Navitar 1-62316 Guida
REV CHANGERECORD AND DATECH
ROCHESTER,NEWYORK
REV
SIZE
B
P/NSUFFIXDEFINITION
-1CONVERSIONCOATING
-2PAINTING
-3MARKING
-RREWORK
UNLESS OTHERWISE
SPECIFIED
DIMENSIONSAREININCHES
AND INCLUDECHEMICALLY
APPLIEDORPLATEDFINISHES
DEC..XXX `.005
DEC..XX `.010
FRACT.`1/64
ANGLES `30'
CONCENTRICITY.003 TIR
BREAK ALL SHARPEDGES
.005 MIN..010 MAX
MAX.SURF.ROUGHNESS 32
TOLERANCES:
MATERIAL:
FINISH:
CHAMFERALL THREADS
30~TOROOTDIAM.
USEDON:
SCALE:
DR.:
CH.:
APP.:
DATEDR.:
DONOTSCALEDRAWING
0.0mm 25.0
0.0inch1.0
SHEETOF
THECONTENTSOFTHIS
DOCUMENTAREPROPRIETARY
TONAVITAR,ITSUSE IS
AUTHORIZEDONLYFOR
RESPONDINGTOREQUEST
FORQUOTATIONOR
PERFORMANCEOFWORKFOR
NAVITAR
1-62316 A
11
R.PODLENA
P.BONAFEDE
11/22/2002
MOTORIZED(STEPPER)6x
ULTRAZOOM&12mm FF,DUAL2
POSITIONLS(HE)
1:1
ARELEASE 06/12/03
OUTLINE
M25x.75T
n1.25 [31.8]
n1.60 [40.6]
1.312n-.001
.000+
.14 [3.4]1.05 [26.7]
4.67 [118.6]
.60 [15.2]
2.20 [56.0]
1.33 [33.8]
1.47 [37.3]
MOTORWIRECONFIGURATION
PIN
1MOTORA+
3+5Vdc
6MOTORB+
7MOTORA-
8FARLIMIT
11 MOTORB-
12 NEARLIMIT
13 COMMON
