Reporting for Call Center

Release 2.2.1xx

Document Number: 200-0400-110

Document Status: Standard

Document Version: 3.02

Part Code: N0078143

October 2005

Upgrading from Call Center Reporting to

Reporting for Call Center

Upgrade Document

The information in this document is subject to change without notice. The statements, configurations, technical data,

and recommendations in this document are believed to be accurate and reliable, but are presented without express or

implied warranty. Users must take full responsibility for their applications of any products specified in this

document. The information in this document is proprietary to Nortel Networks.

Trademarks

*Nortel, Nortel Networks, Nortel (Logo), Nortel Networks (Logo), the Globemark, and This is the way, This is

Nortel (Design mark), This is Nortel Networks (Design mark) are trademarks of Nortel Networks.

*Microsoft, MS, MS-DOS, Windows, and Windows NT are registered trademarks of Microsoft Corporation.

All other trademarks and registered trademarks are the property of their respective owners.

Table of Contents

Change History...................................................................................1

How to use this guide ........................................................................3

Introduction.........................................................................................................3

How this guide is organized ................................................................................3

Introduction ........................................................................................5

Upgraded Browser-Based Interface................................................................5

Upgraded Web Host PC software...................................................................5

Upgrade! No Multiple Client software to install................................................5

Upgrade! No Upload of Call Center Configuration...........................................5

Can the old Master PC be used as the Web Host PC? ...................................6

Do I have to remove the old Nortel Call Center Reporting 2.5, 3.0, or 3.5 software? 6

Can the upgraded software co-reside with the old software? ..........................6

Minimum PC and Operating System Requirements ........................................7

Operating System Compatibility .....................................................................8

Installation ..........................................................................................9

Introduction.........................................................................................................9

Installation prerequisites .....................................................................................9

Installing Nortel Networks Reporting for Call Center software ............................10

TCP/IP Protocol ...........................................................................................10

Checking whether the Windows Networking Component is Installed.............10

Installing Nortel Networks Reporting for Call Center ..........................................11

Configuration....................................................................................19

Quick Steps to Configure Nortel Networks Reporting for Call Center .................19

Before You Begin.........................................................................................19

Configuring Nortel Networks Reporting for Call Center .................................19

Verification........................................................................................26

Accessing the Real Time Screens.....................................................................26

Reporting Option..........................................................................................26

References ........................................................................................32

Index..................................................................................................34

List of Figures

Figure 1: InstallShield Initialization Dialog Box.........................................................................................................12

Figure 2: Language Selection Dialog Box...................................................................................................................12

Figure 3: InstallShield Windows Installer Configuration Dialog Box.........................................................................13

Figure 4: InstallShield Wizard Start Dialog Box.........................................................................................................13

Figure 5: License Agreement Dialog Box ...................................................................................................................14

Figure 6: Customer Information Dialog Box...............................................................................................................15

Figure 7: Choose Destination Location .......................................................................................................................16

Figure 8: Setup Status Dialog Box ..............................................................................................................................17

Figure 9: Database Installation Dialog Box.................................................................................................................17

Figure 10: Java Installation Dialog Box ......................................................................................................................17

Figure 11: Installation Complete Dialog Box..............................................................................................................18

Figure 12: Login Page .................................................................................................................................................20

Figure 13: Change Password Page...............................................................................................................................21

Figure 14: Administration Menu Page.........................................................................................................................22

Figure 15: Call Center Connection Page .....................................................................................................................23

Figure 16: Download Status Window..........................................................................................................................24

Figure 17: Administration Menu Page.........................................................................................................................26

Figure 18: User Main Menu ........................................................................................................................................27

Figure 19: Real Time Menu Page................................................................................................................................28

Figure 20: Real Time Summary Skillset Selection Page .............................................................................................29

Figure 21: Real Time Summary Page..........................................................................................................................30

Change History 1

Issue 03 (02) Upgrading from Call Center Reporting to Reporting for Call Center

Change History

Issue 01 (01) – 15-December-2003

1. Original Release.

Issue 01 (02) – 23-January-2004

1. Amended as per Nortel team review feedback.

Issue 01 (03) – 4-April-2005

1. 2003 Server support note added.

