Motorola VIP1200 Manuale utente

igital

elevision

sers

uide

Celect Communications, LLC (dba West Wisconsin Video)

Fiber Optic Network

Getting Started

Turning your TV & Set-top Box (STB) ON/OFF using the Remote Control

Remote Control Guide

Menu Screen

Guide Menu

How toAccess the Guide Menu

Symbol Guide

Finding Programming

Setting a (One-Time) Reminder

SettingAutotune

Setting Scheduled Events

Purchasing a Pay-Per-View (PPV) Movie/Event

Canceling a PPV Movie/Event

PVR (Personal Video Recorder) Menu (if applicable)

How toAccess the PVR Menu

Controlling Live TV - Pause, Instant Replay, Rewind, Fast-Forward

Recording Programs

One Touch Recording

Schedule Recording(s)

Playing your Recording(s)

Deleting your Recording(s)

Vault Menu

Settings Menu

How toAccess the Setting Menu

Using Caller ID (On-Screen)

Using Channel Blocking

Using Parental Control

Unlocking/Reactivating Parental Controls

Changing Password and/or PIN#

Using Closed Captioning

Favorites Menu

Creating a Favorites Tab

Adding Channels to your Favorites List

Search Menu

Searching for a Program

Troubleshooting

Set-top Box (STB) Guide

TABLEOFCONTENTS

Basic Functions

Options for Changing Channels

Basic Navigation Tips

GETTINGSTARTED

Turning your TV & Set-top Box (STB) ON/OFF

using the Remote Control

• Press the button labeled STB, then press the button labeled POWER.

IF you press the POWER button & the TV DOES NOT Turn ON/OFF

IF you press the POWER button & the STB DOES NOT Turn ON/OFF

Press the button

labeled TV Press the button

labeled POWER Press the button

labeled STB

Press the button

labeled TV Press the button

labeled POWER

(To turn the TV OFF)

Press the button

labeled STB

VIP1200

< >

LINK HD RECORD

POWER MENU

ON THE STB

GREEN lighted

ring around the

power button

indicates the

STB is ON.

123

Press the button

labeled POWER

(To turn the

TV & STB ON)

2314

PVR Controls

POWER

STB (Set-top Box)

Press to select STB mode

switch.

DVD

AUX

(VCR, Stereo,Additional TV, etc.)

Press to selectAUX mode switch.

RECORDED TV

Press to access your Personnal

Video Recorder (PVR).

Press to display the Settings Menu.

VIDEO ON DEMAND (VOD)

Lists VOD movies.

BACK

Clears last digit entered.

Press to accept your selection.

ARROWS

Press the arrows to move the

highlight on screen.

INFO

Press to display information for a

program.

GUIDE

Press to view on-screen program

guide.

EXIT

Press to return to live TV.

NUMBER PAD

Use to enter channel numbers,

passwords, etc.

LAST

Press to return to the last

channel viewed.

CH / PG

Changes channels in live TV.

Scrolls a full page in the GUIDE.

MUTE

Press to turn sound on & off. ENTER

Makes your selection.

REPLAY

Jumps back 8 seconds.

FWD

Jumps ahead 8 seconds.

Equipment Controls

(Mode Switches)

Navigation Controls

Number Pad &

Volume Control

RECORD

Press to record live TV.

REW

Press up to 4 times to rewind at

increasing speeds.

Press up to 4 times to fast-

forward at increasing speeds.

VOL

Press to increase or decrease

volume control.

(In STB mode switch) turns

BOTH STB and TV on/off.

[Note: TV, DVD orAUX mode

switch, turns on/off only speciﬁed

equipment.] TV/VIDEO

Press to select DVD mode switch.

Press to select TV mode

switch.

Press to switch inputs.

PAUSE

Press to pause live TV.

PLAY

Press to play current video.

STOP

In Recorded TV, stops playback.

REMOTECONTROLGUIDE

Options for Changing Channels

Enter the desired channel

number using the Number Pad.

Option

•Use the up, down arrows to view channels at the present

time. Use the left, right arrows to view the current channel’s future

programming.

•Press once to select desired channel.

Option OK

BASICFUNCTIONS

• Pressing the LAST button will take you to the last channel viewed.

Option Press the button to view the next or previous numbered

channel.

