Powerware 5125 Tower Manuale utente

POWERWARE®5125 Tower

User’s Guide

1000VA, 1500VA, 2000VA, 2200VA

www.powerware.com.au

POWERWARE®5125

1000, 1500, 2000 & 2200VA

User’s Guide

Special Symbols

The following are examples of symbols used on the UPS to alert you to important information.

RISK OF ELECTRIC SHOCK - Indicates that a risk of electric shock is present

and the associated warning should be observed.

CAUTION: REFER TO OPERATOR’S MANUAL - Refer to your operator’s manu-

al for additional information, such as important operating and maintenance

instructions.

RJ-45 RECEPTACLE - This receptacle provides network interface connections.

Do not plug telephone or telecommunications equipment into this receptacle.

This symbol indicates that you should not discard the UPS or the UPS batteries in

the trash. The UPS may contain sealed, lead-acid batteries. Batteries must be

recycled.

5125Manual.qxd OMM5125TRev3

Where the brand name “Powerware” is used,

the term refers to Eaton’s Powerware Division, trading in Australia

as Eaton Power Quality Pty Ltd

Table of Contents

Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

1.0 Powerware 5125 - One of the Best! . . . . . . . . . . . . . . . . . . . . .3

2.0 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

3.0 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

4.0 Additional UPS Features . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

5.0 UPS Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

6.0 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

7.0 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

8.0 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

9.0 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Powerware Australia/New Zealand Offices . . . . . . . . . . . . . . .34

Trademarks

Windows is a registered trademark of Microsoft Corporation.

All other brand and product names are trademarks or registered trademarks of their

respective holders.

Safety Instructions

IMPORTANT SAFETY INSTRUCTIONS!

SAVE THESE INSTRUCTIONS!

This User Guide contains important instructions for your Powerware 5125 that must be followed

during installation and maintenance of the UPS and batteries.

The installation and use of this product must comply with all national, federal, state, municipal, or

local codes that apply. For assistance, call Powerware Service or your local Powerware office.

If the Powerware 5125 has been damaged during shipment, call your vendor immediately.

If the Powerware 5125 is stored, the batteries should be recharged every 6 months. If stored

above 25°Celsius, recharge the batteries more often.

CAUTION!

Whenever the Powerware 5125 is “On,” there may be dangerous voltage present at the unit’s

outlets. This is true because the unit’s battery supplies power even if the unit is not plugged

into the wall outlet. The unit contains dangerous voltages.

To reduce the risk of electric shock, install in a temperature-controlled and humidity-

controlled indoor area free of conductive contaminants.

The power supply cord is intended to serve as the disconnect device. The socket-outlet shall

be near the equipment and shall be easily accessible.

With the exception of the user-replaceable batteries, all servicing of this equipment must be

performed by qualified service personnel.

Before maintenance or repair, all connections must be removed. Before maintenance, repair,

or shipment, the unit must be completely switched off and unplugged or disconnected.

1.0 Powerware 5125 - One of the Best!

The Powerware 5125 uninterruptible power system (UPS) protects your sensitive electronic equip-

ment from basic power problems such as power failures, power sags, power surges, brownouts,

and line noise.

Power outages can occur when you least expect it and power quality can be erratic. These power

problems have the potential to corrupt critical data, destroy unsaved work sessions, and damage

hardware - causing hours of lost productivity and expensive repairs.

With the Powerware 5125, you can safely eliminate the effects of power disturbances and guard

the integrity of your equipment. The Powerware 5125 was designed for critical applications such

as PC’s, servers, workstations, and telecommunications equipment. Figure 1 shows the

Powerware 5125 UPS with an optional Extended Battery Module (EBM)

Figure 1. The Powerware 5125

Providing outstanding performance and reliability, the Powerware 5125’s unique benefits include the

following:

• Advanced Battery Management Plus (ABM Plus™) doubles battery service life, optimises recharge

time and provides a warning before the end of useful battery life.

• Buck and Double Boost regulation ensures consistent voltage to your load by correcting voltage

fluctuations without using battery power.

• Hours of extended runtime with up to four EBMs.

• Hot-swappable batteries simplify maintenance by allowing you to replace batteries safely without

powering down the critical load.

• Start-on-battery capability allows you to power up the UPS even if utility power is not available.

• Advanced power management with the Software Suite CD for graceful shutdowns and power

monitoring.

• Sequential shutdown and load management through separate receptacle groups, called load

segments.

• Network Transient Protector guards your network communications equipment from surges.

• Optional X-Slot™modules provide enhanced communication capabilities for increased power

protection and control.

2.0 Installation

This section explains:

• UPS installation

• UPS rear panels

Installing the UPS

The following steps explain how to install the UPS. Figure 2 shows a typical installation only. See “UPS

Rear Panels” on Page 7 for the rear panel of each model.

NOTE Do not make unauthorised changes to the UPS, otherwise damage may occur to your

equipment and void your warranty

1. If installing an optional EBM, continue to Step 2; otherwise skip to Step 4

2. Plug the EBM cable into the battery connector on the UPS rear panel (See Figure 2).

3. If a second EBM is to be installed, plug the EBM cable of the second cabinet into the battery

connector on the first EBM. Up to four EBMs may be connected to the UPS.

Figure 2. Typical Installation with Two EBMs

4. If you are installing power management software, connect your computer to the UPS

communication port using the supplied communication cable.

5. Plug the detachable UPS power cord into the input connector on the UPS rear panel.

6. Plug the UPS power cord into a power outlet. The front panel indicators cycle through a startup

sequence while the UPS conducts a self-test.

When the self-test is complete, the indicator flashes, indicating the UPS is in Standby mode

with the equipment offline. If the alarm beeps or a UPS alarm indicator stays on, see Table 9 on

Page 25.

7. Plug the equipment to be protected into the appropriate UPS output receptacles (see page 15 for

more information on load segments).

DO NOT protect laser printers with the UPS because of the exceptionally high power

requirements of the heating elements.

8. Press and hold the ON button until you hear the UPS beep (approximately one second). The

indicator stops flashing and the bar graph indicators display the percentage of load being applied

to the UPS

The UPS is now in Normal mode and supplying power to your equipment.

NOTE The batteries charge to 90% capacity in approximately 3 hours. However, it is

recommended that the batteries charge for 24 hours after installation or long-term

storage.

Figure 3. PW51251000A and PW51251500A Rear Panel

Figure 4. PW51252000A and PW51252200A Rear Panel