2. Changed to be BCM – version agnostic.

Issue 02 (01) – 8-July-2005

1. Nomenclature changes to support new product branding.

2. Updated all relevant text and screenshots to support product changes in RCC.

Issue 02 (02) – 19-September-2005

1. Edited text.

2. Standardization made to figure labels, headers, formatted text and added cross-

references.

Issue 03 (01) – 19-October-2005

1. Nomenclature changes to support product branding of Reporting for Call Center.

2. New screenshots and editing of text in line with Reporting for Call Center.

Issue 03 (02) – 24-October-2005

1. Updated figure numbers in the List of Figures.

2. Changed Release number and updated Document Number and Document

Version.

Change History

Issue 03 (02) Upgrading from Call Center Reporting to Reporting for Call Center

How to use this guide

Introduction

This guide is designed to lead you through the process of upgrading from Nortel Networks Call

Center Reporting 2.5/3.0/3.5 to Nortel Networks Reporting for Call Center.

How this guide is organized

The Upgrading from Call Center Reporting to Reporting for Call Center guide is organized as

follows:

How to use this guide This chapter provides a brief overview identifying the

organization of this guide.

Introduction This chapter gives a background to the upgrade process

and what it involved. The chapter describes some

differences between the previous architecture products and

the updated architecture. The chapter also answers some

questions you may have about the upgrade process.

Installation This chapter describes how to install Nortel Networks

Reporting for Call Center.

Configuration This chapter describes how to configure Nortel Networks

Reporting for Call Center including verification of a

successful installation .

Verification This chapter describes how to verify that Nortel Networks

Reporting for Call Center is communicating correctly with

the Call Center.

References This chapter lists documents referenced in the body of this

guide.

Index Provides a cross-reference of topics in this document.

Issue 03 (02) Upgrading from Call Center Reporting to Reporting for Call Center

Introduction 5

Issue 03 (02) Upgrading from Call Center Reporting to Reporting for Call Center

Introduction

Upgraded Product Architecture

Nortel Networks Reporting for Call Center has undergone several major changes from previous

versions of Nortel Networks Call Center Reporting 2.5/3.0/3.5. The following sections list some

main differences between the upgraded architecture and the previous versions.

For a full description of the upgraded features of Nortel Networks Reporting for Call Center,

refer to the Reporting for Call Center Setup and Operations Guide.

Upgraded Browser-Based Interface

Nortel Networks Reporting for Call Center is a reporting tool for the Call Center. It has a

browser-based interface, visually similar to the Call Pilot Manager. As with the Call Pilot

interface, it is accessed from an Internet Explorer browser session.

Upgraded Web Host PC software

Nortel Networks Reporting for Call Center has a single software installation on one Personal

Computer (PC). This PC is the Web Host PC, which functions similarly to the Master PC in the

former Nortel Networks Call Center Reporting 2.5/3.0/3.5 streams.

The Web Host PC stores the historical statistical databases. It is connected to the Call Center to

obtain the historical statistical information and Real Time screen information.

The wallboards are also driven from the Web Host PC.

Upgrade! No Multiple Client software to install

In the Nortel Networks Reporting for Call Center streams, the customer had to install ‘Multiple

Client’ software onto other PCs to view the Real Time screens or Reports.

With Nortel Networks Reporting for Call Center, the users of those other PCs use Internet

Explorer to browse back to the Web Host PC to access the Real Time screens and Reports.

No Client software is now required for the other PCs.

Upgrade! No Upload of Call Center Configuration

In the Nortel Networks Call Center Reporting 2.5/3.0/3.5 streams, the customer had to upload the

Call Center configuration to view the Agent, Line, and Skillset names in the Reports and Real

Time screens. If the Call Center configuration was modified, the Configuration Upload step had

to be performed again.

Nortel Networks Reporting for Call Center automatically obtains the information it needs for the

Real Time screens and Reports from the Call Center, and it does not need to store a copy of the

Call Center configuration.

Introduction

Upgrading from Call Center Reporting to Reporting for Call Center Issue 03 (02)

No Upload Configuration step is required in the configuration and maintenance of the Nortel

Networks Reporting for Call Center software.

Can the old Master PC be used as the Web Host PC?

If the PC hardware and operating system meet the minimum specifications, then the answer is

Yes. See below, Can the upgraded software co-reside with the old software?.

