PEERLESS IWB600-WB Manuale utente

SMART Board SB685 and SB690 mount

For attachment over a marker board/chalkboard

The IWB600-WB wall mount for SMART Boards models SB685 and SB690 is the cost-effective

solution for effortlessly adding interactive SMART Boards to classrooms or boardrooms.

Designed to t directly over the existing chalkboard, these SMART Board mounts are easy

to install and simple to adjust.

VIEWING FLEXIBILITY

Can be adjusted vertically

and horizontally

EASY INSTALLATION

Hook-on design can be

installed by a single person

IWB600-WB

Compatible with 87"

SMART Board SB685 and

94" SMART Board SB690

 Hook-on design allows for

single person installation

Vertical and horizontal

SMART Board adjustment

 Mounts over the existing

marker board/chalkboard

CLICK: www.peerlessmounts.com CALL: 800.865.2112 FAX: 708.865.2941

FEATURES

Max load: 50lb (22kg)

Safety LockImage StabilityClean Installation

STURDY CONSTRUCTION

Provides sturdy and stable

SMART Board support

PACKAGE SIZE (W x H x D) PACKAGE SHIP WEIGHT PACKAGE UPC CODE PACKAGE CONTENTS UNITS IN PACKAGE

IWB600-WB 17.0” x 5.0” x 68.0”

(432 x 127 x 1727mm) 23lb (10kg) 735029269717

Wall Bracket, Vertical

Rails, Horizontal Rails and

Fasteners to attach

to the screen

Package Speciﬁcations

DImENSIONS (W x H x D) PRODUCT WEIGHT LOAD CAPACITy FINISH AVAILABLE COLORS

IWB600-WB 59.0” x 58.5” x 4.0”

(1499 x 1486 x 102mm) 20lb (9kg) 50lb (22kg) Powder coat Silver

Product Speciﬁcations

Model Numbers WARRANTY: Limited 5-year

A R C H I T E C T S S P E C I F I C A T I O N S

The Wall Mount for SMART Boards SB685/SB690 shall be a Peerless model IWB600-WB and shall be located where indicated on the plans.

The nish shall be scratch resistant silver. Assembly and installation shall be done according to instructions provided by the manufacturer.

Peerless Industries, Inc. 3215 W. North Avenue Melrose Park, IL 60160 (800) 865-2112 (708) 865-8870 Fax: (708) 865-2941 www.peerlessmounts.com

All dimensions = inch (mm)

IWB600-WB: SMART Board SB685 and SB690 mount for attaching over a marker board/chalkboard

LIT-0560

59"

(1499 mm)

58.57"

(1488 mm)

(51 mm)

55"

(1397 mm)

4.14"

(105 mm)

54.4"

(1382 mm)

3.59"

(91 mm)

48"

(1219 mm)

50"

(1270 mm)

68"

(1727 mm)

FRONT VIEW

SIDE VIEW

ISO VIEW
