PowerWalker VFI 3000 LCD Guida all'installazione

Product Information

PowerWalker is a brand of:

BlueWalker GmbH Phone: +49 (0) 2137 / 92 98 73 • ax: +49 (0) 2137 / 78 73 925

Martin-Buber-Strasse 12 • D-41470 Neuss • Germany [email protected] • www.bluewalker.eu • www.powerwalker.com

PowerWalker VFI 3000 LCD

Online UPS

3000VA Online UPS

IEC Outlet, Modem/Phone Surge Protection, EPO

function

USB & RS-232 Connection for monitoring

LCD display to show all UPS settings

Programmable power management outlets

Product Features

With true double-conversion design, PowerWalker V I 3000 LCD provides

powerful and overall protection to your sensitive devices. It can accept wider

input voltage for harsh environment. It's perfect protection for your servers

and workstations.

• True double-conversion

• Output power factor 0.8

• Wide input voltage range (110-300 VAC)

• Input power factor correction 0.98

• 50/60 Hz frequency converter mode

• ECO mode operation for energy saving (ECO)

• Programmable power management outlet

• Emergency power off (EPO) function

• WAGO connection kit (for external battery packs) included

• Optional SNMP module

Backsite view

Item

10120106

Connection terminal

Product Information

PowerWalker is a brand of:

BlueWalker GmbH Phone: +49 (0) 2137 / 92 98 73 • ax: +49 (0) 2137 / 78 73 925

Martin-Buber-Strasse 12 • D-41470 Neuss • Germany [email protected] • www.bluewalker.eu • www.powerwalker.com

Technical Details

Product Features

Ca acity 3000VA / 2400W

In ut

Voltage Range

Low Line Transfer 160/140/120/110VAC ± 5%

Voltage Range

Low Line Comeback 175VAC ±5%

Voltage Range

High Line Transfer 300VAC ± 5%

Voltage Range

High Line Comeback 290VAC ± 5VAC

Frequency Range 50Hz or 60Hz

Phase Single phase with ground

Power Factor +/- 1Hz

Out ut

AC Voltage Regulation

(Batt. Mode) ± 3 %

Frequency Range

(Synchronized Range)

47 ~ 53Hz or

57 ~ 63Hz

Frequency Range

(Batt. Mode)

50Hz ± 0.25Hz or

60Hz ± 0.3Hz

Current Crest Ratio 3:1

Harmonic Distortion ≤ 4% THD (Linear Load)

≤ 7% THD (Non-linear Load)

Waveform (Batt. Mode) Pure Sine Wave

Transfer Time

Inverter to By ass 4ms (Typical)

Efficiency

AC Mode 88%

Battery Mode 83%

Battery

Ty e 12V / 9Ah

Quantity 6x

Recharge Time 4h to 90%

Audio Indicators

Battery Mode Beep every 4 sec

Low Battery Beep every second

Overload Beep twice every second

Fault Continuously sounding

O tional Accessoires

SNMP Module DP-801 Item-No. 10120502

Battery Pack (12V / 9Ah) Item-No. 10120511

Version: EN 12/04/2011

We reserve the right for technical changes and mistakes

LCD Dis lay

LCD Indicators

UPS status, Load level, Battery level,

Input/Output voltage, Discharge

timer, and ault conditions

Connections

Communication USB port & RS-232 port

Outlets 6x IEC (2x programmable)

Protection Port RJ-11 in/out

SNMP optional

EPO Yes

WAGO connection Yes, kit included

Software & System Requirements

Software ViewPower

O erating System or details visit:

www.powerwalker.com/viewpower.html

Other 1x USB port or 1x RS-232Port

Product Details

Dimensions 421mm x 190mm x 318mm (DxWxH)

Colour Black

Weight UPS case 29.1kg

Fan Control Always on

Noise Level < 45dB at 1 meter

Model Code V I 3000 LCD

Environment

Tem erature 0°C – 40°C

Humidity 20 - 90% (non-condensing)

Package Content

Package Content PowerWalker V I 3000 LCD,

Software CD, USB cable, 2x IEC

output cables, power cord, WAGO

connection Kit, printed manual

Logistic Data

Giftbox Language EN/DE/ R/ES/IT/PT/SE/ I/NO/TR

RU/UA/BY/PL/CZ/HR/HU/BG/KZ/CS

Manual Language EN/DE/ R/ES/RU

Dimension/Giftbox 555mm x 325mm x 465mm (DxWxH)

Weight/Giftbox 31.5kg

Pieces/carton 1

Pieces/ alette 16

BlueWalker

Item-No. 10120106

EAN 4260074972757

Warranty 24 Months (except battery)

Use UPS configurator on www.powerwalker.com for

detailed backup time information.
