Parker 60VM4071 Manuale utente
Explosion Proof Electric Actuated
Shut-Off/ Flow Regulating
Needle Valve
Operation and Maintenance Manual
Catalog: 02-9342ME January 2017
2
Parker Autoclave Engineers
Instrumentation Products Division
Erie, PA USA
www.autoclave.com | Cat. 02-9342ME
Model #
Serial #
Table of ConTenTs page
1.0 Introduction .......................................................................................................... 2
2.0 Meaning of Safety Words...................................................................................... 2
3.0 TechnicalSpecication ......................................................................................... 2
4.0 Drawings .............................................................................................................. 3
5.0 Installation ........................................................................................................... 3
6.0 Service ................................................................................................................. 4
Section 1.0
Introduction
The Parker Autoclave Engineers Electric Flow Control valves are
designed to operate up to 60,000 psi depending on the model
number. The valves are "fail-as-is" meaning the valve maintains
its last position on signal or power failure.
Section 2.0
Meaning of Safety Words
A safety related message is identied by a safety alert symbol
and a signal word to indicate the level of risk involved with a
particular hazard. The denitions of the three signal words are
as follows:
indicates a potentially hazardous
situation which, if not avoided, could result
in death or serious injury.
indicates a potentially hazardous
situation which, if not avoided, may result
in minor or moderate injury.
WARNING
!
CAUTION
!
Section 3.0
Technical Specication
Electrical Power
Power Required: 24 VDC/72 Watt Maximum
Input Impedance: 250 Ohms (4-20 mA input)
Environmental
Atmosphere: NEC CLASS I, DIV 1, GROUP B,C,D
Operating Tempertaure (Actuator): -40º to 85º C
Maximum Weight: See drawing.
Dimensions: See drawing.
Personnel:
Installation must be carried out by qualied personnel
familiar with all pertinent wiring practices, codes, and safety
procedures.
Read this manual in its entirety prior to any attempt to
install, operate, or perform maintenance on the
Electric Flow Control Valve.
If you are unsure of how to proceed, please contact Parker
Autoclave Engineers Service Department at (814) 860-5700
or fax us at (814) 860-5811.
!
CAUTION
Internal dip switches are factory set. Do not adjust switches
unless directly advised in Section 6 (Service) of
this manual.
!
CAUTION
3
Parker Autoclave Engineers
Instrumentation Products Division
Erie, PA USA
www.autoclave.com | Cat. 02-9342ME
Section 4.0
Drawings
VALVE SERIES DRAWING
1/8"10V AE003953
1/4"10V AE003954
3/8"10V AE003955
1/2"10V AE003956
1/4"SW AE003957
3/8"SW AE003958
1/2"SW AE003959
1/4"20SM AE003960
3/8"20SM AE003961
9/16"20SM AE003962
1/48"30VM AE003963
3/8"30VM AE003964
9/16"30VM AE003965
1/8"60VM AE003966
3/8"60VM AE003967
9/16"60VM AE003968
Section 5.0
Installation
Electrical Wiring:
The actuator comes with a female 1/2" NPT connection for the
user to connect their electrical piping. It is the responsibility
of the user to connect to the actuator in a way that meets their
hazardous location codes. The electrical wiring is connected at
the terminal block as indicated on photo and schematic below.
Signal Positioning:
A 4-20mA signal corresponds to a 0-100% open position.
A 4.0mA signal directs the valve to a fully closed position.
When a 20mA signal is given the valve is fully opened a full
5 turns. The relationship between the signal and the valve
position is linear.
High Pressure Plumbing:
Refer to the Tools and Installation section of the Parker
Autoclave Engineers VFT product catalog.
Wiring schematic:
ISO-9001 Certifie
d
Switches 1 through 11 are factory set and will vary
depending on the valve type.
Do not adjust switches 1 through 11.
!
CAUTION
02-9342ME January 2017© 2017 Parker Hannin Corporation | Autoclave Engineers is a registered trademark of the Parker Hannin Corporation
Parker Hannin Manufacturing Ltd.
Instrumentation Products Division, Europe
Industrial Estate Whitemill
Wexford, Republic of Ireland
PH: 353 53 914 1566
FAX: 353 53 914 1582
Instrumentation Products Division
Autoclave Engineers Operation
8325 Hessinger Drive
Erie, Pennsylvania 16509-4679 USA
PH: 814-860-5700 FAX: 814-860-5811
www.autoclave.com
WARNING
FAILURE, IMPROPER SELECTION OR IMPROPER USE OF THE PRODUCTS AND/OR SYSTEMS DESCRIBED HEREIN OR RELATED ITEMS CAN CAUSE DEATH, PERSONAL INJURY
AND PROPERTY DAMAGE.
This document and other information from Parker Hannin Corporation, its subsidiaries and authorized distributors provide product and/or system options for further investiga-
tion by users having technical expertise. It is important that you analyze all aspects of your application and review the information concerning the product or system in the current
product catalog. Due to the variety of operating conditions and applications for these products or systems, the user, through its own analysis and testing, is solely responsible
for making the nal selection of the products and systems and assuring that all performance, safety and warning requirements of the application are met. The products described
herein, including without limitation, product features, specications, designs, availability and pricing, are subject to change by Parker Hannin Corporation and its subsidiaries at any
time without notice.
Offer of Sale
The items described in this document are available for sale by Parker Hannin Corporation, its subsidiaries or its authorized distributors. Any sale contract entered by Parker will be
governed by the provisions stated in Parker's standard terms and conditions of sale (copy available upon request).
Section 6.0
Service
For valve maintenance or packing leaks refer to the Manual Valves Operation and Maintenance Manual (Catalog# 02-0024ME).
RE-ZERO THE VALVE AFTER MANUAL ADJUSTMENT. REMOVE THE TOP COVER AND APPLY POWER TO THE ACTUATOR AND
CYCLE DIP SWITCH 12 FROM OFF TO ON AND BACK TO OFF. VERIFY THAT THE VALVE STARTS TO MOVE. THE VALVE WILL
RUN UNTIL IT COMPLETELY CLOSES. IT IS NOW READY FOR OPERATION.
For service, contact the Parker Autoclave Engineers’ Representative in your area or phone Parker Autoclave Engineers’ Support
Services at 1-814-860-5703.
