INSTRUCTIONS FOR USE
Pro-Ject CD Box
© Audio Trade GmbH · Pro-Ject CD Box · Revision 15.10.10/15.12.10
2
Dear music lover,
thank you for purchasing a PRO-JECT AUDIO CD Box.
In order to achieve maximum performance and reliability you should study these instructions for use carefully.
!
Warning of a hazard for the user, the unit or possible misuse.
Important notice.
Help to protect the environment
If you are not going to use the player for an extended period of time, e.g. vacation, we suggest to disconnect
it from the AC mains. Please be certain that the player is in standby-mode prior to unplugging the power
supply from the AC mains.
Caution! Laser diode
This product contains a laser diode of higher class than 1. To ensure continued safety, do not remove any
covers or attempt to gain access to the inside of the product. Refer all servicing to qualified personnel.
Discs to avoid
If a disc is cracked, chipped, warped, or otherwise damaged, don't risk to play it. You could end up damaging
the unit. This player is designed for use with fully circular, full size CDs only. Use of shaped discs is not
recommended. The manufacturer and the distributor disclaims all liability arising in connection with the use
of damaged or shaped discs.
Connectors
Out
Right
Left
!
Make all connections whilst the converter is disconnected from the power supply.
Take care to connect the left and right channels correctly. The right channel is usually marked red,
the left channel black or white.
Connection to the amplifier
Connect the Out socket to a line input (such as AUX) on your amplifier.
Mains power connection
The unit is supplied with a power supply suitable for your country's mains supply. Check the label before
connecting to ensure compliance with the mains rating in your house. Connect the low voltage plug from the
power supply to the Power ~16V socket before connecting the power supply to the mains.
© Audio Trade GmbH · Pro-Ject CD Box · Revision 15.10.10/15.12.10
3
Remote control
123
6
9
8
5
4
7
0
VOL+
VOL-
ON/OFF
STOP
+10
Standby
1
ON/OFF
turns the unit on or back into standby
Volume control
0
_
VOL
or
0+
VOL
adjusts the sound volume of your Pro-Ject Audio amplifier
Stop
STOP stops playback
Play / Pause
8starts and pauses playback
Selecting tracks
1- 9and
+10
accesses a specific track directly and start playback.
For example, to play track 19, press
+10
and 9. To play track 29, press
+10
, 2and 9.
Stepping between tracks, scanning through the disc
Press
7
or
9
. The display shows the number of the tracks as you step.
Press and hold the button
7
for fast reverse scanning.
9
activates fast forward scanning.
Repeat and random play
Press the 0button repeatedly selects the two repeat modes. The display shows:
repeat play for the current track
repeat play for all tracks
Pressing 0again takes the CD player back to standard playback.
© Audio Trade GmbH · Pro-Ject CD Box · Revision 15.10.10/15.12.10
4
Front panel controls
CD Box
ABC D
To switch on from standby or to standby
A short press of the button Cswitches the player to its fully operational status. To return to standby, press C
for more than three seconds. The display shows STANDBY when the unit is in standby.
To switch to standby, playback must be stopped.
Inserting and ejecting a disc
Switch the unit on from standby. Insert the disc into the slot, with the label side facing upwards. The slot-loading
mechanism will load the disc automatically. The display shows the total number of tracks on the disc and the
total duration of the disc.
A short press of the button Cstops playback. Pressing (short) Cagain, ejects the disc.
Play
Bstarts playback of the first track. The display shows the current track number, the elapsed time of the
current track and the play icon.
Pause
Bpauses playback. The display shows the current track number, the elapsed time of the current track and the
pause icon.
To resume playback press Bagain.
Stop
A short press of the button Cstops playback. The display shows the total number of tracks on the disc, the
total duration of the disc and the stop icon.
Stepping between tracks
Press the buttons A (previous track) or D (next track). The display shows the number of the tracks as you step,
the elapsed time of the current track and the step icon.
Scanning through the disc
Press and hold the button A(fast backward) or D(fast forward) to scan through the disc. The display shows
the current track number, the elapsed time of the current track and the scan icon.
Releasing Aor Dwill take you back to playback.
© Audio Trade GmbH · Pro-Ject CD Box · Revision 15.10.10/15.12.10
5
Replacing batteries
Proceed as follows:
• Unlock and slide open the battery case cover
• Replace the battery.
Make sure the battery is the right way round !
• Close the battery case cover
Battery type: 1 x CR2032 / 3V or 1 x CR2025 / 3V
Do not dispose the batteries as ordinary domestic refuse. Please dispose your exhausted batteries at
the appropriate collection sites - usually located at supermarkets and drugstores.
Technical specifications Pro-Ject CD Box
Supports: CD, CD-R, CD-RW and Hybrid-SACD
Frequency response: 20Hz - 20kHz, +0dB/-0,1dB
Noise floor: 108dB / 1V
THD: 0,004%
Line-level output: 1 pair RCA/Phono sockets
Output voltage: 1Vrms
D/A converter: Texas Instruments TLV320DAC23
24Bit/96kHz, 8-times oversampling
Outboard power supply: 16V/1.000mA AC; suitable for your country's mains supply
Power consumption: 16V/350mA AC
Replacement battery remote control: 1 x CR2032 / 3V or 1 x CR2025 / 3V
Dimensions W x H x D (D with sockets): 206 x 36 x 150 (156)mm
Weight: 1.260g without power supply
Service
Should you encounter a problem which you are not able to alleviate or identify despite the above information,
please contact your dealer for further advice. Only when the problem cannot be resolved there should the
unit be sent to the responsible distributor in your country.
Warranty
The manufacturer accepts no responsibility for damage caused by not adhering to these instructions
for use. Modification or change to any part of the product by unauthorized persons release the
manufacturer from any liability over and above the lawful rights of the customer.
PRO-JECT is a Registered Trademark of H. Lichtenegger.
This guide was produced by: Audio Trade GmbH
Copyright © 2010. All rights reserved.
The information was correct at the time of going to
press. The manufacturer reserves the right to make
changes to the technical specification without prior
notice as deemed necessary to uphold the ongoing
process of technical development.
