Miboxer Rainbow Remote S2-B Manuale utente
Button Diagram
Install Battery
Product Features
Product Parameters
Model No.: S2-B / S2-W / S2-G
2.4G Rainbow Remote (RGB+CCT)
Touch ring:
brightness, saturation, color temperature, RGB use together.
(It turns to adjust brightness by default if remote is not operated
for 3 seconds)
Model No.: S2-B / S2-W / S2-G
Working Voltage: 3V(AAA battery*2PCS)
Transmitting Power: 6dBm
Standby Power: 20uA
RF: 2.4GHz
Modulation Method: GFSK
Control Distance: 30m
This product adopt world-wide used 2.4GHz frequency, GFSK
control method, with features of low power consumption, long
distance transmitting, strong anti-interference and fast
comunication rate. It can control color, color temperature,
saturation and brightness of Mi-Light / MiBoxer 2.4G smart light.
Note: 2*AAA Battery need to buy seperately
1. Open battery cover
behind remote.
2. Install battery correctly and
close battery cover.
Turn on lights /
Dynamic mode /
Link / Unlink
Brightness /
Saturation
Turn off lights
RGB / Color temp.
24mm70mm
12power power 3Made in China
Linking Code / Unlinking Code Instructions
Linking Code Instructions
You can control lights after linking remote with light.
Attention
1. If indicator light flashes quickly when using, please replace
battery in time. Do not use poor quality battery in case of
leaving out liquid to damage remote.
2. Do not use remote in a large-scale metal area or an area
with strong electromagnetic waves nearby, otherwise
will affect communication distance seriously .
Short press key twice in succession, and then touch
to adjust RGB.
Function Description
Press key twice in succession, and then touch to
adjust color saturation of lighting. (Note: only in RGB mode)
Adjust saturation
Adjust RGB
Short press key once, then touch to adjust color temp.Adjust color temperature
Short press key once, then touch to adjust brightness.
Adjust brightness
Long press key until indicator light flashes twice, then
short press key to cycle switch.
(Note: it will exit automatically if no operation after 3 seconds)
Dynamic mode switching
ON
ON
Link/Unlink
button
power power
Link/Unlink
button
123Linking failed if light is not blinking slowly, Please follow
above steps again.(Note: lights that have linked can't
link again)
Unlinking failed if light is not blinking quickly, Please
follow above steps again.(Note: lights haven't linked
that don't need to unlink)
Switch off light after
10 seconds, then
switch on again.
Switch off light after
10 seconds, then
switch on again.
Short press "ON"
button 3 times
within 3 seconds
when light on.
Short press "ON"
button 5 times
within 3 seconds
when light on.
Lights blink 3 times
slowly means linking
is done successfully.
Lights blink 10 times
quickly means
unlinking is done
successfully.
Unlinking Code Instructions
