Motorola DCT2500 Manuale utente

The latest interactive digital cable set-top for standard-definition TV.

Motorola’s DCT2500 is a full-featured digital set-top providing a wide array of capabilities and ease of use.

DDCCTT22550000

DDiiggiittaallSSeett--ttoopp

The Motorola DCT2500 is a digital cable set-top that offers

enhanced features and capabilities. It provides state-of-the-art

digital compression technology, which means increased

"bandwidth" for more channels and services like high-definition

TV (HDTV) and Video on Demand (VOD), as well as support for

Internet, Electronic Program Guide (EPG), Pay-Per-View, e-mail,

home shopping, and more.

Platform versatility means that the Motorola DCT2500 will

continue providing growing services and increased viewing

capabilities. Its technology significantly boosts channel capability

while delivering digital audio and video quality to TV viewing.

Check with your local cable service provider for availability of the

DCT2500 in your area.

HIGHLIGHTS

• Open architecture supports downloaded third-party software

applications when offered through service providers

• Video image resizing for adjusting to different screen and window

sizes

• High-resolution on-screen graphics

• Enhanced memory for faster switching between menu screens and

digital channels

• Advanced security via Motorola DC-II conditional access and

Harmony keeps Internet hackers from gaining access to your TV

set-top

• Motion picture industry standard for coding and decoding video

(MPEG-2)

• AC-3 standard for 5.1 Dolby® Digital Surround Sound

MOTOROLA and the Stylized M Logo are registered in the U.S. Patent and Trademark Office. DOCSIS is a registered trademark of Cable

Television Laboratories, Inc. MediaCipher is a registered trademark of General Instrument Corporation. Moxi is a trademark of Digeo, Inc. All

other product or service names are the property of their respective owners.

To view our full line of Connected Home Solutions, visit our Web site at

broadband.motorola.com/consumers

521920-001

xxxx-0105-xK

DDCCTT22550000

DDiiggiittaallSSeett--ttoopp

FEATURES

175 MHz MIPS 32 CPU with 8 K instruction and 8 K data caches

High-speed, unified memory design with support for up to 64 MB of

DDR SDRAM

64 PID filters individually assignable to in-band or out-of-band

streams

Video decoder with enhanced VBI data processing capability

Analog/digital video scaling (picture in graphics)

High-resolution graphics with support for multiple planes as well as

current DCT2000 modes

MPEG-2 Digital Video Processor

ATSC standard Dolby Digital (AC-3) audio processor

ITU standard 64/256 QAM/FEC/enhanced adaptive equalizer

On-board real-time RF return (256 Kbps)

Clear Analog Channel Processor with BTSC Decoder

54–860 MHz tuner

DES-based encryption/DCII access control

Digital diagnostics

Frequency-agile 2.048 Mbps out-of-band data receiver

Macrovision copy protection

Wide screen (16 x 9) video support

Full feature access from front panel

Switched accessory outlet

OPTIONAL FEATURES

IR Blaster connection (remote control sensor extender)

RF bypass or A/B switch

Telephone modem (14.4 bps)

S-Video output

USB 1.1

Universal remote (DRC450)

Keyboard

STANDARD INTERFACES

Dolby® 5.1 digital audio output

RF and baseband output (video, L/R audio) ports

IR Blaster port

TVPASS® renewable security connector

High-/low-speed data output (27 and 2 Mbps)

RS-232 serial port

4-digit, 7-segment LED display with IR receiver for remote and/or

keyboard

GENERAL SPECIFICATION

Width x Height x Depth 17.13 x 13.25 x 2.75

Weight 8.6 lbs

Technical Specifications