Do I have to remove the old Nortel Call Center Reporting 2.5, 3.0, or 3.5 software?

No, but you can if it is no longer needed. See the following section, Can the upgraded software

co-reside with the old software?.

Can the upgraded software co-reside with the old software?

None of the Nortel Networks Call Center Reporting 2.5/3.0/3.5 software is required for the

operation of the upgraded Nortel Networks Reporting for Call Center software.

However, the customer may choose to retain the Nortel Networks Call Center Reporting

2.5/3.0/3.5 software to allow them to review the historical reports that are stored on their old

system.

Leaving the Nortel Networks Call Center Reporting 2.5/3.0/3.5 Master or Multiple Client

software on the PC that will be used as the Web Host PC does not affect the operation of Nortel

Networks Reporting for Call Center.

The two different applications can co-reside on the same PC with no interaction.

Installing Nortel Networks Reporting for Call Center on a PC on which Nortel Networks Call

Center Reporting 2.5/3.0/3.5 is already installed does not affect the operations of either

application.

Note: If the Nortel Networks Call Center Reporting 2.5/3.0/3.5 software is configured to power

any IP wallboards that Nortel Networks Reporting for Call Center is going to power,

remember to remove them from the Nortel Networks Call Center Reporting 2.5/3.0/3.5

configurations. Otherwise, both sets of software try to power the wallboards, which results

in the wallboard display alternating between the two sets of data from the two different

applications.

Note: The specification of the hardware used as the Master PC for the Nortel Networks Call

Center Reporting 2.5/3.0/3.5 software might not be sufficient to support the Nortel

Networks Reporting for Call Center software. See the following section, Minimum PC and

Operating System Requirements.

Altri manuali per Call Center Telephone

Indice

Altri manuali Nortel Software

Nortel

Nortel CC MIS Manuale utente

Nortel

Nortel Manager Manuale di istruzioni

Nortel

Nortel BCM200 Guida rapida alla configurazione

Nortel

Nortel SREM Manuale utente

Nortel

Nortel CCT Manuale di istruzioni

Nortel

Nortel 2350 Manuale utente

Nortel

Nortel Norstar ICS Remote Tools 11 Manuale utente

Nortel

Nortel Agent Manuale utente

Nortel

Nortel Voice Mail Guida di riferimento

Nortel

Nortel AS 5300 Manuale utente

Nortel

Nortel 2350 Manuale utente

Nortel

Nortel Passport 4400 Guida

Nortel

Nortel Viewer Manuale utente

Nortel

Nortel Viewer Manuale utente

Nortel

Nortel INM 3.1 Manuale di istruzioni

Nortel

Nortel Contact Center Manager Manuale del prodotto

Nortel

Nortel Observe Manuale utente

Nortel

Nortel Contact Center Manager Manuale utente

Nortel

Nortel BCM 4.0 Manuale utente

Nortel

Nortel BCM 4.0 Manuale di installazione e funzionamento

Nortel

Nortel Alteon OS 42C4911 Guida utente

Nortel

Nortel Voice Mail Manuale utente

Nortel

Nortel Configuration Manager Guida rapida

Nortel

Nortel 2070 Guida rapida

Manuali Software popolari di altre marche

COMPRO

COMPRO COMPROFM Manuale utente

Muratec

Muratec OFFICEBRIDGE ONLINE Manuale utente

Oracle

Oracle Contact Center Anywhere 8.1 Manuale utente

Adobe

Adobe 65007312 - Photoshop Lightroom Manuale

Avaya

Avaya NULL One-X for RIM Blackberry Manuale utente

HP ProLiant BL420c Manuale utente

PS Audio

PS Audio PowerPlay Manuale del proprietario

Brady

Brady LOCKOUT PRO 3.0 Manuale di servizio

Avaya

Avaya Interaction Center Manuale utente

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuale

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manuale utente

Oracle

Oracle Application 9i Manuale utente

Acer

Acer RDM Manuale utente

Canon

Canon Vixia HF21 Manuale utente

Canon

Canon ZR950 Manuale utente

Samsung

Samsung Auto Backup Manuale utente

Polycom

Polycom Vortex EF2201 Istruzioni per l'installazione e il funzionamento

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manuale utente
