamination, especially around the bypass orifice, may lead to faults in the measurement. The
bypass orifice plate can be dismounted and cleaned without interruptin the main flow it the ball
valves are closed first.
Caution!
Appropriate safety precautions have to be taken hen removing the device. Al ays use
ne gaskets hen reinstalling the device in the pipng.
4.3 Returning the de ice to the manufacturer
This device has been carefully manufactured and tested. Should you nevertheless need to return a
device to MECON GmbH please observe the followin points:
Caution!
Accordin to the actual waste disposal directives, the owner/customer is responsible for
the waste mana ement of hazardous and toxic waste. For reasons of environmental
protection and safe uardin the health and safety of our personnel all de ices sent to
MECON GmbH to be repaired must be free of toxic and hazardous substances.
This also applies to ca ities of the de ices before returning them to MECON.
The customer has to confirm this by filling in an appropriate form hich is available for
do nload on the MECON ebsite:
.mecon.de/en/declaration/contamination pdf
Caution!
In case of returnin devices which contain hazardous and toxic substances, Mecon
GmbH is entitled to dispose of these substances at cost to the customer without any
further notice.
Operatin Instructions F O N4 www.mecon.de Pa e 9 / 20
04/2013 OI_FO_N4_EN
Device Description
5 De ice Description
5.1 Scope of deli ery
1 Orifice flowmeter FO N4
2 Operatin instructions
3 Certificates (optional)
Fig. 1 Scope of devlivery
Information !
Please check the delivery for completeness using the packing list.
5.2 Versions
Fig. 2 Standard device with bypass
and orrifce made of PVC
The FO N4 orifice flowmeter primarly consists of an orifice plate as the sensor and a float as the
display element. A differential pressure is produced across the orifice plate which is fitted in the
main stream between two flan es in the pipin . In a bypass, this differential pressure produces a
volume flow in a variable area meter. The hei ht of the float indicates the flow rate.
The flow is read at the position of the float´s widest diameter.
Pa e 10 / 20 www.mecon.de Operatin Instructions F O N4
04/2013 OI_FO_N4_EN
Device Description
Special features:
• Complies with requirements for treatment and disinfection of swimmin / bathin pools
(DIN 19 643)
• Simple installation
• Direct visualitzation of flow rate in bypass
• Suitable for any mountin positions without reduction in accuracy
5.3 Nameplate
Important!
Please refer to the device nameplate to ensure that the device is built
according to your order.
Check particularly for the corect supply voltage
Fig. Nameplate of the FO N4
1 Code number Device specific code number
2 Year / Serial number Device specific serial number and the year it was built
3 Cate ory Cate ory acc. To Pressure Equipment directive (PED)
4 TS Medium Maximum temperature of the medium
5 PS Maximum pressure of the medium
6 Pmax bei TS Maximum pressure of the medium at temperature TS
Indice
