Metra Electronics 99-5825S Manuale utente

METRA. THE WORLD’S BEST KITS.™

APPLICATIONS

1-800-221-0932 metraonline.com

INSTALLATION INSTRUCTIONS FOR PART 99-5825

Ford Fiesta 2011-up

•ISODINHeadunitprovision

•Driverinformationcircuitsandbuttons

•PaintedSilverorMatteBlacktomatchfactoryfinish

WIRING & ANTENNA CONNECTIONS(SoldSeparately)

Wireharness:

•XSVI-5524-NAVFordinterface2011-up

Antennaadapter:

•40-EU10multi-appadapter

PanelRemovalTool•PhillipsScrewdriver•SocketWrench•CuttingTool

•A)RadioHousing•B)RadioISOBrackets

•C)(6)#8x3/8”Phillipstrussheadscrews

TOOLS REQUIRED

KIT FEATURES

KIT COMPONENTS

99-5825S

99-5825B

Table of Contents

Dash Disassembly

–FordFiesta2011-up 3-4

Kit Assembly

–FordFiesta2011-up,ISODINheadunitprovisions 5

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take steps

toward a better tomorrow.

Metra recommends MECP

certified technicians

99-5825

Caution

Metra recommends disconnecting the negative battery terminal before beginning any

installation. All accessories, switches, and especially air bag indicator lights must be

plugged in before reconnecting the battery or cycling the ignition.

*NOTE: Refer Also to the instructions included with the aftermarket radio.

NOTE: This kit comes pre-programmed for vehicles equipped with SYNC. It will not operate

properly in vehicles equipped without SYNC unless it is programmed.

Programming for vehicles without SYNC:

1. Turn on the ignition.

2. Press and hold the kit’s menu button for ten seconds.

3. Release the menu button and test the kit’s buttons for proper operation.

1. Unsnapandremovethepaneloverthe

 displayatthetopofthedash.(FigureA)

2. Removetwo7mmhexscrewsfromthe

 topoftheradiopanel.(FigureB)

3. Unclipandremovetheradiotrimpanel

 includingthevents.(FigureC)

Continued on next page

Dash Disassembly

99-5825

(Figure A)

(Figure B)

(Figure C)

Dash Disassembly

99-5825

(Figure B)

(Figure C)

4. Removetwo7mmhexholdingradio

 andradiochassistogether(fromtopof

 panel).(FigureA)

5. RemovetwoT-20Torxandunclipthe

 twoventsfromthefactoryradiopanel.

 (FigureB)

6. RemovetwoT-20Torxfrompassenger

 airbaglightandremoveit.(FigureB)

7.Asmallcutisrequiredinthesubdash

 forclearance.(FigureC)

(Figure A)

Kit Assembly 99-5825

(Figure A)

(Figure B)

(Figure C)

1. Snapthefactoryventsintotheradio

 panel.(FigureA)

2. MounttheISObracketstotheheadunit

 withthescrewssuppliedwiththeunit.

 (FigureB)

3. Mounttheradiobracketassemblyto

 theradiopanelusingthesupplied

 screws.(FigureC)

4. Mountthefactoryairbagindicatorto

 theRadioPanelusingthesupplied

 screws.(FigureA)

5. Locatethefactorywiringharness

 andantennapluginthedash.Metra

 recommendsusingthepropermating

 adaptersfromMetraand/orAXXESS.

6. Reassembledashinreverseorder

 ofdisassembly.

NOTE: This kit comes pre-programmed

for vehicles equipped with SYNC. It will

not operate properly in vehicles equipped

without SYNC unless it is programmed.

Programming for vehicles without SYNC:

1. Turn on the ignition.

2. Press and hold the kit’s menu button

for ten seconds.

3. Release the menu button and test the

kit’s buttons for proper operation.

ISO DIN head unit provisions

Notes

METRA. THE WORLD’S BEST KITS.™

1-800-221-0932 metraonline.com

INSTALLATION INSTRUCTIONS FOR PART 99-5825

REV. 7/13/11
