OPTO-EDU A22.1201 Manuale utente

A22.12 01

Student Biological

Instruction Manual

To ensure the safety and obtain satisfactory performance, please study this instruction manual thoroughly be

fore start to use the instrument.

www.cnoec.com.cn

Contents:

I, The applications

II, Names of the parts, components and accessories

III, Major technical index

IV, How to use

V, Lamp & fuse replacement

VI, Maintenance and general care of your microscope

VII, Optional accessories

Applications:

Widely used in electronics industry, assembling and inspection of

precise instruments and meters, educational experiments,

observation and research. It can be used in the schools, research

institutes, factories, and families to study the geology, out appearance

of objects.

Names of the parts and accessories :

Base, fixing block, sliding stand, pole , hand clamp, incident

illuminator,

Eyepieces, diopter adjustment ring, prism housing, objective,

power switch

Major technical index:

1, optical index: Field scope, Working distance,

2, electric index: input voltage: 220V 50Hz or 110 60Hz(optional)

Illumination style:

1), natural light

2),The illumination coming from the source of a ball shaped

lamp(A/C12V/10W or 6V6W) through the condenser, becomes soft and

brighter. (optional)

3), structure index: binocular head slanting 45 degrees

left & right diopter adjustment +/- 5 degrees

inter-pupillary adjustable distance: 54---76mm

www.cnoec.com.cn

How to use: Regarding the names of the parts please refer

to Part II.

1, environmental requirement when in use:

Dry and dust-free. Room temperature should be between –5----+40 C

2, Illuminator control: Plug in the power cord and use the switch.

3, One pair of rubber eye guards is contained inside the packing. They

are used to prevent the extra light from entering the eyepieces, to

improve visibility.

Focusing, diopter, inter-pupillary adjustments:

Place a specimen onto the stage. Loose the body locking thumb

screw and hold the microscope head and move the body up and down

to fix it at the estimated working distance. Rotate the zooming knob

while looking through the right eyepiece until you see the image.

Using the focusing handles to get the sharpest image of the specimen.

Then look through the left eyepiece with your left eyes and turn the

diopter adjustment ring until you get an image as sharp as the right

one. Then grasp the right and left prism housing and move them

closer or father apart in order to match your pupils’ distance.

Adjustment is proper when the field of view becomes comfortable and

presents a full single field.

Lamp and fuse replacement:

Disconnect electric power supply before replacement! Make sure the

bulb to be replaced is not hot.

1, replacement of incident lamp: Take off the incident lamp tube

assembly and you will be able to replace the bulb.

2, Replacement of fuse: Unscrew the fuse holder at the back part of

the base and change the fuse .

Maintenance and general care of your microscope:

1, Microscope is a delicate precision instrument and it may be

www.cnoec.com.cn

damaged by dropping and hitting.

2, Do not keep microscope under sun. It should be kept in a dry and

clean environment and avoid heat and strong tremor.

3, To obtain clear image, do not touch lenses with your finger.

4, All lens surface should be kept clean. If the lens get dusty blow off

the dust with a rubber syringe. If necessary clean the lenses with a lint

free cloth dipped in aether.

5, Do not use any organic material to clean the microscope surface,

especially the plastic surface. It should be cleaned by neutral

detergent.

6, Because the assembly of all parts has been done by skilled optical

craftsmen at the factory, you should never attempt disassembly.

7, Apply a little bit grease regularly to the mechanical parts.

8, When not in use always cover the microscope with the dust cover

and place it in a cool and dry place.

Optional parts:

1, Eyepieces:

Models

Magnifications

Viewing field

2, Objectives:)0.5X 1.0X

www.cnoec.com.cn

1 Incident light 9 Illumination cable

2 Eyepiece 10

Fastening knob

3 Prism housing 11

connector

4 Holder 12

Horizontal pillar

5 Objective case 13

Pillar

6 Switch 14

Connect spanner

7 Power cable 15

Focusing knob

8 Base
