Phase Technologies CS-525 Manuale utente

T E C H N O L O G Y

In-wall & In-ceiling Systems With High-end Tonal Balance

Extended power handling

Phase Tech’s CS Series offers extended

performance and power handling for in-

ceiling or in-wall applications. Each model

features extra-high sensitivity to assure

satisfying volume, even with low-pow-

ered distribution systems.

CS-6R/PT

2-Way 6.5” woofer with .75” pivoting

tweeter CS-6R/PT incorporates a .75” dome

tweeter and 6.5” woofer, offering extended

performance and power handling for out-

standing reproduction of movies and music.

The pivoting tweeter allows the speaker to

be properly aimed at the listener in off-axis

mounting situations.

CS-6R

2-Way 6.5” woofer with .75” ﬁxed tweeter

CS-6R incorporates a .75” dome tweeter and

6.5” woofer, offering excellent performance

for all types of music and movies.

CS-5R

2-Way 5.25” woofer with .75” ﬁxed

tweeter CS-6R incorporates a .75” dome

tweeter and 5.25” woofer, offering excellent

performance in smaller spaces for all types

of music and movies.

CS-650

2-Way in-wall 6.5” woofer with .75” tweeter

All CS Series speakers are designed to handle

the full dynamic range of today’s multi-channel

digital sources. The CS-650 includes a durable

two-way weather-resistant design for use indoors

or out when an in-wall application is needed.

CS-525

2-Way in-wall 5.25” woofer with .75” tweeter

The CS-525 offers quality performance for

smaller areas in a durable two-way weather-re-

sistant design for use indoors or out.

CS-6DVR

2-Way 6.5” dual voice coil woofer with a

dual .75” pivoting tweeter assembly

CS-6DVR incorporates two .75” dome tweet-

ers in a pivoting housing and 6.5” dual voice

coil woofer, offering stereo sound from a

single speaker for secondary listening areas.

Included jumper switches also allow for use as

a bipole or dipole surround speaker in a home

theater system.

CS-5DVR

2-Way 5.25” dual voice coil woofer with a

dual .75” pivoting tweeter assembly

CS-5DVR incorporates two .75” dome tweeters

in a pivoting housing and 5.25” dual voice coil

woofer, offering stereo sound from a single

speaker for smaller secondary listening areas.

Included jumper switches also allow for use as

a bipole or dipole surround speaker in a home

theater system.

Acoustically superior

The CS Series is engineered to handle the

dynamic range of multi-channel audio tech-

nologies like Dolby Digital and DTS and well

as traditional two-channel sources. The CS

Series delivers high-end tonal balance and

a clear distinction between musical notes.

Durable performance

The line comprises two-way models

including 5.25” or 6.5” polypropylene

cones with butyl-rubber surrounds for

lasting performance, indoors or out. Mul-

tiple tweeter conﬁgurations allow the CS

Series to match the needs of any room.

T E C H N O L O G Y

In-wall & In-ceiling Systems With High-end Tonal Balance

Tweeter

Woofer

Frequency

Sensitivity

Impedence

Finish

Mounting Depth

Inputs

Grilles

Recomended

Amp Power

Cutout Dim.

Outside Dim.

Ship Weight

CS-6R/PT CS-6R

.75” Aimable Dome

6.5” Polypropylene /Butyl surround

48 Hz - 20 kHz

90 dB

8 Ohms

White

3 1/2”

Push Termial

Perforated

5 - 100 Watts RMS

7 5/8”

8 13/16”

4.5 lbs

.75” Dome

6.5” Polypropylene /Butyl surround

48 Hz - 20 kHz

90 dB

8 Ohms

White

2 5/8”

Push Termial

Perforated

5 - 100 Watts RMS

8 1/8”

9 1/2”

3.5 lbs

CS-5R

.75” Dome

5.25” Polypropylene /Butyl surround

60 Hz - 20 kHz

90 dB

8 Ohms

White

2 3/8”

Push Termial

Perforated

5 - 80 Watts RMS

7”

8 3/8”

3 lbs

CS-6DVR CS-650 CS-525

Tweeter

Woofer

Frequency

Sensitivity

Impedence

Finish

Mounting Depth

Inputs

Grilles

Recomended

Amp Power

Cutout Dim.

Outside Dim.

Ship Weight

2 x .75” Aimable Dome

6.5” Polypropylene /Butyl surround

48 Hz - 20 kHz

90 dB

8 Ohms

White

3 1/2”

Bi/Dipole Switchable

Perforated

5 - 100 Watts RMS

7 5/8”

8 13/16”

5 lbs

2 x .75” dome

6.5” polypropylene

52 Hz - 20 kHz ( 3 dB)

90 dB

8 Ohms

3-1/8”

Push Termial

10 - 80 Watts RMS

6-3/4” (W) x 10-1/4” (H)

8” (W) x 11-3/4” (H)”

3 lbs

2 x .75” dome

5.25” polypropylene

68 Hz - 20 kHz ( 3 dB)

90 dB

8 Ohms

3-1/8”

Push Termial

10 - 65 Watts RMS

6-3/4” (W) x 10-1/4 (H)”

8” (W) x 11-3/4” (H)”

3 lbs

CS-5DVR

2 x .75” Aimable Dome

5.25” Polypropylene /Butyl surround

48 Hz - 20 kHz

90 dB

8 Ohms

White

3 1/2”

Bi/Dipole Switchable

Perforated

5 - 100 Watts RMS

6 7/8”

8 1/8”

3 lbs

All Phase Tech products come with a transferable 10-year factory warranty.

P#217-1016