•GREEN is always the highlight color. As you navigate channel list-

ings using your remote, the highlight appears on screen to indicate

your current selection.

• Pressing on your remote will return you to watching Live TV.

EXIT

Basic Navigation Tips

Option • Press to view complete list of channels & programming.

• Using the or scroll up or down to view channels.

• Press to select desired channel.

GUIDE

MENUSCREEN

Menu Screen

The Menu Screen is an easy

access to any features you may

have. Pressing the button will

provide you the following options:

Guide - Using the Guide Menu

allows you to view program listings of

what’s on now and what will be on in

the future.

PVR (if applicable) - Using the PVR Menu, also known as a DVR, allows

you to record programs on your Set-top Box (STB) and view at a later

time as well as pause, fast forward, play or rewind current programs.

Vault - Using the Vault Menu allows you to view history of Pay-Per-View

(PPV), Reminders, Messages and Caller ID.

Parental Controls -(Appears if feature is ON.)

Settings - Using the Setting Menu allows you to create/edit preferences,

create/edit users, view packages you are subscribed to and view billing

information.

Favorites - Using the Favorites Menu allows you to “tag” your favorite

channels.

Search - Using the Search Menu allows you to enter in keywords to ﬁnd

programs related to your keyword.

11:00am

wwisconsin

Guide

PVR

ault

Settings

Favorites

Celect

Communications 23 2008//09

GUIDEMENU

Guide Menu

The Guide Menu allows you to view

information of current and future

programming including:

Channel Name, Channel

Number, Brief Description of

Program, Rating, Start and End

Times, Date

Celect

Communications

9:25 am

24 CNN

25 CNNH

26 MSNBC

27 CNBC

28 ESPNC

CNN Newsroom

Morning Express

MSNBC News Live

Squawk on the Street

Beach Volleyball

Showbiz tonight

MSNBC News...

Billiards

The Call

Subscribed

10/02/2008 9:00 am 10:00 am9:30 am

CNN Newsroom

8:00 am – 11:00 am, TV

Options To Access the Guide Menu

GUIDE

Press

Option • Press

• Using the

• Highlight GUIDE

• Press

Option

Symbol Guide

Indicates the channel is part

of the active FAVORITES

list.

Indicates the program is

set for AUTOTUNE once.

Indicates the program is

set for a REMINDER once.

Indicates the program is

set to RECORD once. Indicates the program is

scheduled to RECORD

repetitively.

Indicates the program is

scheduled to give a

REMINDER repetitively.

Indicates the program is

scheduled to AUTOTUNE

repetitively.

Indicates the channel is

BLOCKED.

QUICK TIP

Press

repeatedly to

scroll through

the (green)

Guide Tabs.

GUIDE

GUIDEMENU

Finding Programming

Setting a (One-time) Reminder

Setting Autotune

QUICK TIP

Quickly scroll through

the GUIDE screen

using the button.

• Press to view complete list of channels & programming.

• Using the scroll up or down to view channels one-by-one.

• Press to select desired channel.

GUIDE

• Press to view complete list of channels.

• Use the to scroll through channels to ﬁnd program of choice.

• Press to highlight your program choice.

• Use the to scroll down to SET REMINDERS and press .

• When a Reminder is set, will appear on the channel.

GUIDE

• Press to view complete list of channels.

• Use the to scroll through channels to ﬁnd program of choice.

• Press to highlight your program choice.

• Use the to scroll down to SET AUTOTUNE and press .

• When Autotune is set, will appear on the channel.

GUIDE

When a program is set to Autotune, your screen will automatically switch

to the program when the program is starting.

When a program is set with a Reminder, a pop-up reminder will appear

when the program is starting.

GUIDEMENU

Schedule Event

To Edit, highlight the item. Press OK

And use the arrow keys to change the settings.

Press OK again to end the edit

SportsCenter

Ch: 29 ESPN For: 01 hrs 00 mins

On: 10 01 At: 12 00 pm

Type: Reminder Freq: Single

OK Cancel

Setting a Scheduled Event

A Scheduled Event allows you to set

up Reminders and Autotune for future

programming. The event(s) can be

set to occur Single, Weekly, Every

M-F, Every Day.

QUICK TIP

To schedule a Recording you

must have the PVR STB.

