Install Instructions For:
| 888-phase tk | www.phasetech.com |
CS-6RCS-6R
© 2005 PhaseTech, Inc. All rights reserved.
The CS-6R full range stereo custom installation loud-
speaker has been designed for easy in-wall or ceiling
mounting. Please read the instructions thoroughly before
beginning and follow them step by step for a successful
installation and years of listening pleasure.
Limited Warranty
Phase Technology warrants its loudspeakers to be free
from defects in material and workmanship for a period of
ten (10) years for speaker product and three (3) years for
the electronic components to the original purchaser.
Purchase must be made from an authorized Phase
Technology dealer.
This warranty does not cover service or parts to repair
damage caused by misuse, abuse, damage while in
transit, alterations, unauthorized repairs, failure to follow
instructions, fire, flood or any other cause beyond the
reasonable control of Phase Technology. Defects in
speaker cabinets or grilles must be brought to the
attention of your dealer immediately after purchase. This
warranty will be void if the products’ serial number has
been altered or removed.
To obtain warranty service, defective product must be
shipped in its original carton or equivalent together with
original invoice or bill of sale, insured and prepaid to
your authorized Phase Technology dealer or the factory
when warranty service is requested.
If you choose to return the defective product to the
factory you must first call us at (904) 777-0700 to
obtain a Return Authorization number prior to shipping.
Product repaired under this warranty will be returned to
you freight collect.
Implied Warranties
Phase Technology will not pay for loss of time,
inconvenience, loss of use, or property damage caused
by your speaker product or its failure to work, or any
other incidental or consequential damages. Some states
do not allow the exclusion or limitation of consequential
damages, so the above limitation may not apply to you.
Phase Technology Corporation
6400 Youngerman Circle
Jacksonville, Florida 32244
(904) 777-0700 Telephone
(904) 771-7793 Fax
Mounting Considerations
CAUTION: When choosing a location for mounting the speakers, make
certain the wall or ceiling material is sturdy enough to support the weight of the
speakers.
1. Decide where the speakers will be mounted. Be careful not to
mount them over a stud or any other obstruction and at least
3/4” from the stud.
2. It is recommended for maximum performance, although not
necessary, that you place a piece of fiberglass or some similar
dampening material behind the speaker.
3. Be certain you can run the speaker wire to the point where the
speaker will be mounted. Phase Technology recommends 18
gauge for distances up to 15 feet and a minimum of 16 gauge for
distances up to 50 feet. For longer lengths or purer signal
connections, consult your retailer.
4. The grilles and baffle edge come in an off-white finish. Paint them using a
good quality interior or exterior paint in the color of your choice. Place the
grille in the baffle prior to painting. The cloth behind the grille will keep the
paint from getting on the speakers. Use as light a coating as possible to
avoid clogging the holes in the grille.
**Do not paint the speaker drivers as this could cause damage**
Mounting Instructions
1. Using the template as a guide (inside package filler), carefully cut a
hole in the wall or ceiling. Find the speaker wire leads and pull them through.
2. Remove the grille from the speaker system.
3. Locate the speaker wire and attach it to the CI input terminals: red/plus,
black/minus
4. If you are using any dampening material, secure it in the hole behind where
the speaker will be located.
5. Place the speaker in the cut-out.
6. Turn the four locking screws counterclockwise one full turn to release the
locking clamps. Once released, turn them clock-wise until they firmly clamp the
speaker to the mounting surface.
7. Position the grille on the baffle and firmly push it into the flange until you feel
it is securely in position.
8. The speaker system is now ready to be turned on.
9. For removal of the custom installation speaker remove the grille. Turn the
four locking screws counterclockwise until they release from the wall or ceiling.
Then pull the system out and disconnect the speaker wires.