See “Schedule a Recording(s)”.

• Press to view complete list of channels.

• Use the to scroll through channels to ﬁnd program of choice.

• Press to highlight your program choice.

• Use the to scroll down to SCHEDULE EVENT and press .

• The pop-up box allows you to select the channel, length of time, the date,

the start time, the type of event and the frequency.

To edit the Schedule Event pop-up box:

• Use the to highlight the desired ﬁeld and press .

• Press up or down to change the information.

• Press to select the criteria.

• When your criteria has been set, use to highlight OK and

press .

• When a Scheduled Event is set, or will appear on the channel.

GUIDE

GUIDEMENU

Purchasing a Pay-Per-View (PPV) Movie/Event

QUICK TIP

You must buy the movie/event before or within 10 minutes of the start time.

• Press

• Use the to scroll movies/events for the day.

• Highlight the movie/event you would like to buy and press .

• Scroll BUY PPV and press .

• The purchase price will be displayed. To accept the charges enter your

PIN# (if PIN is enabled in Setting) and select BUY.

GUIDE

Canceling a PPV Movie/Event

You can cancel a PPV Event, BEFORE the movie/event is scheduled to

start. You cannot cancel an All Day Ticket (ADT) or a PPV Movie/Event

AFTER it has started.

• Press

• Use the to highlight the movie/event you would like to cancel and

press .

• Scroll and highlight CANCEL PPV PURCHASE and press .

GUIDE

QUICK TIP

To enable or change your PIN#, see

“Changing Password and/or PIN#”

QUICK TIP

Your default PIN# is the last 4

digits of your phone number.

Altri manuali per VIP1200

Indice

Altri manuali Motorola Decoder

Motorola

Motorola DCT700 Manuale utente

Motorola

Motorola DCX3200 P2 Manuale utente

Motorola

Motorola DCX3300 Manuale utente

Motorola

Motorola QIP7232 P2 Manuale utente

Motorola

Motorola DCT1700 Manuale del proprietario

Motorola

Motorola QIP7000 (P2) Series Manuale utente

Motorola

Motorola DCX3200 Manuale utente

Motorola

Motorola VIP1200 Manuale utente

Motorola

Motorola DCX3200 P2 Manuale utente

Motorola

Motorola HDTV Manuale utente

Motorola

Motorola MTS HDTV set-top box Manuale utente

Motorola

Motorola VIP 1963 Manuale utente

Motorola

Motorola DCT3400 Series Manuale utente

Motorola

Motorola DCT3400 ALL-DIGITAL SET-TOP - TV GUIDE... Manuale utente

Motorola

Motorola RNG200N Manuale utente

Motorola

Motorola VIP1002E Manuale utente

Motorola

Motorola DCX700 Manuale utente

Motorola

Motorola DCX3220e Manuale utente

Motorola

Motorola DCH6416 Manuale utente

Motorola

Motorola DCT6412 DUAL-TUNER DVR AND HD SET-TOP - MICROSOFT... Manuale utente

Motorola

Motorola DCT2500 Manuale utente

Motorola

Motorola DCH70 Manuale utente

Motorola

Motorola xfinity RNG150N Manuale utente

Motorola

Motorola DCT1800 Manuale utente

Manuali Decoder popolari di altre marche

VBrick

VBrick 8000-0188 Manuale utente

Kogan

Kogan KGNPVR500VAA Manuale utente

Asus

Asus O!PLAY MEDIA PRO Manuale utente

Samsung

Samsung ICU 100 Manuale utente

VECTORMAX

VECTORMAX A12E Manuale utente

DStv

DStv Explora Manuale utente

Ace Digital TV

Ace Digital TV ADB 3800 Manuale utente

Cisco

Cisco 4398DVB Manuale utente

Polaroid

Polaroid KHA-01651B Manuale utente

Samsung

Samsung GX-SM530CF Manuale utente

BT Business Total Broadband Manuale utente

Megasat

Megasat HD 720 plus Manuale utente

Sungale

Sungale STB608 Manuale utente

Amino

Amino Amigo 7X Manuale utente

Geniatech

Geniatech ATV225 Manuale utente

Android

Android Androidminibox mx2 se Manuale utente

Hama

Hama Internet TV Box Manuale utente

Ariva

Ariva T650i Manuale utente
